DIRECT STEAM FLOOR MOUNTED
TILTING 2/3 JACKETED KETTLES
VDLT & VDPT SERIES
MODELS
VDLT20
VDLT30
VDLT40
VDLT60
VDLT80
For additional information on Vulcan-Hart or to locate an authorized
parts and service provider in your area, visit our website at www.vulcanhart.com
VULCAN-HART
DIVISION OF ITW FOOD EQUIPMENT GROUP, LLC
WWW.VULCANHART.COM
REPLACEMENT PARTS
ML-103414
ML-103415
ML-103416
ML-103417
ML-103418
CATALOG OF
Model VDLT40
P.O. BOX 696, LOUISVILLE, KY 40201-0696
FORM 37115 (July 2007)
TEL. (800) 814-2028
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Vulcan-Hart ML-103414
Summary of Contents for Vulcan-Hart ML-103414
- Page 1 VDLT40 ML-103416 VDLT60 ML-103417 VDLT80 ML-103418 For additional information on Vulcan-Hart or to locate an authorized parts and service provider in your area, visit our website at www.vulcanhart.com VULCAN-HART DIVISION OF ITW FOOD EQUIPMENT GROUP, LLC WWW.VULCANHART.COM CATALOG OF REPLACEMENT PARTS Model VDLT40 P.O.
-
Page 2: Gear Box Assembly
REPLACEMENT PARTS VDLT & VDPT SERIES 2/3 JACKETED KETTLES GEAR BOX ASSEMBLY – 2 –... - Page 3 PART NO. 00-881962 Handwheel ... 1 SC-047-42 Set Screw ... 1 00-836936 Tilting Shaft ... 1 00-836952 Tension Pin ... 1 00-855086 Worm & Segment Gear Kit ... 1 00-881963 Thrust Bearing ... 2 NS-013-50 Jam Nut ... 2 00-881984 Steam Control Valve ...
- Page 4 REPLACEMENT PARTS VDLT & VDPT SERIES 2/3 JACKETED KETTLES HINGED COUNTERBALANCED COVER (OPTIONAL) PART NO. 00-842956 Bolt ... 1 00-850622 Washer ... 1 00-851961 Cover (20 Gallon) ... 1 00-850430 Cover (30 Gallon) ... 1 00-850217 Cover (40 Gallon) ... 1 00-844424 Cover (60 Gallon) ...
- Page 5 SPRING ASSISTED HINGE ASSEMBLY (OPTIONAL) PART NO. 00-836977 Lock Pin ... 1 00-836978 End Lock Plate ... 1 00-836979 Stationary Disc ... 1 00-844367-00034 Cores ... 2 00-844367-00035 Spring ... 1 00-850518-00002 Handle Assy. (20 Gallon) ... 1 00-850518-00003 Handle Assy. (30 Gallon) ... 1 00-850518 Handle Assy.
- Page 6 REPLACEMENT PARTS VDLT & VDPT SERIES 2/3 JACKETED KETTLES PART NO. 00-836939 Nut ... 1 ... 1 ... 00-836940 Nut ... 1 00-836967 Handle ... 1 ... 1 ... 00-836942 Handle ... 1 00-836943 Hex. Assembly Nut ... 1 ... 00-836944 Hex.
