Vulcan-Hart GHCB34S Specifications

GHCB34S
SPECIFICATIONS
Heavy duty gas char-broiler with cabinet base, _____" wide, Vulcan-
-Hart Model No. ___. Stainless steel body and 6" adjustable legs.
1 / " front gas manifold. Heavy cast iron char-radiants and
1
4
broiler grates. 5 / " wide grates are reversible for "level" broiling
5
16
or self cleaning. Cast-in pitched grease trough in each grate
blade provides fat run-o and controls are-ups. One
16,000 BTU/hr. burner for each broiling grate, _______ BTU/hr.
total input. Three manual control valves. Pilot ignition system.
Underburner ba ing system re ects heat upwards creating a
cool zone beneath the burners. Large capacity grease collector.
Exterior dimensions: ____"w x 39
6" legs.
CSA design certi ed. NSF listed.
SPECIFY TYPE OF GAS AND FINISH WHEN ORDERING.
SPECIFY ALTITUDE WHEN ABOVE 2,000 FT.
VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. 1-800-814-2028
F-32338 (2-05)
/ "d x 36" working height on
1
8
502-778-2791 QUOTE & ORDER FAX: 1-800-444-0602
Item # __________________________
GHCB SERIES
HEAVY DUTY GAS CHAR-BROILER
WITH CABINET BASE
GHCB34S 34" wide char-broiler, 96,000 BTU/hr.
STANDARD FEATURES
Stainless steel body and 6" adjustable legs.
1 / " diameter front gas manifold.
1
4
Heavy cast iron char-radiants and broiler grates.
5 / " wide grates are reversible for "level" broiling or self
5
16
cleaning. Cast-in pitched grease trough in each grate blade
provides fat run-o and controls are-ups.
One 16,000 BTU/hr. burner for each broiling grate.
Three manual control valves.
Pilot ignition system.
Underburner ba ing system re ects heat upwards creating a
cool zone beneath the burners.
Large capacity grease collector.
One year limited parts and labor warranty.
OPTIONS
Stainless steel nishing back panel.
Common front top ledge up to 68" wide. (Not for use on griddle
tops, spreader plates and deep fat fryers.)
Cap and cover manifold end(s).
1 / " stainless steel toe base - 31
5
8
Set of four 5" diameter casters, two locking.
Stainless steel dolly frame with casters, up to 102" wide.
Second year extended limited parts and labor warranty.
ACCESSORIES
17" high stainless steel backguard. (Common backguards
available up to 102" wide.)
23" high stainless steel single deck high shelf. (Common high
shelves available up to 72" wide.)
35" high stainless steel double deck high shelf. (Common high
shelves available up to 72" wide.)
Round rod grate assembly.
Banking kit.
Grate scraper.
Grate lifter.
Gas pressure regulator (specify size and type of gas).
Flexible gas hose with quick disconnect and restraining de-
vice. Consult price book for available sizes.
C.S.I. Section 11420
/ " working height.
5
8
