SKYLUX Climax 36178 Installation Instructions Manual

Self-supporting aluminium profile system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
CANOPY
EN
Climax
®
Installation instructions
Self-supporting aluminium profile system
Art.N° 36178

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Climax 36178 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SKYLUX Climax 36178

Summary of Contents for SKYLUX Climax 36178

  • Page 1 CANOPY Climax ® Installation instructions Self-supporting aluminium profile system Art.N° 36178...

  • Page 2: Safety

    Safety Take the necessary and required safety precautions, such as safety nets and lifelines when installing from the outside, safety goggles, gloves, hard hat, etc. Do not step on the glass. Falling from height • When using ladders to go on the roof: - Ladder in good condition? - Set up correctly at an angle of 75°? - Secured below and on top against moving?
  • Page 3 Sharp objects • Make sure your fingers/hands are not pinched and watch out for cuts while handling veranda parts. • Be careful where you put your hands during the installation. • Wearing cut-resistant gloves is mandatory. Ergonomics • Always lift loads correctly: bend your knees, move your feet instead of forcing your spine, lift as close to your body as possible.

  • Page 4: Table Of Contents

    Table of contents SAFETY p. 2 - 3 CONTENTS p. 4 - 5 OVERVIEW OF CLIMAX PROFILES AND PARTS p. 6 - 10 GENERAL INSTALLATION TIPS p. 11 - 20 MEASURING YOUR CLIMAX PITCHED ROOF p. 12 - 13 MEASURING YOUR CLIMAX SADDLE ROOF p.
  • Page 5 Table of contents SPECIFIC INSTALLATION TIPS FOR THE CLIMAX SADDLE ROOF SYSTEM p. 68 - 74 PREPARATION OF THE RIDGE PROFILES OF A SADDLE ROOF p. 69 - 70 INSTALLATION OF THE RIDGE PROFILES OF A SADDLE ROOF p. 71 PREPARATION OF THE TIE BAR FOR THE SADDLE ROOF p.

  • Page 6: Overview Of Climax Profiles And Parts

    Overview of Climax profiles and parts WALL WALL TOP G120A GUTTER 120 A WALL BOTTOM RAISED PROFILE FOR GUTTER SUPPORTS HINGE SUPPORT HINGE SUPPORT GUTTER GUTTER SUPPORT INSIDE GUTTER FOR G GI 0 CONNECTION FOR G GI 90 OUTSIDE CORNER PIECE 90° THERMAL SUPPORT GI 120 OUTSIDE CORNER PIECE 120°...
  • Page 7 Overview of Climax profiles and parts L632 L END PROFILE FOR GLASS POST CLIP BASE FOR P V642 STEEL TUBE 60X40X2 GALVA POST 50/100 ALUMINIUM SIDE PROFILE 16, 25, POST CLIP BASE FOR POST CLIP L16P 32 MM WITHOUT COAT CL16 ALUMINIUM CLIP 16 MM POST CLIP...
  • Page 8 Overview of Climax profiles and parts COEX SEAL FOR GUTTER/RIDGE REINFORCED PVC END PROFILE 16 C11CX U16P WHITE/BLACK MM WHITE REINFORCED PVC END PROFILE 25 SUPPORT SEAL FOR GLASS U25P MM WHITE ACCESSORIES REINFORCED PVC END PROFILE 32 SPACER A1 U32P MM WHITE SPACER A2...
  • Page 9 Overview of Climax profiles and parts PERFORATED PLASTIC TAPE 25 MM BB25 GAP1 THERMAL END PANEL FOR GD1 WITH GUARANTEE PERFORATED PLASTIC TAPE 32 MM BB32 GAP2 THERMAL END PANEL FOR GD2 WITH GUARANTEE STRAIGHT CONNECTOR GRS1 GUTTER SLIDE END FOR GR ON G120A S163 STOP 16/3 GRS2...
  • Page 10 Overview of Climax profiles and parts SUPPORT BRACKET FOR SADDLE 8424 END-PIECE FOR THREADED BAR ROOF RIDGE BASE PLATE FOR POST 8426 EYE BOLT M10 x 50 U-TOP, BOTTOM FOR POST P AND 8421 TUBE PULLER SET BASE PLATE PV SELF-DRILLING STAINLESS STEEL SCREW (NON-COATED) STAINLESS STEEL BOLT, NUT AND...

