CANOPY
EN
Climalux / Climalux Horizon
Mounting instructions
Art.N° 36179

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Climalux and is the answer not in the manual?

Questions and answers

Summary of Contents for SKYLUX Climalux

  • Page 1 CANOPY Climalux / Climalux Horizon Mounting instructions Art.N° 36179...
  • Page 2: Table Of Contents

    5.6 ROOF PACKAGE P. 12 5.7 POST COVERS P. 13 5.8 GLAZING EDGE PROFILE P. 13 6 MEASURING A WALL-SUPPORTED CLIMALUX ROOF P. 14 6.1 OVERVIEW ELEMENT POSITION CODE P. 14 6.2 MEASURING P. 15 MEASURING A FREESTANDING CLIMALUX ROOF P.
  • Page 3 11.3 GUTTER BEAM G1: TYPE GX P. 31 11.3.1 GX + VS: GUTTER WITH REINFORCEMENT PROFILE P. 31 11.3.2 GX + PU: INSTALLATION ON POST PX P. 32 11.3.3 GX + LT150: INSTALLATION ON POST PXLX P. 32 11.3.4 GX + LT150 (+ VTVS): INSTALLATION ON POST PXLX P. 33 11.3.5 GX: COUPLED GUTTER P.
  • Page 4: Safety

    SAFETY Take the necessary and required safety precautions, such as safety nets and lifelines when installing from the outside, safety goggles, gloves, hard hat, etc. Do not step on the glass. Falling from height • When using ladders to go on the roof: - Ladder in good condition? - Set up correctly at an angle of 75°? - Secured below and on top against moving?
  • Page 5 Sharp objects • Make sure your fingers/hands are not pinched and watch out for cuts while handling veranda parts. • Be careful where you put your hands during the installation. • Wearing cut-resistant gloves is mandatory. Ergonomics • Always lift loads correctly: bend your knees, move your feet instead of forcing your spine, lift as close to your body as possible.
  • Page 6: Guidelines

    We cannot be held responsible for possible incomplete information. Always check if our product is suited for your application. As the handling and installation of the product are done beyond our control, can Skylux not be held responsible for possible damages.
  • Page 7: Load Capacity Graphs

    We recommend removing any snow from the roof to prevent accumulation against the wall by the wind. When snow on a higher roof can slide on to the Climalux roof, measures must be taken to prevent this, for example, by using snow hooks and snow beams.
  • Page 8: Load Capacity Of Rafters In Function Of Plastic Sheets Or Glass

    4.2 Load capacity of rafters in function of plastic sheets or glass The graphs below can be used to determine the free span for the rafter DX. This is the maximum length of the rafter in function of the load and the depth (D) of your roof. The maximum bending is 1/200 (plastic sheets) or 1/300 (glass).
  • Page 9: Load Capacity Of Gutter Beams

    4.3 Load capacity of gutter beams 4.3.1 For roofs with plastic sheets The graphs below can be used to determine the free span for each type of gutter (support). This is the distance between your supports (posts) in function of the load and the depth (D) of your roof. The maximum bending is 1/200.
  • Page 10: For Roofs With Glass

    4.3.2 For roofs with glass The graphs below can be used to determine the free span for each type of gutter (beam). This is the distance (P) between your supports (posts) in function of the load and the depth (D) of your roof. The maximum bending for a construction with glass is 1/300.
  • Page 11: Overview Installation Variables

    5 OVERVIEW INSTALLATION VARIABLES 5.1 Approach of mounting instructions 1) The tables below identify the relevant part combinations in function of your roof configuration. 2) Afterwards, use the index at the beginning of this document to find the installation points with relevant instructions. 3) The parts list can help you with this.
  • Page 12: Horizontal Beams

    Post type & position Freestanding roof: PXLX PGDX founded with Statik P1.1 = P1.n P1.2 P1.1 = P1.n P1.2 P2.1 = P2.n P2.2 Element & Foundation No steel PX founded in PXLX founded in concrete PGDX founded in type anchor concrete concrete With steell...
  • Page 13: Post Covers

    Legend Quality solution Ideal solution Good solution Seals Seal below glazing Seal below glazing CY10 Seal below / above glazing Clips fix position CL16 fix position on tooth 1 CL16 fix position on tooth 2 CL16 fix position on tooth 3 Screws °...
  • Page 14: Measuring A Wall-Supported Climalux Roof

