Summary of Contents for MobileDemand xTablet T1175
- Page 1 User Manual xTablet T1175 1501 Boyson Square Drive – Suite 101 Hiawatha, Iowa 52233 | PH: 319.363.4121 | RuggedTabletPC.com...
-
Page 2: Table Of Contents
T1110 Contents Copyright and Trademark Notice User Manual FCC Information xTablet T1175 IC Statements Safety Instructions Introduction Product Overview Specifications Power Supply Battery... -
Page 3: Xtablet T1175
T1175 Copyright and Trademarks Notice All marks and names mentioned may be trademarks of their respective owners. No warranty as to accuracy or completeness is expressed or implied. We reserve the right to make changes to this document without prior notice. - Page 4 T1175 FCC-B Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installa- tion.
- Page 5 This equipment complies with Industry Canada radiation exposure limits set forth for an uncontrolled environment. End user must follow the specific operating instructions for satisfying RF exposure compliance. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. The device is designed to meet the requirements for exposure to radio waves established by the Industry Canada.
-
Page 6: Safety Instructions
T1175 Safety Instructions Read the safety instructions carefully and thoroughly. All cautions and warnings on the equipment or user’s manual should be noted. Keep this equipment away from humidity and high temperature. The openings on the enclosure are used for air convection to prevent the equipment from overheating. - Page 7 Place the power cord in a way that people are unlikely to step on it. Do not place anything on top of the power cord. Always keep strong magnetics or electrical objects away from the tablet. To avoid damage or electrical shock never pour liquid into any opening. If any of the following situations arise, have the equipment checked by a service personnel: •...
-
Page 8: Introduction
Unpacking Unpack the shipping carton and check all items carefully. If any item is damaged or missing contact MobileDemand. Please keep the box and packing materials in the event you need to ship the unit. The package should contain the following items: •... -
Page 9: Product Overview
Product Overview Front View Front Camera Internal Microphone Status LEDS Power Battery Status • Green OFF: Power off /Hibernation • OFF: Battery is not charging • Green ON: Power on • Green ON: Battery is fully charged • Breathing Green: Standby /Sleep •... - Page 10 T1175 Top View Barcode Scanner (optional) Power Button ► Before powering on the tablet PC for the very first time, you must connect it with AC power. ► Press and hold the power button for 2 seconds to power on the tablet PC.
- Page 11 Left Side View USB 3.1 Gen 2 Port (with DisplayPort function) USB 3.1 Gen 2, the SuperSpeed USB 10Gbps, supports high-speed data transfer for the connected devices, such as storage devices, hard drives, or video cameras. The DisplayPort function supports external display connection. USB 3.1 Gen 2 Port USB 3.1 Gen 2, the SuperSpeed USB 10Gbps, supports high-speed data transfer for the connected devices, such as storage devices, hard drives, or video cameras.
- Page 12 T1175 Back View F1 Button - Barcode Scanner Trigger Battery Latch This built-in rear camera can be used for photos, video recording, conferencing, and other interactive applications. Micro SD Card Slot To access remove battery. Nano Sim Card Slot To access remove battery.
-
Page 13: Specifications
Specifications The specifications listed here are for reference only, and may change without notice. DIMENSIONS 11.54 in. L x 7.56 in. H x .67 in. D I/O PORTS USB 3.1 Gen1 (Type A ) 293mm L x 192mm H x 17mm D USB 3.1 Gen1 (Type C ) Weight - 1350g | 2.97lbs USB 2 Gen1 (Type C ) -
Page 14: Power Supply
AC/DC Adapter Ensure the xTablet T1175 is connected to an AC power source via the AC adapter before turning it on for the first time. If the xTablet automatically shuts down due to low battery power, it is likely to cause system failure. -
Page 15: Battery
Battery This Tablet is equipped with a built-in Lithium-ion Polymer battery pack. The rechargeable Lithium-ion Polymer battery pack is an internal power source. The battery pack may be damaged if users attempt to disassemble it. The limited warranty will be voided if the battery pack is disassembled by non-authorized technicians. - Page 16 Contact our sales team today | sales@mobiledemand.com | 319.363.4121 1501 Boyson Square Drive | Suite 101 | Hiawatha, Iowa 52233 | RuggedTabletPC.com ©2023 MobileDemand, LC | All trademarks are property of their respective owners. VERSION 12.11.23...