  • Page 11: General Installation Tips

    The latest version of this manual can be consulted by visiting www.skylux.be. Climafast The CLIMAFAST calculation application, free of charge by Skylux. You will receive information on how to log on and download the Excel version of the application upon request. With Climafast you can determine the price of your Climax roof.

  • Page 12: Measuring Your Climax Pitched Roof

    These measurements can be used to calculate all other measurements using the Climafast calculation application that is made available free of charge by Skylux. We strongly recommend the use of the calculation application. All possible exceptions are taken into account. The correct cutting lengths are provided and only correct combinations are suggested.
  • Page 13 Measuring your Climax pitched roof The difference in height H and depth D for the veranda. H M = The height from the floor and the bottom side of the wall bottom (MB) measured at the back of the veranda. H N = The slope of your veranda floor.

  • Page 14: Measuring Your Climax Saddle Roof

    These measurements can be used to calculate all other measurements using the Climafast calculation application that is made available free of charge by Skylux. All possible exceptions are taken into account. The correct cutting lengths are provided and only correct combinations are suggested. The list of measurements for sizing is always provided with the materials.
  • Page 15 Measuring your Climax saddle roof The difference in height H and depth D for the saddle roof. H M = Height between the floor and the bottom side of the ridge to wall bottom MB measured at the back against the wall.

  • Page 16: Preparation

    Preparation The Climax roof can be delivered cut-to-size to reduce the installation time. The seals and certain other components are, when possible, fixed onto or into the profiles for the preinstalled roof system. Walls Check that the walls, against which the structure is to be installed, are: - Sufficiently load-bearing to anchor the roof.

  • Page 17: General Tips And Maintenance Instructions

    Dissolve a little panels are only adapted in combina- household soap (neutral) in the water tion with Skylux screwable clips. if required (no detergent!!). Never use 5. GLASS solvents or abrasive products. Heat accumulation: the top side...
  • Page 18 An appropriate sealing is recom- Relax - PMMA: S5P Heatstop) or move during sawing. The saw blade colour differences. mended. install a Skylux conservatory dome. must slightly reach out of the sheet. 18/88 E_MH_Installation_instructions_Skylux_Climax 20/11/2020...
  • Page 19 Overview of the drawing of the conservatory roof without thermal bridge A10 - A11: Posts, page 22-23 / 44 A20 - A23: Gutters, page 24-28 / 41 A30 - A33: Wall profiles, page 29 / 32-33 / 40 A40 - A42: Supports and side supports, page 30-33 / 36-39 19/88 20/11/2020 E_MH_Installation_instructions_Skylux_Climax...
  • Page 20 Overview of the drawing of the conservatory roof with thermal bridge B10 - B11: Posts, page 43-44 / 67 B20 - B23: Gutters, page 45-48 / 65-67 B30 - B33: Wall profiles, page 50 / 55 / 65 B40 - B42: Supports and side supports, page 51-55 / 58-64 20/88 E_MH_Installation_instructions_Skylux_Climax 20/11/2020...
  • Page 21 Installation tips for the Climax system without thermal bridge 21/88 20/11/2020 E_MH_Installation_instructions_Skylux_Climax...

  • Page 22: Posts

    Posts Determine the length of the posts (Hn + Hg) in relation to the gradient and the position of the wall profile (HM). Specific instructions are applicable for posts in combination with gutter support GD2 (see page 81). The following posts can be used for roofs without a thermal bridge: Standard posts accessories for the corner post accessories for the intermediate post...
  • Page 23 Posts Posts with post clips for water discharge Post 181/110 (P + PCB + PC) Accessories for corner posts Accessories for middle posts Base plate PV and U-shaped bracket U-bracket Bolt the U-bracket to the PV base plates (Fig. A) using the BMR screw set (Fig. B) for the corner posts. Determine the position of the PV base plates as indicated on page 13 and anchor these on a solid foundation in concrete using the suitable fixing accessories (not supplied).