    6 MEASURING A WALL-SUPPORTED CLIMALUX ROOF 6.1 Overview element position code P1.n P1.2 P1.1 14/60 E_MH_Mounting_instructions_Skylux_Climalux_ClimaluxHorizon 27/04/2023...
  • Page 15: Measuring

    Measure horizontally from the wall to the inner side of the support post to determine the roof depth D. The additional depth of gutter GX is 160 mm, or of the gutter with ornamental frame GLX is 176 mm for a Climalux. The extra depth of the GXLX measures 180 mm.
  • Page 16 H = H M - H G h = 144 mm or 163 mm (wall profile height) Installing the Climalux post PX and PV base plate. - Determine point O 1 . - Determine O 2 . The distance O 1 - O 2 = patio roof width “B”.
  • Page 17: Measuring A Freestanding Climalux Roof

    7 MEASURING A FREESTANDING CLIMALUX ROOF 7.1 Overview element position code P2.n P2.2 P1.n P2.1 P1.2 P1.1 7.2 Detail foundation & height 7.2.1 Ridge beam H1 in lateral view Wall profile type Glass/sheet thickness 8-16 mm Sheet thickness 32 m...
  • Page 18: Gutter Beam G1 In Lateral View

    7.2.2 Gutter beam G1 in lateral view Gutter type GXLX PXLX PXLX PCLXLX PCLX 7.3 Optional ground foundation Determine the foundation dimensions. Make sure the posts will be in the middle of the foundation. min. min. 700 min. 1. Soil 2.
  • Page 19: Overview Profiles And Parts

    8 OVERVIEW PROFILES AND PARTS WALL WALL PROFILE GIXL CONNECTING PIECE FOR GXLX MX32 WALL PROFILE FOR 32 MM SHEETS CROSSBEAM FOR OVERHANG GUTTER GUTTER PROFILE GDCX COVER FOR CROSSBEAM GDX RAFTERS STEEL SHAFT 80 X 25 X 3 RAFTER ORNAMENTAL PROFILE SOFTLINE RAFTER TYPE 2 FOR GUTTER GX...
  • Page 20 GREY SEAL FOR SPACER OR SIDE CLSB BASE SCREWABLE CLIP RAFTER TOP SCREWABLE CLIP GREY SEAL FOR SPACER OR SIDE CY10 CLST FOR 8 TO 16 MM RAFTER CLSL TOP SCREWABLE CLIP GREY SEAL FOR CL16 AND CLSB ACCESSORIES POSTS POST 110/141 FOR GUTTER GX SPACER REINFORCED PVC END PROFILE...
  • Page 21 GUTTER END PIECE RIGHT “SKYLUX” L432 L-OBTURATOR PROFILE FOR GLASS GASXL FOR GXLX SYNTHETIC TAPE 10 AND 16 MM WITH GUTTER END PIECE UNIVERSAL FOR BT16 GASXL GUARANTEE GXLX PERFORATED SYNTHETIC TAPE 16 MM BB16 LOGO LOGO FOR GUTTER END PIECE...
  • Page 22 5,5 x 32 mm (TX 25) SELF-DRILLING SCREW SST U TOP-BOTTOM FOR POST PX SELF-DRILLING SCREW PAINTED SST SELF-DRILLING SCREW SST WITH SEAL 5,5 x 25 mm (TX 25) SCR.002 GALVANISED U TOP-BOTTOM FOR POST PGDX FOR FIXATIONS THROUGH STEEL 82416 PROFILES CONNECTION PROFILE...
  • Page 23 DIN 125-1A WASHER M10 PGDX POST 110/110 46673 GALVANISED 51197 COUNTERSINK Ø 16.5 MM CROSSBEAM 51819 COUNTERSINK Ø 20.5 MM C110 CONNECTING PIECE FOR VTVS REINFORCEMENT PROFILE 48111 PGDX 93874 PT110 VTPS POST SUPPORT 100 x 100 REINFORCEMENT PLATE 51817 47792 END PLATE FOR VTPS02...
  • Page 24: Preparation

    9 PREPARATION 9.1 Walls Check that the walls, against which the structure is to be installed, are: - sufficiently load-bearing to anchor the roof; - free of obstacles such as water drains, window sills, ..Cut a slot in the walls against which the patio roof will be mounted. Place a lead slab or zinc flashing profile in this slot.
  • Page 25: Assembling The Posts

