DIGITAL PHASE SHIFTER
MODEL:CPS-5HP/CPS-7.5HP/CPS-10HP
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the major
top brands and does not necessarily mean to cover all categories of tools offered by us. You
are kindly reminded to verify carefully when you are placing an order with us if you are
actually saving half in comparison with the top major brands.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for VEVOR CPS-5HP
Summary of Contents for VEVOR CPS-5HP
- Page 1 Technical Support and E-Warranty Certificate www.vevor.com/support DIGITAL PHASE SHIFTER MODEL:CPS-5HP/CPS-7.5HP/CPS-10HP We continue to be committed to provide you tools with competitive price. "Save Half", "Half Price" or any other similar expressions used by us only represents an estimate of savings you might benefit from buying certain tools with us compared to the major top brands and does not necessarily mean to cover all categories of tools offered by us.
- Page 2 This is the original instruction, please read all manual instructions carefully before operating. VEVOR reserves a clear interpretation of our user manual. The appearance of the product shall be subject to the product you received. Please forgive us that we won't inform you again if there are any technology or software updates on our product.
-
Page 3: Correct Disposal
Warning-To reduce the risk of injury, user must read instructions manual carefully. CORRECT DISPOSAL This product is subject to the provision of European Directive 2012/19/EC. The symbol showing a wheelie bin crossed through indicates that the product requires separate refuse collection in the European Union. -
Page 4: Fcc Information
Continued use may cause fire or electric shock. WARNING ▪ Use this DPS only for operation 3 phase motor(220-240V) from single phase power (220-240V) supply. ▪ As the DPS has no protection device, install safety circuit breaker at the input terminal to use it ▪In the event of abnormality, cut off the power immediately.(There is a danger of electric shock.) ▪... -
Page 5: Technical Parameter
If you use a DPS that is one step above your motor capacity. you can get 90 to 95% efficiency. (65 to 70% efficiency when using DPS with the same capacity) ex) in the case of 5HP motor: If you use CPS-5HP model: 65 to 70% efficiency - 4 -... - Page 6 If you use CPS-5HP model: 90 to 95% efficiency Q/A USING FOR DPS Question / Answer 1. Only 2 phases come out from the DPS's output voltage. 3 phase voltages are output only when the motor is running. When the motor is not running, it is normal for only single phase output to come out.
- Page 7 load.Also, make sure that the magnetic control line is connected to the U and W positions of the DPS output. 10. How should the magnet switch, overload, and breaker capacities be selected? When using the above products, it should be selected as twice the capacity of the rated current of the motor.
- Page 8 - 7 -...