  • Page 24: Gutter

    Gutter Multiple gutter combination options are possible with regard to the load and the required span for roofs without a thermal bridge. Use the load graphs on pages 77 - 80 or calculate using the Climafast calculation application: Gutter combination (with reinforcement profile) GD1 + G + Y10 (+ V642) V642 GD2 + G + Y10 (+ PL165* / PL105)
  • Page 25 Gutter GD1 + G + Y10 Assemble the gutter components to prepare for the installation of the gutter. S1/S2 Cut out the opening for the water outlet. Connect the gutter (G) to the gutter Use a Ø 80 mm circular drill for this task. support (GD1) using the Y10.
  • Page 26 Gutter GD2 + G + Y10 Assemble the gutter components to prepare for the installation of the gutter. S1/S2 PL105* PL165* Y16P Cut out the opening for the water outlet. Connect the gutter (G) to the gutter support Use a Ø 80 mm circular drill for this task. (GD2) using the Y10.
  • Page 27 Gutter Multiple gutter elements can be connected to each other for gutter lengths > 7 metres. A gutter support must be installed at every gutter connection point. We recommend tilting the profiles and supporting the gutter support connections when using a gutter and gutter support (GD1.GD2) combination. The gutter profiles can be linked using connection pins 909 and/or connector profile GI.

  • Page 28: Hinge Profile

    Gutter The Climax system can be installed on a (roof) structure. The self-supporting gutter profiles must be replaced by non-self-supporting hinge profile SB for this. This profile is installed on a continuous upstand using adjusted fixing accessories to be provided by the customer. Seal C11CX must be installed according to the figure below to provide a watertight and windtight connection.

  • Page 29: Wall Profile

    Wall profile Parts 73,4 73,4 C1CX C1CX Y16P Y16P 38,5 38,5 Preparation 1000 1000 Make a slot in the wall against which the conservatory roof must be installed (see page 16). Install a lead slab or zinc flashing. Drill a hole on the indicated line in the bottom wall profile MB at 250 mm from the ends and, subsequently, every 500 mm.
  • Page 30 Rafters and side rafters The following (side) supports are possible: Sheet supports TP (white) are used for roofs with glazing plastics. Sheet supports TPG (green) are used for roofs with glass (single or double glazing). A steel reinforcement profile must be slid into the supports for a large span or an expected heavy snow load.
  • Page 31 Rafters and side rafters Preparation Y25/Y32 TP(G) Cut the plastic sheet supports TP or TPG to the right length Adaptor profile Y25 or Y32 should be slid in while retaining the precut part. You may have to make this depending on the glazing thickness (see the cut-away yourself depending on the cutting.

  • Page 32: Supports And Side Supports

    Supports and side supports Assembly AX = PL + 22 MM The number of supports and their position is determined in relation to the glazing and the load. Check the length of the support with regard to the depth of the conservatory and the load (glazing + snow and wind); see the graphs on pages 77 - 80 or use the Climafast calculation application.
  • Page 33 Supports and side supports Installation using connectors and glass A1/A2 D1/D2/D3 Fasten connectors K on to the hinge profiles using parker screws PST. Drill holes with a Ø of 4 mm in advance at the indicated lines (left and right) of the connector. The holes are to be drilled to the left and right of the support, both on the wall and gutter side.

  • Page 34: Glazing

    Glazing: plastic sheets Preparation gutter GD1+G120A GD1+G GD2+G Glazing Plastic sheets 10 - 45° 10 - 20° Only the left and right sheets are cut to size. Provide the open ends with suitable plastic tape (closed tape BT on the top side = wall side and perforated tape BB on the bottom side = gutter side).
  • Page 35 Glazing: glass sheets Preparation GD1+G120A gutter GD1+G GD2+G Glazing Glass 5 - 20° 5 - 45° max. L432 L632 28 mm L432/L632 L432 28 - 38 mm Always use laminated glazing in your conservatory roof according to the applicable standards. Consult your glass supplier.