    10 ASSEMBLING THE POSTS 10.1 Post type: PX 10.1.1 PX + PU + (PV): Installation on ground/gutter with bracket 253,5 (optional) 10.2 Post type: PXLX 10.2.1 PXLX + LB150: Installation on ground with bracket ZSB (x4) • Installation option 1: without water outlet LB150 LB150 23 mm...
  • Page 26: Pxlx: Foundation Without Anchor

    10.2.2 PXLX + PS02 140x30: Installation; founded on the ground PXLX + PS02 140x30 Fixed on the ground Positioning sticker art. 94600: Bottom edge of sticker & post together = the ground anchor is fully retracted. Fix the base plate on the foundation with the appropriate fixing material. PXLX DIN 933 M10x20 PS02 140x30...
  • Page 27: Pxlx + Pclx / Pclxlx: Post Cover Options

    10.2.4 PXLX + LB150 (+ C72): Installation on gutter with bracket (+ side beam P72 in case of bracket C72) PXLX Installation gutter (GX / GXLX) Installation gutter (GX / GXLX ) & fixation post (P72+C72) P1.1 = P1.2 = P1.n P1.1 P1.1 PXLX + LB150...
  • Page 28: Post Type

    10.3 Post type: PGDX 10.3.1 PGDX + PUX + (PV): Installation ground & GDX PGDX Wall-supported roof with overhang Freestanding roof Ground fixation GDX fixation GDX fixation P1.1 = P1.n P1.2 P1.1 = P1.2 = P1.n P2.2 (not P1.1 & P1.n) PGDX + PUX + PV PGDX + PUX (+PV) PGDX + PUX + GDX...
  • Page 29: Pgdx: Foundation Without Anchor

    10.3.3 PGDX: Foundation without anchor - Install the post at least 400 mm deep into a concrete foundation. - Slide 2 threaded rods M10 through the founded part of the post. Perpendicular to each other. Drill 4 holes & let the rods protrude 10 cm in each direction. - Close the openings in the post below the foundation level with tape art.
  • Page 30: Assembling The Horizontal Beams

    11 ASSEMBLING THE HORIZONTAL BEAMS 11.1 Wall-supported back profile for glazing up to 16 mm for sheets 32 mm 39,5 39,5 C1CX C4CX MX32 98° 98° 11.1.1 Preparation A lead flashing is recommended for a waterproof junction to the wall. Cut a slot in the wall against which the patio roof will be mounted.
  • Page 31: Side Beams W1 & Wn: Type P72

    11.2 Side beams W1 & Wn: Type P72 11.2.1 P72 + PU: Side beam standard version Slots can be provided in the top side of P72 if it is not visible, to slide the P72 over the PU brackets that are already fixed on an already existing structure.
  • Page 32: Gx + Pu: Installation On Post Px

    11.3.2 GX + PU: Installation on post PX - Cut out the opening for the water outlet. Use a hole saw Ø 80 mm (not included in delivery). - Use the delivered post gauge for a perfect position of the post bracket. - If the reinforcement profile is used, you need to use the self-drilling screws 6.3 x 25 mm.
  • Page 33: Gx + Lt150 (+ Vtvs): Installation On Post Pxlx

    DIN 933 M10 x 20 DIN 6798 A M10 PXLX PXLX 11.3.4 GX + LT150 (+ VTVS): Installation on post PXLX P1.1 & P1.n P1.2 (VS) VTVS DIN 933 M10x20 DIN 933 M10x20 DIN 912 DIN 125 M10 DIN 125 M10 M8x16 LT150 LT150...
  • Page 34: Gx: Coupled Gutter

    11.3.5 GX + GX: Coupled gutter Multiple gutter elements can be connected to each other for gutter lengths > 7 m. A gutter support must be installed at every gutter connection point. The gutter profiles can be linked using connection pins 909 and the connector profile GIX. Use silicone SG20 as sealant. GX + GIX + 909 (4x) GLX + 909 (2x) 11.3.6 GX + GLX / GR: Gutter with cover...
  • Page 35: Gutter Beam G1: Type Gxlx

    11.4 Gutter beam G1: Type GXLX 11.4.1 GXLX + V1243: Gutter with reinforcement profile V1243 GXLX PT150 52,58 11.4.2 GXLX + LT150 + PT150: Installation on post PXLX - Cut out the opening for the water outlet. Use a hole saw Ø 80 mm (not included in delivery). Place the drill head in the groove.
  • Page 36: Gxlx: Coupled Gutters

