Page 1: Table Of Contents
N120/N100 0.36x Wide Angle Conversion Port Compact with Intergrated Float Collar and Interchangable Port Mounting Ring PN 85206 User Manual Underwater Optics Introduction Package Contents Important Instructions Part Names Interchangeable Port Mounting Ring WACP-1B to Adaptor/Extension Ring Specifications Care/Storage Warranty June, 2023... -
Page 2: Introduction
PACKAGE CONTENTS Make sure that you have all the included items listed below before using this product. If some items are missing or damaged, contact your local Nauticam dealer. WACP-1B N100 Mounting Ring... -
Page 3: Important Instructions
IMPORTANT INSTRUCTIONS Water-tight test of the housing (without Do not use any kind of abrasive solution to camera inside) along with WACP-1B be- clean the glass surfaces. fore usage is recommended. Do not expose the housing in direct Do not point of the lens directly towards sunlight for a prolonged period. -
Page 4: Part Names
PART NAMES Top & Rear View Lens mount index mark Bayonet Mount N120 Mounting Ring N100 Mounting Ring... -
Page 5: Interchangeable Port Mounting Ring
* drawings as illustrations only N100 N120 first remove the o-ring from N120 mounting ring remove the six screws from WACP-1B body take out the N120 mounting ring replace with the N100 mounting ring and screw back the six screws onto WACP-1B body... -
Page 6: Wacp-1B To Adaptor/Extension Ring
‘O’ index on the adaptor / extension extension ring installation.) ring. Align the ‘O’ index on the WACP-1B with the ‘I’ index on the adaptor/extension ring, and gently push the adaptor/ extension ring towards the WACP-1B until it cannot go... -
Page 7: Specifications
SPECIFICATIONS 85206 WACP-1B Outer diameter x Length DIA 194mm×174mm Weight in air 3.7 kg Buoyancy in water Negative 0.01 kg Body construction Hard-anodized aluminum alloy Lens construction 6 elements in 5 groups Lens coating Anti-reflection coating on both sides Focal range... -
Page 8: Care/Storage
O-ring should be discarded immediately (e.g. by sand) (Dry and clean the dome sur- and replaced only with one that is provided face with a microfiber cloth. / Do not use by NAUTICAM. any kind of abrasive solutions to clean the dome surface.) -
Page 9: Warranty
NAUTICAM accepts no liability for any damage to and defects in the housing caused by improper use and/ or poor maintenance; it is the responsibility of the owner to carefully follow the instructions in our manuals. - Page 10 Nauticam Internationl Ltd. Rm 2203, CCT Telecom Bldg, 11 Wo Shing St, Fo Tan, Hong Kong Tel. +852 - 26902711 Fax. +852 - 26909778 URL. www.nauticam.com Gallery. www.nauticam.smugmug.com...