  • Page 36: Finish

    Finish SUPPORTS SEAL FINISH Y25/Y32 C2CX C2CX Finish using seal C2CX for plastic sheets or glass: The glazing Push seal C2CX into sheet support TP(G) or into thickness and options are provided in the table on page 84. raised profile Y25/Y32. CLIP FINISH For plastic sheets or glass: The glazing thickness and options are provided in the table on page 84.
  • Page 37 Finish SUPPORTS Screw-in type clips For plastic sheets or glass: The glazing thickness and options are provided in the table on page 84. CLST CLSB CY10 The screw-in type clips consist of 2 parts: Push seal C8 or CY10 on both sides into the CLSB clips. - CLSB bottom clips Ensure that seal C8 does not continue up to the end of the - CLST top clips...
  • Page 38 Finish SIDE SUPPORTS SEAL FINISH Seal C2CX for plastic sheets or glass: The glazing thickness and options are provided on page 84. C2CX L16P C2CX Y25/Y32 L16P TP(G) TP(G) Push seal C2CX into sheet support TP(G) or into raised profile Y25/Y32. Cut side finishing profile L16P obliquely on the wall side in accordance with the roof pitch a.
  • Page 39 Finish Installation of screw-in type side clips Drill holes with a Ø of 5.5 mm in the CLSB every 500 mm, starting and ending at 200 mm from the ends. Fasten the CLSB to the TPG using adapted Hi-Lo screws. Fasten perpendicularly and use a slight torque to ensure the screw head is pressed flat against the CLSB.
  • Page 40 Finish WALL PROFILE C1CX Position seal C12 to increase the pressure of C1CX on Position the MAS end panel on the freestanding sides the glazing. of the wall profile. Use the point indications on the MAS to determine the position of the second ZSG screw.
  • Page 41 Finish GUTTER GD2 + G GD2C GD2C Y16P click Gutter support GD2 is finished with GD2C. Cut the Fasten the detail of the GD2C with a clip into plastic profile longitudinally at the indicated position. The profile Y16P. Once it is in the correct position, free the length of GD2C matches the distance between the adhesive strip completely and push the GD2C against walls and/or posts.
  • Page 42 Installation tips for the Climax system with thermal bridge 42/88 E_MH_Installation_instructions_Skylux_Climax 20/11/2020...

  • Page 43: Posts

    Posts Determine the length of the posts (HN + Hg) in regard to the slope and the position of the wall profile (Hm). Specific instructions apply for the posts in combination with gutter support GD2 (see page 84). The following posts can be used for roofs with a thermal bridge: Standard posts accessories for the corner post accessories for the middle post...
  • Page 44 Posts Bolt the U-bracket to the base plates PV using the BMR screw set for the corner posts. Determine the position of the base plates PV as indicated on page 13 and anchor these on a strong foundation in concrete with the appropriate fixing material.
  • Page 45 Gutter combination There are multiple gutter combination options in relation to the load and the required span for roofs with a thermal bridge. Use the load graphs on pages 77 - 80 or calculate using the Climafast calculation application: Gutters (with reinforcement profile) GD1 + (V642) + G + Y16P + C11CX C11CX Y16P...

  • Page 46: Gutter

    Gutter GD1 + G + Y16P + C11CX Assemble the gutter components to prepare for the installation of the gutter. S1/S2 Y16P Cut out the opening for the water outlet. Connect the gutter (G) to the gutter support (GD1) Use a Ø 80 mm circular drill for this task. using the Y16P.
  • Page 47 Gutter GD2 + G + Y16P + C11CX Assemble the gutter components to prepare for the installation of the gutter. S1/S2 Y16P Y16P Cut out the opening for the water drainage. Connect the gutter (G) to the gutter support (GD2) Use a Ø...
  • Page 48 Gutter Multiple gutter elements can be connected to each other for gutter lengths > 7 metres. A gutter support must be installed at every gutter connection point. We recommend tilting the profiles and supporting the gutter support connections when using a gutter and gutter support (GD1.GD2) combination. The gutter profiles can be linked using connection pins (909) and/or GI connector profile.

  • Page 49: Hinge Profile

    Hinge profile The Climax system can be installed on a (roof) structure. The self-supporting gutter profiles must be replaced by non-self-supporting hinge profile SB for this. This profile is installed on a continuous upstand using adjusted fixing accessories to be provided by the customer. Seal C11CX must be installed according to the figure below to provide a watertight and windtight connection.