    Installation gutter type GXLX P1.1/ P1.2 / P1.n GXLX V1243 DIN 933 M10x20 DIN 912 DIN 125 M10 M8x16 LT150 11.4.3 GXLX + GXLX: Coupled gutters - Multiple gutter elements can be connected to each other for gutter lengths > 7 m. A gutter support must be installed at every gutter connection point - Slide the reinforcement profile into the gutter.
  • Page 37 GXLX GXLX Ø 11 VGXLX DIN 6798 A M10 GXLX DIN 933 M10x20 PT150 LT150 DIN 6798 A M8 GXLX DIN 912 M8x16 DIN 6798 A M10 DIN 933 M10x20 GXLX GXLX DIN 6798 A M8 DIN 912 M8x16 GXLX GIXL GXLX 37/60...
  • Page 38: Ridge Beam H1 & Roof Overhang Beam O1

    11.5 Ridge beam H1 & roof overhang beam O1 11.5.1 GDX + IP140 / V14105: Beam with reinforcement profile - Fastening a reinforcement profile in the GDX (below and above) has a positive influence on the overall strength. - These profiles can be purchased at a local steel merchant. - We recommend to treat the steel reinforcement profile against corrosion.
  • Page 39: Overhang Beam O1: Gdx

    11.5.3 Overhang beam O1: GDX - See chapter 11 roof package: roof with overhang 11.5.4 GDX + PUX: Installation on PGDX ZSB (4x) 11.5.5 GDX: Installation on PGDX + C110 P2.1 & P2.n P2.2 Bottom side Drill pattern = sticker 49563 Top side Drill pattern = sticker 94593 P2.1...
  • Page 40: The Connection Of 2 Supports Is Supported By The Post

    P2.1 & P2.n P2.2 DIN 7991 M10x180 DIN 933 M10x30 PT110 DIN 125 M10 P2.2 P2.1 / P2.n 11.5.6 The connection of 2 supports is supported by the post 40/60 E_MH_Mounting_instructions_Skylux_Climalux_ClimaluxHorizon 27/04/2023...
  • Page 41 Drill 2 x 2 holes Ø 14 mm in the bottom side at 35 mm from the edge. Also drill 2 x 2 holes Ø 11 mm at 250 and 465 mm from the edge. Use a countersink 90° Ø 20.5 mm to make the hole conical. Ø...
  • Page 42: Gdx: Cover Profile

    Slide the connection profile UPN140 in the support lide the second support over the connection profile until it until the drill hole matches the opening in the reaches the first support. Put 2 bolts M10 x 180 in the holes support.
  • Page 43: Preparation Of The Frame

    12 PREPARATION OF THE FRAME 12.1 Overview R2, R3, ... 12.2 Installation W1 & Wn 12.2.1 W1 / Wn with C72 brackets W1 / Wn with C72 brackets P2.1 & P2.n P1.1 P1.n P1.1 + W1 DIN 7991 M10x120 DIN 933 M10x60 DIN 125 M10 43/60 27/04/2023...
  • Page 44: Installation R1 + R2 + Rn

    12.3 Installation R1 + R2 + Rn - See chapter 13: “Assembling the roof package” 12.3.1 Outlining the structure 1. Check the perpendicularity (squareness) of the structure with the spirit level. 2. Also check if the diagonals are equal. 3. Fix the entire structure firmly in its current position. 4.
  • Page 45: Assembling The Roof Package

    13 ASSEMBLING THE ROOF PACKAGE 13.1 Parts The rafters are pre-cut on the wall and gutter side. Check the rafter length in function of the glazing + snow & wind load (see graphs chapter 4). Or by using Climafast, the free calculation programme for professionals. Rafter DX + C3 (or CY10) α...
  • Page 46: Installation Of The Rafters

    General: The number of rafters and their position must be determined in function of the glazing and the load. Check the axis distance in relation to the depth of the patio roof (D) and the load (glazing + snow and wind). Check the graphs (chapter 4).
  • Page 47: Version 2: Gutter Gxlx

    13.4.2 Version 2: gutter GXLX ZSC (2x) 13.4.3 Versie 3: roof with overhang ZSC (2x) LGDX ZSG (1x) ZSG (1x) LGDX ZSC (2x) ZSG (3x) 47/60 27/04/2023 E_MH_Mounting_instructions_Skylux_Climalux_ClimaluxHorizon...
  • Page 48: Spacers

    13.4.4 Spacers Spacers 8-11 & 16mm CY10 8 & 9 mm CY10 C3 (CY10) CLICK C3 (CY10) CLICK 13.5 Finish 13.5.1 Wall profile Use 2 ZSG screws to screw the end plate MSX on the rafter DX on the freestanding sides of the wall profile. Fasten the MSX only after the complete roof installation is finished.
  • Page 49: Options

