Explanation of icons

2.2 Explanation of icons
Symbol Description
Press
Do not press
Turn
Switch
Switch off machine
0
1
Switch on machine
0
1
ENTER (enter the menu)
NAVIGATION (Navigating in the menu)
EXIT (Exit the menu)
Time display (example: wait 4s/press)
Interruption in the menu display (other setting options possible)
Tool not required/do not use
Tool required/use
