Vulcan-Hart HEG24R Specifications

SpECIFICATIONS:
Heavy duty electric griddle, Vulcan-Hart Model No. ________.
Stainless steel front, sides and 4" adjustable legs. _____"w x
_____"d x 1 ⁄ " thick polished steel griddle plate. One solid sheathed
2
tubular incoloy heating element, thermostat and cycling light per
each 12" griddle width. Thermostat adjusts from 200° to 450°F.
Stainless steel splash shield is 4" high at the back and tapers
down to 2" in the front. 3 ⁄ " wide grease trough empties into large
1
8
capacity grease drawer. Requires 208 or 240 volt, 60 Hz, 1 or 3
phase power supply.
NSF listed. U L listed. U L listed to Canadian safety standards.
SpECIFy VOLTAGE AND pHASE WHEN ORDERING.
VULCAN-HART COmpANy, p.O. BOX 696, LOUISVILLE, Ky 40201, TEL. 1-800-814-2028
F-31616 (04-07)
502-778-2791 QUOTE & ORDER FAX: 1-800-444-0602
Item # __________________________
HEG SERIES
HEAVy DUTy ELECTRIC GRIDDLES
HEG24R
24"w x 18"d griddle plate
■
HEG36S 36"w x 18"d griddle plate
■
HEG36D
36"w x 24"d griddle plate
■
HEG48D 48"w x 24"d griddle plate
■
HEG60D 60"w x 24"d griddle plate
■
HEG72D
72"w x 24"d griddle plate
■
STANDARD FEATURES
■ Stainless steel front, sides and 4" adjustable legs.
⁄ " thick polished steel griddle plate.
■ 1
2
■ One solid sheathed tubular incoloy heating element, thermostat
and cycling light per each 12" griddle width. Thermostat adjusts
from 200° to 450°F.
■ Stainless steel splash shield is 4" high at the back and tapers
down to 2" at the front.
■ 3 ⁄ " wide grease trough empties into large capacity grease
1
8
drawer. 72" wide model has two grease drawers. "R" model
has a front and rear grease trough. "S" & "D" models have a
front grease trough.
■ Requires 208/240 volt, 60 Hz, 1 or 3 phase power supply.
■ One year limited parts and labor warranty.
OpTIONS
Stainless steel stand with undershelf and casters, two
■
locking.
480 volt, 60 Hz, 3 phase.
■
C.S.I. Section 11420
