- Page 1 Card Collector bollard User Manual Applicable Models: TSP-4 series Version: 1.0 Date: September. 2021...
-
Page 2: Chapter 1 Application
When used in ZKTeco’s access control systems, the data is transferred via Wiegand interface from built-in reader of the card capture reader to the ZKTeco’s ACCESS-controller. The ability to operate the card reader is supported by the C3-200 and InBi0-260 controllers. -
Page 3: Chapter 2 Operation Conditions
Chapter 2 Operation Conditions The card capture reader with regard to resistance to environmental exposure.Operation of the card capture reader is allowed at an ambient air temperature from -28°C to +60°C and relative air humidity up to 85% at 27°C. -
Page 4: Chapter 3 Technical Specifications
Chapter 3 Technical Specifications Model card collecting machine Input voltage DC 24V Working temperature（℃） -28~60 Working humidity 5% ~ 85% Working environment indoor and outdoor(shelter) Mean lifetime 3 years Dimensions(mm) 88.39×125.50×58.40 Card container capacity 500 cards Weight(Net） Max. 15 kg Attention! This model of the card capture reader is not equipped with a built-in card reader. -
Page 6: Chapter 4 Delivery Set
Chapter 4 Delivery Set 4.1 Standard delivery set Main equipment: Card capture reader:-------------------------------------------------------------------------------1 Container lock key: --------------------------------------------------------------------------------2 Package: Carton: -----------------------------------------------------------------------------------------------1 4.2 Optional equipment supplied on request Fixing screw: ---------------------------------------------------------------------------------------4... -
Page 7: Chapter 5 Product Description
Chapter 5 Product Description 5.1 Main features External elements of the card capture reader (panels) are made of polished stainless steel. Card reader (purchased separately) is mounted under the cover of the card capture reader on a special bracket. - Page 8 J2 - connection with electromagnet to control capture collector work. J4 - indication control inputs that permit the passage of the card capture reader. J5 - connector with NO-COM interface for wiring from the ACCESS-controller. J6 - connector with turnstile NC-COM-NO, output open signal to turnstile J7- connect the card holder sensor to ensure that the card really enters the card box.
