Installation
Wall mounting bracket installation (optional)
Your telephone base comes with the wedge installed, ready for desktop use. If you prefer to mount
your telephone on the wall (optional), it is designed to mount on a standard telephone wall plate. For
wall mounting, follow these instructions:
• First, insert the lower portion tabs of the wall mounting bracket into the lower grooves in the telephone
base, then snap the upper portion tabs of the wall mounting bracket into place.
• Mount the telephone base on the wall by positioning it so the mounting studs will fit into the holes on the
telephone base and wall mounting bracket. Slide the telephone base down on the mounting studs until it locks
into place.
• To remove the bracket, press both upper portion tabs firmly inward and pull the bracket downward
until it release from the grooves.

Desk/table bracket installation

To place your telephone base on a desk or table, insert the
wall mounting/desktop bracket.
• Insert the lower portion tabs of the bracket into the upper
grooves of the telephone base.
• Snap the upper portion tabs of the bracket into place.
• To remove the bracket, press both upper portion tabs
firmly inward and pull the bracket upward until it is
released from the grooves.
lower portion tab
lower grooves
www.vtechphones.com
upper portion tab
upper grooves
7
