TOTAL ACCESS 234 SHDSL NTU
Quick Start Guide
ET
C C I
ONNECT THE ONSOLE NTERFACE
Before connecting to the Total Access 234 console interface, you will need the following items: VT100
terminal or PC (with VT100 terminal emulation software) and a straight through serial cable with a DB-9
(male) connector on one end and the appropriate interface for your terminal (or PC) on the other.
1. Connect the DB-9 (male) connector of your serial cable to the console port on the rear
panel of the unit.
2. Connect the loose end of the serial cable to the VT100 terminal or PC (with terminal
emulation software).
3. Open a VT100 terminal session to the Total Access 234 using the following settings:
9600 baud, 8 data bits, no parity bits, and 1 stop bit. Press <Enter> to activate the
ADTRAN Command Line Interface (CLI).
S
PECIFICATIONS
DC Input Power 12 VDC nominal (8.5 VDC min, 18 VDC max); ITU-T standards: G.991.2
Diagnostics & Test Self-diagnosis; local loopback; remote loopback
EMC Emissions EN55022:1998 Class B; FCC Part 15 Class B
EMC Immunity, Power EN55024:1998; EN61000-3-2; EN61000-3-3; Telstra 1563; K.21 (2004)
Fault, and Lightning Enhanced
Electrical Safety EN60950; AS/NZS 60950; UL60950 3rd ed.;
CSA C22.2 No. 60950 3rd ed.; IEC 60950 CB Scheme
Telecom S043.2; G.991.2
Environmental
Operating Temp: 0
*Note:
No stacking should be done at 50
Humidity: 95 percent noncondensing
Dimensions 9.3 inches W x 2.1 inches H x 6.1 inches D
Connectors SHDSL Port: RJ-45; 135 ohms; TNV-3 rated
10/100BaseT Ethernet: RJ-45
Console Port: DB-9 female
Power Input: Kycon KPJ-3S snap & lock or equivalent
Quick Start Guide, 61200708L1-13B, January 2005
ETH
o o
C to 50 C; Storage Temp: -20
o
C. Up to three units can be stacked at room temperature.
Technical Support 1-888-4ADTRAN or +1-256-963-8716
For more detailed documentation, visit us online at
C
ONFIGURE
Configure the Gateway IP addresses and subnet mask by following
these steps. If you are not sure what IP address to assign, please
contact your network administrator.
1. Enter enable to activate the Enable command security mode.
2. When prompted, enter the enable password (if configured).
3. Enter config terminal to activate the Global configuration mode.
4. Enter bre lan-gw 10.26.12.12 wan-gw 100.26.12.12 mask
255.255.255.0* to assign LAN and WAN Gateway IP addresses
and subnet mask.
*Note: Underlined text represents example entries only. Modify
them to match your configuration.
5. Enter exit to return to the Enable configuration mode.
6. Enter copy running-config startup-config to save the running
configuration to the unit's non-volatile memory (NVRAM).
F
EATURES
• One integrated EIA-232 configuration port (DCE)
• One integrated 10/100BaseT Ethernet port
• 2-Wire/4-Wire SHDSL interface
• WAN Protocol: ATM
• Command Line Interface (CLI)
o o
C to 70 C
• Management - EOC/CLI using Virtual Terminal
• Front panel LEDs
• Wall mounting available with additional parts
G IP A /S
ATEWAY DDRESSES UBNET
Table standoff cannot be used with this unit.
Copyright © 2005 ADTRAN, All Rights Reserved
www.adtran.com
P/N 1200708L1
M
ASK
