Overview
WARNING!
Read all warnings, cautions, notes and installation instructions before installing or servicing this
equipment.
The SDG-8622 is a carrier-class, dual-band, WiFi 6 Mesh AP designed to deliver top-end WiFi 6 performance, multi-gigabit wired
and wireless throughput, and advanced service delivery capabilities.
Figure 1: SDG-8622 WiFi 6 Mesh AP
WARNING!
A warning indicates a hazard that, if not avoided, could result in death, injury, or serious property damage.
CAUTION!
A caution indicates a hazard that, if not avoided, could result in service interruption, damage to the
equipment, or minor property damage.
NOTE
A note highlights additional, but important, information or features.
SDG-8622 -Quick Start Guide - Issue: A
Service Delivery Gateway
WiFi 6 Mesh AP
January 2024
6SDG8622-13A
P/N:17600072F1S, 17600072F2S, 17600072F3S, 17600072F4S
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for ADTRAN 17600072F1S
Summary of Contents for ADTRAN 17600072F1S
- Page 1 WiFi 6 Mesh AP January 2024 6SDG8622-13A P/N:17600072F1S, 17600072F2S, 17600072F3S, 17600072F4S Overview WARNING! Read all warnings, cautions, notes and installation instructions before installing or servicing this equipment. The SDG-8622 is a carrier-class, dual-band, WiFi 6 Mesh AP designed to deliver top-end WiFi 6 performance, multi-gigabit wired and wireless throughput, and advanced service delivery capabilities.
- Page 2 Prior to Installation Before installing the equipment, inspect the device. If damage has occurred during shipping, file a claim with the carrier, and then contact Adtran Customer Support. For more information, refer to the product warranty available online at https://adtran/wp_support_warranty.
- Page 3 Adtran Supplying Power to the device Desktop Installation The SDG-8622 can be placed on a desk or table. Table 1 shows the recommended minimum distance (in feet and meters) between the device and household appliances to reduce interference. Table 1: Recommended Minimum Distance Between the SDG and Household Appliances...
-
Page 4: Understanding The Status Leds
Adtran Subscriber Connections 1. Connect the USB-C end of the power adapter to the USB-C Power In Port on the bottom of the device. 2. Plug the other end of the power adapter into the wall outlet. 3. The SDG will begin powering up immediately as the SDG-8622 has no on/off power switch. - Page 5 Adtran Multifunction Status LED Color LED State Event Purple Pulsing Satellite Set Up White Solid Satellite up Pulsing Satellite up, fair signal Amber Pulsing Satellite up, poor signal White Pulsing Reverting Multifunction Status LED The multifunction status LED on the front of the unit indicates the device status.
-
Page 6: Product Specifications
Adtran Using SmartOS Quick Setup for the SDG-8622 For devices with SmartOS installed, scan the QR code labeled WiFi QuickStart located on the back of the unit. You will be presented with a series of self-guided steps to choose your account password, select gateway or access point mode, and configure the Wi-Fi SSID and passphrase. -
Page 7: Safety And Regulatory
Transportation Temperature: -40°F to 158°F (-40°C to 70°C) any humidity Operating Humidity: 5 to 85 percent, non-condensing NOTE Changes or modifications not expressly approved by Adtran will void the warranty. Compliance This product meets the following compliance requirements: ... - Page 8 This equipment contains no parts that can be serviced by the user. This product meets EU RoHS Directive. Refer to www.adtran.com/environmental for further information on RoHS/WEEE. This product is NRTL Safety Listed to the applicable UL/CSA Standards.
-
Page 9: Can Ices-3(B)/Nmb-3(B)
Adtran FCC Requirements for Operation in the United States FCC Requirements for Operation in the United States FCC Information to User This product does not contain any user serviceable components and is to be used with approved antennas only. Any product changes or modifications will invalidate all applicable regulatory certifications and approvals. - Page 10 Adtran Industry Canada CAUTION! Radiation Exposure Statement: This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. This radio transmitter (IC: 2250A-17600072) has been approved by Industry Canada to operate with the antenna types listed below.
- Page 11 For Adtran training inquiries, visit: https://adtran.com/training http://adtran.com/sdg-info Adtran Customer Care: Warranty: Adtran will replace or repair this product within the warranty period if it does not meet its From within the U.S. published specifications or fails while in service. 1.888.423.8726 Warranty information can be found online at From outside the U.S.
