Summary of Contents for djpower XUN V-5

  • Page 2: Before You Begin

    Useful information. Disclaimer The information and specifications contained in this User Manual are subject to change without notice. DJPOWER assumes no responsibility or liability for any errors or omissions and reserves the right to revise or to create this manual at any time.

  • Page 3: Safety Notes

    V-5 USER MANUAL Safety Notes Please read the following Safety Notes carefully before working with the product. The notes include important safety information about installation, usage, and maintenance. 1.5.1 Personal Safety • Always connect the product to a grounded circuit to avoid the risk of electrocution. •...

  • Page 4: Product Overview

    In the event of a serious operating problem, stop using the product immediately. • Use only DJPOWER Spark Seed PRO-K4 or PRO-4. Keep this User Manual for future use. If you sell the product, be sure that the purchaser receives this document.

  • Page 5: Technical Specifications

    V-5 USER MANUAL Product Dimensions TECHNICAL SPECIFICATIONS Identification Category Spark Machine Model AC Power Input Voltage & Rate AC 220-240 V, 50/60 Hz Current Limiter Specifications 10 A, 250 V Typical Current 10 A Current Limiter Type Breaker Nominal Total Power Consumption 500 W Power Input/Output Connector Lockable PowerCon...
  • Page 6 V-5 USER MANUAL Placement & Horizontal √ Mounting Inclined ≤15° Vertical × Hang Upside Down × Rigging & Trussing × Rotating Nozzle × Deflector × Control On-device Manual Control LCD Control Board Wireless Control × Wired Control × Control Protocol DMX-512 DMX Channel Range RFID Card...
  • Page 7 15°. 4.5.2 Rigging DJPOWER recommends using the following general guidelines when mounting this product. • Before deciding on a location for the product, make sure there is easy access to the product for maintenance and programming purposes.

  • Page 8: Preparing For Operation

    V-5 USER MANUAL OPERATION Preparing for Operation • After checking that all the parts are intact and complete, position the machine on flat. • Fill the consumable into feed port when power off. • Always connect the product to a grounded circuit. Before power on, make sure it is connected with the rated voltage. •...
  • Page 9 V-5 USER MANUAL 5.3.2 Menu Map Parameter Display Description Range Heating Up 530℃-630℃ Temp Shows the device is heating Heating Up The current temperature, current pressure and delay Preparing time will cycle through the display. Pressure Page Heating Up Delat 1.0S Ready to Spark 530℃-630℃...
  • Page 10 V-5 USER MANUAL Remaining Time Device remaining time 10次 Press <ENTER> for 3 seconds to enter the advanced setting menu page, then press <MENU> to select the corresponding menu, and press ▲ or ▼ to select an option or value. Temperature Set Device operating temperature settings 530℃-630℃...

  • Page 11: Starting Address

    When choosing a startup DMX address, always consider the number of DMX channels. If you choose a starting address that is too high, some channels will not be accessible. DJPOWER® V-5 uses 2 DMX channels. If you need to control all channels, it is recommended to configure the highest starting address as 512.

  • Page 12: Running Time

    V-5 USER MANUAL Parameter Display Description Range Spark output, current temperature, current Current Temperature 33 pressure, and delay time, it will be displayed on DMX Address the screen. Current Pressure DMX Address Delat Time 1.5S DMX Address 5.4.3 DMX Channel Assignments and Values Channel Value Description...

  • Page 13: Manual Mode

    Precaution for use • The Spark Seed could be only filled in and used for the DJPOWER Spark Machine after successfully identified by swiping Consumable ID card. • Make sure to fill the Spark Seed through the feed port on the top of the fixture and when power supply is off.

  • Page 14: Technical Information

    After a period of using, check if there is any consumable tuberculation inside the nozzle. Do necessary cleaning up if there has some, or it may affect spark performance, even damage the machine. Test-run your DJPOWER@ V-5 on a monthly basis to achieve the best performance. Storage 7.2.1...
  • Page 15 V-5 USER MANUAL 7.3.2 Device Error Menu Map Errors Display Possible Cause Device Error When the temperature is higher than the limit temperature, the over Over heat shutdown temperature protection function is activated. Device Error Heating system cannot reach pre-set target temperature after 10-min Heat up failed heat-up Device Error...
