Installation
Wall mounting bracket installation
Your telephone base comes with a desktop bracket installed. If you prefer to mount your telephone
on the wall, it is designed to mount on a standard telephone wall plate.
To install the wall mounting bracket:
1.
First, remove the bracket from the telephone base by carefully pressing on the tabs until the bracket
is released.
2.
Next, rotate the bracket so that the hole for the wall mounting studs is in the same orientation as
the mounting hole on the back of the telephone base.
3.
Insert the lower tabs of the bracket into the grooves marked WALL MOUNT in the telephone base,
then snap the upper tabs into place.
DS4122-X CIB 0110 08.indd 5
upper tab
lower tab
upper grooves
lower groove
www.vtechphones.com
5
01/11/2008 11:55:09
