CANOPY
EN
Climaglide
®
Mounting instructions carrier system - 10 mm
Art.N° 80574

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Climaglide and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SKYLUX Climaglide

Summary of Contents for SKYLUX Climaglide

  • Page 1 CANOPY Climaglide ® Mounting instructions carrier system - 10 mm Art.N° 80574...

  • Page 2: Safety

    Safety Take the necessary and required safety precautions, such as safety nets and lifelines when installing from the outside, safety goggles, gloves, hard hat, etc. Do not step on the glass. Falling from height • When using ladders to go on the roof: - Ladder in good condition? - Set up correctly at an angle of 75°? - Secured below and on top against moving?
  • Page 3 Sharp objects • Make sure your fingers/hands are not pinched and watch out for cuts while handling veranda parts. • Be careful where you put your hands during the installation. • Wearing cut-resistant gloves is mandatory. Ergonomics • Always lift loads correctly: bend your knees, move your feet instead of forcing your spine, lift as close to your body as possible.

  • Page 4: Table Of Contents

    Contents SAFETY p. 2 OVERVIEW PROFILES AND PARTS p. 5 DRAWING p. 6 USE AND VERSIONS p. 7 GENERAL INSTALLATION TIPS p. 8 MEASURING YOUR GLASS SLIDING PARTITION p. 9 GLASS PLATES SIZES p. 10 SPECIFIC INSTALLATION TIPS p. 11 - 16 UPPER RAIL p.

  • Page 5: Overview Profiles And Parts

    Overview profiles and parts Upper rail for 3 glass Latch block CGT310 CGBL panels Upper rail for 4 glass End piece CGT410 CGPLS10 panels Upper rail for 5 glass Lock CGT510 CGPLL10 panels Bottom rail for 3 glass CGB3 panels Bottom rail for 4 glass Side profile with sliding CGB4...

  • Page 6: Drawing

    Drawing CGT Upper rail CGL10 side profile CGSH sliding lock CGPL carrier profile CGB bottom rail B1 = Upper rail (page 11) B2 = Side profile with sliding lock (page 12) B3 = Side profile (page 12) B4 = Bottom rail (page 13) B5 = Sliding element (page 14 –...

  • Page 7: Use And Versions

    The version of your Climaglide glass sliding partition is determined by a code CG XYY L/R D: Example: CG 303 L 10 is a Climaglide glass sliding partition with 3 tracks and 3 sliding elements that open to the left (seen from the inside out). It is equipped with a glass thickness of 10 mm.

  • Page 8: General Installation Tips

    Since our product is processed and assembled outside of our supervision, any damage cannot be attributed to Skylux. The fitter must bear in mind the specified dimensions of the glazing and the wind load in accordance with applicable standards.

  • Page 9: Measuring Your Glass Sliding Partition

    Measuring your Climaglide glass sliding partition Make sure the opening is perfectly square. The sill into which the lower rail is screwed must be perfectly level to allow the sliding partition system to work properly. If the deflection of the upper profile (gutter) is more than 20 mm, the glass sliding partition cannot be installed.

  • Page 10: Glass Plates Sizes

    Dimensions of the glass plates The height of the glass plate is: Hg – 85 mm. 10 mm The glass plates are distributed evenly across the width. The width of the glass plate is: - For a single system: (Bp-31,6+31*(X-1))/X-2,5 - For a double system: =(Bp-31,6-7+31*(X-2))/X-2,5 The glass dimensions have to be calculated.

  • Page 11: Specific Installation Tips

    Specific installation tips Upper rail (CGT) Check whether the upper profile can be anchored without perforating the gutter itself. As far as possible, it must therefore be possible to anchor the profile in the rearmost part of the gutter profile. Pre-drill upper profile with Ø...

  • Page 12: Side Profile With Sliding Lock

    Bottom rail (CGB) The single system with sliding lock only has drainage holes. The double system has 2 holes in the bottom rail to lock the sliding elements. These holes are positioned in the central inside part of the bottom rail. Make sure the horizontally drilled drainage holes are pointing outwards and the locking holes at the end match.
  • Page 13 Side profile (CGL10) + side profile with sliding lock (CGSHS) Needs to be sawn to the precise length on the construction site. Make sure the milled-out opening is facing downwards. For centering side profile (CGL10) use upper and down mounting block (CGCAL10U, CGCAL10D). First position the side profile on the parking side and centered above the outermost track.

  • Page 14: Sliding Elements

    Sliding elements (CGPL) The carrier profiles are custom-made and fitted with wheel guidance and locks. In the single system with one lock, there is one carrier profile fitted with a lock opening. It’s used for the sliding element on the parking side. There is also another carrier profile with locking side which goes to side profile with sliding lock.
  • Page 15 Install the first element with lock opening pointing inside on the parking side on the outermost track. Tip the sliding element up in the outermost guide of the upper rail. Tilt the element until it is vertical and let it drop until the wheel guide fits onto the outermost track.

  • Page 16: Finish

    If you have ordered the sealing brushes, they can now be sawn to length and be fixed on the glass with a suitable glue (TEC7 transparent or simular). ONLY USE ORIGINAL PARTS DELIVERED BY SKYLUX. EVERY GUARANTEE IS CANCELLED IF NON-ORIGINAL PARTS ARE USED. THESE GUIDELINES ONLY HAVE AN ADVISORY CHARACTER. ASSEMBLY FALLS UNDER THE ENTIRE RESPONSIBILITY OF THE CUSTOMER.
