Summary of Contents for djpower djv DJ-300
-
Page 2: Safety Use
Foreword Thank you very much of choosing DJPOWER DJ-300 MINI HAZE MACHINE. Before starting operation, we strongly suggest you to read the user manual carefully. Following the instructions here will ensure your safety while operating the machine, easily achieve the best effect, as well as understand the right way to care for and maintain the machine, hence to prolong the product life cycle. -
Page 3: Function Specification
• For adult use only. Fixture must be installed out of the reach of children. Never leave the unit running unattended. Keep it away from fire , combustible and flammable materials. • Position the machine in well-ventilated area. Please leave about 50cm spaces surrounding the unit. •... -
Page 4: Digital Display
MENU button: Different pages can be chosen, there are 4 pages in total. UP : Increase value set for subpages. DOWM: Decrease value set for subpages. Enter: Confirm or exit. Digital display 1) Heat page It shows that machine is heating . After finishing heating, this page will disappear, and show relevant operation page, output page will show as default. - Page 5 Values 10s-300s can be set by up and down,and it can be save after setting by enter. 3.Set the time duration in TIMER mode Values 10s-300s can be set by up and down,and it can be save after setting by ente. Function specification ...
- Page 6 M-1 wired remote controller Operating Instruction (optional, extra charge) Manual remote control operation(M-1) Note: This button is point contact button, Press the button on the remote control to start smoking, and press it again to stop smoking. W-2 wireless remote controller Operating Instruction (optional, extra charge) This device can use optional wireless controller to control the fog, this includes transmitters and receivers, you can control up to four separate fog machine, if it is to let them run at the same time the number could be more.
-
Page 7: Service And Maintenance
Service and Maintenance • Please use DJPOWER fluid. It will prolong the lifetime of machines. To avoid danger, it is not allowed to take machine apart by unprofessional man. Neither to refit the machine. • Excessive dust, fluid residue and dirt will degrade performance and cause overheating. Remove dust from air vents with air compressor, vacuum or a soft brush. -
Page 8: Product Overview
Power: 230 W Heat-up Time: 2 min 30 seconds Output: 3,000 cuft/min Fluid consumption Rate: 5 h 33 min/L Controller Optional: W-2 or M-1 DMX-512: √ Tank capacity: 1.5 L N.W.: 4 kg G.W.: 5 kg Machine Size: 336/155/253 mm Package Size: 355/255/275 mm DMX Channel:... - Page 9 Fog machine oil blowout and heater blocking phenomenon analysis Please use the original consumables, protect your health and life of machine A.Oil injection trouble: Refers to the fog fluid atomizing in the heater pipe of the machine is not good, heater temperature cannot be timely and effective transmit to the fog fluid, fog fluid cannot all atomization and lead to oil injection First reason: Using the low quality or counterfeit fog fluid, low quality fog fluid have more impurities,...