  • Page 50: Wall Profile

    Wall profile Parts 73,4 73,4 C1CX C1CX Y16P 2x Y16P C11CX C11CX 38,5 38,5 Preparation 1000 1000 Make a slot in the wall against which the conservatory roof can be installed (see page 14.) Install a lead slab or zinc flashing. Drill a hole on the indicated line in the bottom wall profile MB at 250 mm from the ends and subsequently every 500 mm.

  • Page 51: Supports And Side Supports

    Rafters and side rafters The following (side) supports are possible: Sheet supports TP (white) are used for roofs with plastic glazing. Sheet supports TPG (green) are used for roofs with glass (single or double glazing). A steel reinforcement profile must be slid into the supports for a large span or an expected heavy snow load.
  • Page 52 Rafters and side rafters Freestanding side support ZD + C5 + TP(G) + Y16P + ZDC TP(G) Y16P Y16P Side support against the wall ZD + TP(G) + L432 ZD + TP(G) + ZD2B TP(G) TP(G) 5 mm 5 mm ZD2B L432 L432 for the finish of the side support with hinge...
  • Page 53 Rafters and side rafters Preparation Y25/Y32 TP(G) Cut the plastic sheet supports (TP or TPG) to the Raised profiles (Y25 or Y32) are required with regard right length while retaining the precut part. You may to specific glazing thicknesses > 20 mm. See the table have to make this cut-away yourself depending on on page 84.
  • Page 54 Rafters and side rafters For freestanding side support with a ZDC finish TP(G) 32 mm 25 mm 16 mm 16 mm (5 - 20 mm) 25 mm (21 - 29 mm) 32 mm (30 - 34 mm) Y16P Cut side finish profile ZDC at a slant on the wall side Slide the ZDC profile on to the side support using based on roof pitch (alpha).
  • Page 55 Rafters and side rafters A1/A2 S1/S2 D1/D2/D3 Position the assembled side supports on hinges S1 or S2 with the stop profiles towards the gutter. The supports with connectors at the wall and gutter side must be anchored in hinge profile S1 or S2 using PST screws.

  • Page 56: Glazing

    Glazing: plastic sheets Preparation gutter GD1+G GD2+G Glazing 10 - 45° Plastic sheets Only the left and/or the right sheet are cut to size. Provide the open ends with suitable plastic tape (closed tape BT on the top side = wall side and perforated tape BB on the bottom side = gutter side).
  • Page 57 Glazing: glass sheets Preparation gutter GD1+G GD2+G Glazing Glass 5 - 45° max. L432 L632 28 mm L432/L632 L432 28 - 38 mm Always use laminated glazing in your conservatory roof according to the applicable standards. Consult your glass supplier. Stick an L-shaped end profile (L432 or L632) on the crosscut side of the glass. Use silicone SG20 for this. Assembly C11CX S1/S2...

