- Page 1 INSTALLATION & OPERATION MANUAL MG24CB MEDIUM DUTY GAS CHARBROILER COUNTERTOP MODEL MODEL MG24CB ML-114634 V U L C A N - H A R T C O M P A N Y , P . O . B O X 6 9 6 , L O U I S V I L L E , K Y 4 0 2 0 1 - 0 6 9 6 , TEL.
- Page 2 CAUSE PROPERTY DAMAGE, INJURY OR DEATH. READ THE INSTALLATION, OPERATING AND MAINTENANCE INSTRUCTIONS THOROUGHLY BEFORE INSTALLING OR SERVICING THIS EQUIPMENT. IN THE EVENT OF A POWER FAILURE, DO NOT ATTEMPT TO OPERATE THIS DEVICE. — 2 — © VULCAN-HART COMPANY, 1997...
-
Page 3: Table Of Contents
TABLE OF CONTENTS GENERAL............... 4 INSTALLATION . -
Page 4: General
Installation, Operation and Care of MODEL MG24CB MEDIUM DUTY GAS CHARBROILER COUNTERTOP MODEL PLEASE KEEP THIS MANUAL FOR FUTURE USE GENERAL Vulcan charbroilers are produced with quality workmanship and material. Proper installation, usage and maintenance of your charbroiler will result in many years of satisfactory performance. It is suggested that you thoroughly read this entire manual and carefully follow all of the instructions provided. -
Page 5: Installation Codes And Standards
When installed, minimum clearance from combustible construction must be 6" at the sides and 6" at the rear; minimum clearance from non-combustible construction must be 0" at the sides and 4" at the rear. The installation location must allow adequate clearances for servicing and proper operation. A minimum front clearance of 32"... - Page 6 Fig. 1 Fig. 2 — 6 —...
-
Page 7: Leveling
LEVELING Place a carpenter's level on top of the charbroiler. Level the charbroiler front to back and side to side by turning the adjustment screw at the bottom of each leg. GAS CONNECTIONS Gas supply connections and any pipe joint compound must be resistant to the action of propane gases. Location of the gas inlet is at the rear on the left side. -
Page 8: Operation
OPERATION WARNING: THE CHARBROILER AND ITS PARTS ARE HOT. USE CARE WHEN OPERATING, CLEANING OR SERVICING THE CHARBROILER. CONTROLS Manual gas valves regulate gas flow to the burners to maintain set temperature. BEFORE FIRST USE Clean the protective metal oils from all surfaces of the charbroiler. Use a non-corrosive, grease dissolving commercial cleaner, following manufacturer's directions. -
Page 9: Turning The Charbroiler On
TURNING THE CHARBROILER ON All burners are lit from constantly burning pilots. Turn gas valve control knobs to HI to ignite the burners. TURNING THE CHARBROILER OFF Turn gas valve control knobs to OFF. Extended Shutdown Turn gas valve control knobs to OFF. Turn the manual shutoff valve to OFF. Shut off the pilot flame by removing the pilot adjustment cap and turning the adjusting screw on the pilot shutoff valve (Fig. -
Page 10: Cleaning
CLEANING At least once a day, remove the grease pan, empty and wash it out in the same way you would any cooking utensil. "Burn off" the grease build-up on the grate daily or as dictated by use. Always use insulated gloves when handling grates or radiants to prevent burns. -
Page 11: Maintenance
To obtain service and parts information concerning this charbroiler, contact the Vulcan-Hart Service Agency in your area (refer to listing supplied with the charbroiler), or Vulcan-Hart Company Service Department at the address or phone number shown on the front cover of this manual. - Page 12 — 12 —...