    14 OPTIONS 14.1 Lighting 14.1.1 Lighting components in wall profile or gutter All electrical operations must be performed by a professional and in accordance with the applicable local regulations for electric installations. ClimaLED spots: see separate mounting instructions Installation of the ClimaLED strips on the gutter GX: The installation and electric wiring must be carried out in accordance with the instructions below.
  • Page 50: Glazing

    The guidelines regarding the placement is only of an advisory nature. They are for informational purposes only. The installation is under the sole responsibility of the customer. THE RESPONSIBILITY OF THE PUBLISHER IS EXPRESSLY DISCLAIMED REGARDING THE PLACEMENT. PERGOLUX - SKYLUX - CLIMAX - CLIMALITE - REFLEX PEARL - RELAX - PRIMALITE - POLYCLEAR ARE REGISTERED BRANDS OF SKYLUX 50/60...
  • Page 51 Relax - PMMA: S5P Heatstop) or move during sawing. The saw blade colour differences. this. An appropriate seal is recom- install a Skylux conservatory skylight. must slightly protrude from the sheet. - For glass: see Pergolux Glass series mended. 51/60...
  • Page 52: Finish

    15.1.2 Finish The maximum thickness of the plastic sheets is 16 mm or 32 mm. Only the left and/or the right sheet are cut to size in width. Take into account a lateral clearance of 5 mm on each side (p. 48). Provide the appropriate tape for the open ends (whole tape BT on the top side = wall side and perforated tape BB on the bottom = gutter side).
  • Page 53: Seals & Water Drainage

    16 SEALS & WATER DRAINAGE 16.1 Extra seals for glass roof with slope of 2° to 5° 16.1.1 Grey foam adhesive tape Stick the tape on the back of the back profile. VTBANDV 94664 16.1.2 Black rubber adhesive tape 16.1.2.1 Strips on the back profile Stick the tape on the inclined surface of the back profile, between the straight edges of the glass-bearing DX profiles and neatly next to it.
  • Page 54: Glass Sheet Preparation

    16.1.3 Glass sheet preparation - Measure & demarcate so the PVC profile is fixed precisely on the cetre of the glass sheet. - Firmly fix the profile on the glass edge: • Art. 94567 = black PVC profile for 8 & 10 mm glass (if necessary, use a bit of lubricant for the installation on 10 mm glass if the glass edge is not chamfered).
  • Page 55: Screw-On Glass Covers

    16.2 Screw-on glass covers For plastic sheets (Pergotop/Pergotop-Soft sandwich panels only suited for installation with Skylux screw-on clips) or glass: possibilities and glass thicknesses can be found in the table on page 12. CLSL CLST CLST CLSB CLSB 8-9 mm...
  • Page 56: Clip-On Glass Covers

    16.3 Clip-on glass covers Clip fixation Sheet thickness Middle rafters (R2) Side rafters (R1 & Rn) Seals CL16 CL32 CLLX Glass 44.2 (8 - 9 mm) Fix position 1 Fix position 1 Glass 55.2 (10 - 11 mm) Fix position 2 Fix position 2 Plastic 16 mm Fix position 3...
  • Page 57: Side Rafters (R1 & Rn): Finish

    16.3.3 Side rafters (R1 & Rn): finish Saw the CLLX/CLSL profile diagonally on the wall side according to the roof slope. Measure the distance to the stop profile to determine the length of the CLLX/CLSL profile. Position the CLLX/CLSL profile on the outside against the rafter profile and push it with your hands or with a rubber hammer and a small wooden board.
  • Page 58 58/60 E_MH_Mounting_instructions_Skylux_Climalux_ClimaluxHorizon 27/04/2023...
  • Page 59 59/60 27/04/2023 E_MH_Mounting_instructions_Skylux_Climalux_ClimaluxHorizon...
  • Page 60 ONLY USE ORIGINAL PARTS SUPPLIED BY SKYLUX. FAILURE TO USE ORIGINAL PARTS VOIDS THE GUARANTEE. THESE GUIDELINES ONLY SERVE AS ADVICE AND INFORMATION. INSTALLATION IS CONDUCTED UNDER THE SOLE RESPONSIBILITY OF THE CUSTOMER. CLIMALUX / CLIMALUX HORIZON IS A REGISTERED BRAND OF SKYLUX...