  • Page 58: Finish

    Finish SUPPORTS SEAL FINISH Y25/Y32 C2CX C2CX Finish using seal C2CX for plastic sheets or glass: The glazing Push seal C2CX into sheet support TP(G) or into thickness and options are provided in the table on page 83. raised profile Y25/Y32. CLIP FINISH For plastic sheets or glass: the glazing thickness and options are provided in the table on page 83.
  • Page 59 Finish SUPPORTS Screw-in type clips For plastic sheets or glass: The glazing thickness and options are provided in the table on page 83. CLST CLSB CY10 The screw-in type clips consist of 2 parts: Push seal C8 or CY10 on both sides into the CLSB clips. - CLSB lower clips Ensure that seal C8 does not continue up to the end of the - CLST upper clips...
  • Page 60 Finish SIDE SUPPORTS WITH RUBBERS Finish using seal C2CX for plastic sheets or glass: The glazing thickness and options are provided in the table on page 83. For freestanding side support: C2CX ZDCS Push seal C2CX into sheet support TP(G) or into raised Install finish profile ZDCS at the crosscut side of the profile Y25/Y32.
  • Page 61 Finish FREESTANDING SIDE SUPPORTS WITH CLIPS Finish using clips for plastic sheets or glass: The glazing thickness and options are provided in the table on page 83. Standard clips (for plastic sheets of glass with a thickness of 16. 25 or 32 mm): CL16/CL32 TP(G) Y16P...
  • Page 62 Finish FREESTANDING SIDE SUPPORTS WITH CLIPS Drill holes with a Ø between 5.5 and 6 mm in the CLSB every 50 cm, starting and ending at 20 cm from the ends. Fasten the CLSB to the TPG using adapted Hi-Lo screws. Fasten perpendicularly and use a slight torque to ensure the screw head is pressed flat against the CLSB.
  • Page 63 Finish SIDE SUPPORT AGAINST THE WALL WITH CLIPS Standard clips (for plastic sheets of glass with a thickness of 16.25 or 32 mm): CLL for 16, 25 or 32 mm thick plastic sheets or glass. Push seal C8 or CY10 into the CLL. Ensure that seal C8 does not continue up to the end of the gutter side but to the end profile on the glazing.
  • Page 64 Finish SIDE SUPPORT AGAINST THE WALL WITH CLIPS Drill holes with a Ø between 5.5 and 6 mm in the CLSB every 500 mm, starting and ending at 200 mm from the ends. Fasten the CLSB to the TPG using adapted Hi-Lo screws. Fasten perpendicularly and use a slight torque to ensure the screw head is pressed flat against the CLSB.
  • Page 65 Finish WALL PROFILE C1CX Position seal C12 to increase the pressure of C1CX on the glazing. GUTTER Install the end panels and click the plastic plug in the A frontal UGS water outlet is required to ensure the corresponding holes. Install the thermal break GAP water can flow outside when the water drainage is between the gutter rafter and the end panel.
  • Page 66 Finish GUTTER GD2 GD2C Y16P Gutter support GD2 is finished with GD2C. The GD2C The GDP thermal bridge must be cut at a length must be cut lengthwise to max 80 mm, up to the equal to the distance between the walls and/or posts. thermal break of the window profile which comes Remove the adhesive strips Position the GDP against underneath the gutter profile.
  • Page 67 Finish GUTTER GD2 GD2C Y16P For window profiles > 80 mm: screw GD2C into the central indication line using coated screws ZSG in plastic profile Y16P. Once it is in the correct position, free the adhesive strip completely and push the GD2C against the gutter.

  • Page 68: Saddle Roof

    Specific instruction tips for the saddle roof Climax system 68/88 E_MH_Installation_instructions_Skylux_Climax 20/11/2020...
  • Page 69 Ridge for saddle roof PREPARATION C1CX C1CX Y16P Y16P C11CX C11CX S1/S2 S1/S2 The ridge of the saddle roof must be attached to at least one wall. Check all dimensions. These can be found in pages 12 and 13 of this manual. The assembly of the ridge profiles is identical for a thermal and a non-thermal saddle roof.
  • Page 70 Ridge for saddle roof PREPARATION ø 8 mm Drill a hole (Ø 8 mm) every 500 mm in the indicator line of the bottom and top wall profile and fasten the profiles back-to-back using the bolts in the fixing sets (BMR). When the ridge profile consists of multiple lengths, the profiles must be slanted.
  • Page 71 Ridge for saddle roof ASSEMBLY HM + 17 Install the ridge support bracket (NCZ) to the wall. Slide the assembled ridge profile on to the ridge Check whether the foundation and the walls on which support bracket (NCZ) and anchor these using 2 fixing the structure is to be anchored have a sufficient sets (BMR).
  • Page 72 Tie bar for saddle roof PREPARATION 8426 8424 To guarantee the stability of the saddle roof, a tie bar must be installed for every 2 supports. With a non-thermal bridge Climax saddle roof, you must also use a tie bar set at the open end. An eye bolt must be installed in these supports at the gutter side during the preparation phase.

  • Page 73: Saddle Roof

    Tie bar for saddle roof ASSEMBLY 8425 8424 8423 8426 8426 8424 8424 Measure the length of the threaded bars towards the ring and cut this to size. The ring can be positioned using the bolts (M10) to ensure a horizontal connection between the supports. When you are certain about the position, you can cut the coated tube to size and slide it over the threaded bars.

