INSTRUCTION MANUAL
Nauticam Macro Port and Zoom Gear
Set for Olympus 12-50mm EZ
PN# 36167
FORWORD
Thank you for your purchase of a NAUTICAM
product.
At NAUTICAM, we pride ourselves in the ability to
recognize the requirements of professional as well
as amateur underwater photographers and fulfill
them through the innovative designs of our
products. We strive to achieve a high level of user-
friendliness by allowing stress-free installation and
easy operation of all important functions of the
camera.
Each product is individually inspected and water
pressure tested to ensure optimum quality.
Please read this manual carefully before using the
product, this will maximize its performance as well
as its lifetime.

Advertisement

loading
Need help?

Need help?

Do you have a question about the 36167 and is the answer not in the manual?

Questions and answers

Related Manuals for Nauticam 36167

Summary of Contents for Nauticam 36167

  • Page 1 PN# 36167 FORWORD Thank you for your purchase of a NAUTICAM product. At NAUTICAM, we pride ourselves in the ability to recognize the requirements of professional as well as amateur underwater photographers and fulfill them through the innovative designs of our products.
  • Page 2 Protect the interior from moisture with and/or placed within our products. and debris in order to prevent malfunction or NAUTICAM accepts no liability for any loss of leakage. captured images or the inability to capture images even if it is due to the malfunctioning of our •...

  • Page 3: Package Contents

    PACKAGE CONTENTS • Make sure that you have all the included items listed below before using this product. • If some items are missing or damaged, please reach out to us or the local Nauticam dealer. Macro Port Zoom Gear Set...
  • Page 4 IDENTIFICATION OF ZOOM GEAR PARTS Two half-rings - Zoom Gear Zoom gear tube - Zoom Gear Spring ring - Zoom Gear Zoom gear ring - Zoom Gear Macro Switch Block - Zoom Gear Macro switch gear Locking ring - Macro switch Gear Positioning Block x3 Screw x11 - Macro Switch Gear...
  • Page 5 IDENTIFICATION OF PORT PARTS Cold shoe Rear port cap Macro Port with M77 thread for Olympus M.Zuiko Digital ED 12-50mm F3.5-6.3 EZ Plastic port cap Control knob Spare O-ring...
  • Page 6 MOUNT GEARS ON LENS 1. Mount the two half-rings on the lens zoom ring as indicated in the diagram. 2. Align the alignment index on the ring with the dot on the lens before tightening four screws. While tightening the screws, make sure that the gaps on both sides are even and the ring does not slip when turning at E- ZOOM mode.
  • Page 7 MOUNT GEARS ON LENS 4. Align the spring ring with the lens as indicated in the diagram. Then lightly push the ring towards the lens until it cannot go any further. Tip: To remove, pull out from the cover. 5. Align the pins on the tube with the holes in the gear ring as indicated in the diagram.
  • Page 8 MOUNT GEARS ON LENS 7. Align the inner groove of the macro switch gear with the white dot on the zoom gear tube. Then lightly push the gear towards the lens until it cannot go any further. 8. Tighten the macro switch gear by screwing the locking ring into the thread on the front of the lens.
  • Page 9 INSTALL PORT TO HOUSING 1. Make sure the control knob is at its most outwards position before mounting/ un-mounting the port. The knob should be left at this position until making sure that the lens and zoom gear is properly installed. 2.

  • Page 10: Specifications

    SPECIFICATIONS CARE AND MAINTENANCE #36167 Macro Port and Zoom Gear Set for • Soak the housing system in fresh water after Olympus 12-50mm EZ each use, during which all control buttons/knobs should be operated a few times to avoid the Gear part: DIA102mm ×...
