Vulcan-Hart VCB-S Specifications

(Shown with optional doors)
SPECIFICATIONS:
Heavy duty gas char-broiler, Vulcan-Hart Model No. VCB-36S.
Stainless steel front, control panel, front top ledge, backsplash
and grease trough. Sides finished in black epoxy powder coat
1
paint. 6" adjustable legs. 1 / " diameter front gas manifold. Full
4
width front grease drawer. Heavy cast iron char-radiants and
"Flame Arrestor" broiling grates. 5
for "level" broiling or self cleaning. Cast-in pitched grease trough
in each grate blade provides fat run-off and controls flare-ups.
One 14,500 BTU/hr. cast iron burner for each broiler grate.
Standing pilot ignition system. Underburner baffling system
reflects heat upwards creating a "Cool Zone" in the grease
drawer and drip pan areas.
Exterior dimensions: 36"w x 38"d x 36" working height on 6"
adjustable legs.
CSA design certified. NSF listed.
SPECIFY TYPE OF GAS AND FINISH WHEN ORDERING.
SPECIFY ALTITUDE WHEN ABOVE 2,000 FT.
VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. 1-800-814-2028
F-32500 (10-03)
1 / " wide grates are reversible
4
502-778-2791 QUOTE & ORDER FAX: 1-800-444-0602
Item # __________________________
VCB-S SERIES
HEAVY DUTY GAS CHAR-BROILER WITH OPEN
CABINET BASE
VCB-36S 36" wide, 87,000 BTU/hr.
STANDARD FEATURES
Stainless steel front, control panel, front top ledge, backsplash
and grease trough.
Stainless steel 6" adjustable legs.
Sides finished in black epoxy powder coat paint.
1
1 / " diameter front gas manifold.
4
Full width front grease drawer.
Heavy cast iron char-radiants and "Flame Arrestor" broiling
grates.
5 1 / " wide grates are reversible for "level" broiling or self
4
cleaning. Cast-in pitched grease trough in each grate blade
provides fat run-off and controls flare-ups.
One 14,500 BTU/hr. cast iron burner for each broiling grate.
Standing pilot ignition system.
Underburner baffling system reflects heat upwards creating a
"Cool Zone" in the grease drawer and drip pan areas.
One year limited parts and labor warranty.
OPTIONS
Round rod broiling grates - for broiling fish or chicken.
Diamond shaped broiling grates, sloped, not reversible.
1 3
16 / "w x 21"d x / " thick aluminum lift-off griddle plate.
2 4
Stainless steel side(s).
Stainless steel cabinet doors.
Stainless steel side and rear splashes.
Cap and cover manifold end(s).
Leveling bolts in place of legs for curb mounting.
Stainless steel dolly frame with casters, up to 72" wide.
3 / " rear gas connection (includes gas pressure regulator.)
4
Common stainless steel front top ledge up to 96" wide.
(Drawing required showing the position of each piece of
equipment.)
ACCESSORIES
Set of four 5" diameter casters, two locking.
26 1 / " or 37 3 / " high stainless steel back riser. (Common back
2 4
risers available up to 72" wide.)
Flexible gas hose with quick disconnect and restraining
device. Consult price book for available sizes.
C.S.I. Section 11420
Left Right
Left Right