  • Page 74: Side Finish Of The Saddle Roof

    Side finish of saddle roof NON-THERMAL BRIDGE SADDLE ROOF L16P/CLL/CLSL D1/D2/D3 The visible side supports are provided with an L16P (with C2CX seals), a CLL (with CL16 or CL32 clips) or a CLSL (with screw-in type CLSB with CLST clips). At the top of the ridge this side finish will be covered by the ridge end panel (NASZ).

  • Page 75: Annex

    Annex load graphs and special applications installation tips for the Climax system 75/88 20/11/2020 E_MH_Installation_instructions_Skylux_Climax...

  • Page 76: Load Graphs

    Please contact your fixing material supplier or specialised engineering consultants in case of doubts. Skylux cannot be held liable for the installation or the fixing material used.

  • Page 77: Load Graphs For Roofs With Plastic Sheets

    Load graphs for roofs with plastic sheets GUTTER PROFILES The graphs below can be used to determine the free span for each type of gutter (support). This is the distance (P) between the supports (posts) in relation to the load and the depth (D) of the roof. The maximum bending is 1/200. The load is related to the snow and wind load.
  • Page 78 Load graphs for roofs with plastic sheets SUPPORT PROFILES The graphs below can be used to determine the free span for each type of support (D1 or D2) with or without a reinforcement profile. This is the maximum length of the support between the hinge profiles in relation to the load and the depth (D) of the roof. The maximum bending is 1/200.
  • Page 79 Load graphs for roofs with glazing GUTTER PROFILES The graphs below can be used to determine the free span for each type of gutter (support). This is the distance (P) between the supports (posts) in relation to the load and the depth (D) of the roof. The maximum bending for structures with glazing is 1/300. The load is the sum of the weight of the glazing and the snow and wind load applied to the roof.
  • Page 80 Load graphs for roofs with glazing SUPPORT PROFILES The graphs below can be used to determine the free span for each type of support (D1 or D2) with or without a reinforcement profile. This is the maximum length of the support between the hinge profiles in relation to the load and the depth (D) of the roof. The maximum bending is 1/300.

  • Page 81: Specific Installation Tips For Posts

    Specific installation tips for posts SUPPORT WITH POSTS FOR GD2 Without thermal bridge H G + H N H G + H N The outer post section P or the post clip PC is 70 mm longer than the inner post section P in relation to assembled support posts (= HN + HG).
  • Page 82 Specific installation tips for glazing connections Application: The glass connector is used for slanted roofs to create a watertight connection between two glass or two plastic sheet sections. This is only possible with sheet support TP or TPG and the screw-in type clips CLSB with CLST/CLSL. The following parts are used for a glass connection: GVT top profile Y16P thermal bridge...
  • Page 83 Specific installation tips for glazing connections Installation: Slide profiles Y16P and Y10 in bottom profile GVB in Position the complete set on sheet support TPG with relation to the glazing thickness according to the table the stop shoulder towards the ridge. Add adhesive to the on page 80.

  • Page 84: Glazing Thickness Table

    Glazing thickness table Thickness CLSB & CLST CL16 CL32 C2CX Stop profile 5 mm ++ (CY10) ° HL25 + (CY10) ° S16.3 6 mm ++ (CY10) ° HL25 + (CY10) ° S16.3 7 mm ++ (CY10) ° HL25 + (CY10) ° S16.3 8 mm ++ (CY10) °...
  • Page 85 85/88 20/11/2020 E_MH_Installation_instructions_Skylux_Climax...
  • Page 86 86/88 E_MH_Installation_instructions_Skylux_Climax 20/11/2020...
  • Page 87 87/88 20/11/2020 E_MH_Installation_instructions_Skylux_Climax...
  • Page 88 ONLY USE ORIGINAL PARTS DELIVERED BY SKYLUX. EVERY GUARANTEE IS CANCELLED IF NON-ORIGINAL PARTS ARE USED. THESE GUIDELINES ONLY HAVE AN ADVISORY CHARACTER. ASSEMBLY FALLS UNDER THE ENTIRE RESPONSIBILITY OF THE CUSTOMER. CLIMAX IS A REGISTERED BRAND OF SKYLUX SPINNERIJSTRAAT 100 - B-8530 STASEGEM T +32 (0)56 20 00 00 - F +32 (0)56 21 95 99 INFO@SKYLUX.BE...

Table of Contents
