Model: PGD105TiSCO
10500 Watt Tri-Fuel Inverter Generator
OPERATOR'S MANUAL
Warning: The Engine Exhaust from this product contains chemicals known to the State
DO NOT RETURN TO STORE!
of California to cause cancer, birth defects or other reproductive harm.
HAVE QUESTIONS OR NEED SERVICE?
866-591-8921
support@pulsar-products.com

Advertisement

Table of Contents
loading

Related Manuals for Pulsar PGD105TiSCO

Summary of Contents for Pulsar PGD105TiSCO

  • Page 1 Model: PGD105TiSCO 10500 Watt Tri-Fuel Inverter Generator OPERATOR'S MANUAL Warning: The Engine Exhaust from this product contains chemicals known to the State DO NOT RETURN TO STORE! of California to cause cancer, birth defects or other reproductive harm. HAVE QUESTIONS OR NEED SERVICE? 866-591-8921 support@pulsar-products.com...

  • Page 2: Table Of Contents

    It means to pay attention and be alert, your safety is involved! Please read and abide by the message that follows the safety alerts symbol. Pulsar Products reserves the right to make updates to this manual at any time. DANGER Please contact Pulsar Support at 866.591.8921 or email...

  • Page 3: Safety Instructions

    Safety Instructions Safety Precautions Safety Symbols Follow all safety information contained in this manual and on the DANGER generator. Before operating your generator, you must read and understand the Using a generator indoors CAN KILL YOU IN MINUTES. manual and familiarize yourself with the safe operation practices. Generator exhaust contains carbon monoxide.
  • Page 4 Safety Instructions WARNING Correct Usage Example location to reduce risk of carbon monoxide poisoning ● ONLY use outside and downwind, far away from windows, doors, and vents. ● Direct exhaust away from occupied spaces. Fuel and its vapors are extremely ammable and explosive which could cause burns, re, or explosion resulting in death or serious injury and/or property damage.

  • Page 5: Co Sentry

    ● If you have questions about intended use, ask a dealer or contact air for dangerous levels of carbon monoxide. If dangerous levels of your local Pulsar service center. carbon monoxide are detected this generator will automatically shutoff. ● Operate generator only on solid, level surfaces.

  • Page 6: Names Of Components

    Components Before operating your generator, you must read and understand the manual and familiarize yourself with the safe operation practices. Right Side Cover Control Panel Transport Handle Recoil Handle Operator Position Fuel Tank Cap Fuel Gauge Fuel Tank Mufer Left Side Cover Wheel Operator Position...

  • Page 7: Control Panel

    Control Panel START STOP...

  • Page 8: SpeciCations

    Specifications Engine Model 192F/P-2 Engine Type Single Cylinder, Four Stroke, Air Cooled, Overhead Valve Cylinder Diameter×Stroke 92x69 (mm) Displacement(cc) Compression Ratio 8.5±1 Gas Distribution Mode Cooling Mode Forced Cold Air Output Power(kW/r/min) 10.5/3600 Starting Mode Electric and Manual Recoil Fuel Tank Capacity(US gallon) 6.9 (26L) Type And Grade Of Fuel Unleaded Gasoline or LPG(Propane)

  • Page 9: Preparation

    Preparation Preparation Your generator requires some assembly. This unit ships from our factory without oil; it must be properly lled with oil before operation. Unpacking 1. Set the shipping carton on a solid, at surface. 2. Remove everything from the carton except the generator. 3.

  • Page 10: Connecting Lpg Tank

    Preparation NOTICE Check oil level often during the break-in period. Refer to the Maintenance section for recommended service intervals. CAUTION This engine is equipped with a low oil shut-off and will stop when the oil level in the crankcase falls below a critical level. NOTICE 4.

  • Page 11: Connect The Natural Gas (Ng) Supply Line

    ● ALWAYS position the propane tank so the connection between the continues or if the leak is not at a tting then DO NOT use the generator valve and the gas inlet will not cause sharp bends or kinks in the and contact an authorized Pulsar service center. hose. WARNING Explosion hazard.

  • Page 12: Battery

    tting with the soap and water solution. If the leak continues or if the leak is not at a tting then DO NOT use the generator and contact an authorized Pulsar service center. 3. Completely unwrap and straighten the natural gas hose to prevent kinks.
  • Page 13 Preparation 3. A quick-connect battery plug is pre-installed on the battery. Remove the cable tie securing the plugs, align colors, then push rmly to connect them. 4. Align the tabs on the bottom of the battery access cover with the generator case then push to reinstall the cover.

  • Page 14: Operation

    Operation Generator Location Starting The Generator WARNING 1. Make sure the generator is on a solid, at, level surface. 2. Disconnect all electrical loads from the generator. Never start or stop the generator with electrical loads connected. NEVER operate the generator inside any building, garage, 3.
  • Page 15 Operation DANGER DANGER 6. Choose the starting method Recoil Start: Firmly grasp and pull the recoil handle slowly until you feel resistance, let it retract then pull swiftly. Fire and explosion hazard. Always turn the propane tank valve to the fully closed position if not running the generator on propane. WARNING When using the generator with propane, make sure there is no possible ignition source close to the generator.
  • Page 16 6. Any generator will produce less power at high altitudes and/or in hot weather. Please contact Pulsar Support at 866.591.8921 for details. Low Oil Indicator 1. If the engine oil level is too low, the LOW OIL light turns on and the engine will automatically shut off.
  • Page 17 Operation Generator Capacity NOTICE Do not overload the generator's capacity. Exceeding your generator's wattage capacity can damage the generator and/or electrical devices connected to it. Make sure the generator can supply enough continuous (running) and surge (starting) watts for the items you will power at the same time. The total power requirements (Volts x Amps=Watts) of all appliances connected must be considered.

  • Page 18: Maintenance

    Maintenance WARNING ACCIDENTAL STARTING: Turn the fuel selector to the "OFF" position, wait for the engine to cool, and disconnect the spark plug cable before performing any inspection, maintenance, or cleaning procedures. EQUIPMENT FAILURE: Do not use damaged equipment. If abnormal noise, vibration, or excess smoking occurs, have the problem corrected before further use.
  • Page 19 Maintenance Checking and Filling Fuel WARNING TO PREVENT SERIOUS INJURY FROM FIRE: Fill the fuel tank in a well-ventilated area away from ignition sources. If the engine is hot from use, shut the engine off and wait for it to cool before adding fuel. Do not smoke. 1.
  • Page 20 Maintenance Air Filter Element Maintenance 1. Allow the generator to cool completely. 2. Remove the Screws from the back of the generator. 3. Remove the Tail Pipe and Spark Arrestor. 1. Loosen screws and remove the Air Filter Access Panel on the left 4.
  • Page 21 Maintenance NOTICE Draining the Carburetor Use only BPR6ES (NGK) type spark plug or equivalent. Using an After closing the Fuel Valve, place an appropriate container under the incorrect spark plug may damage the engine. Carburetor and carefully remove the Drain Bolt from the bottom of the Carburetor Bowl, allowing the fuel to drain completely.

  • Page 22: Troubleshooting

    8. Too much fuel in the chamber. This can be caused 8. Shut off the fuel valve, move the generator to by the carburetor needle sticking. a safe, outdoor location and contact a certied Pulsar Service Center before using the generator again. 9. Clogged Fuel Filter. 9. Replace Fuel Filter.
  • Page 23 Troubleshooting Problem Possible Causes Probable Solutions THE ENGINE WILL COMPRESSION RELATED: COMPRESSION RELATED: NOT START 1. Cylinder not lubricated. 1. Pour a tablespoon of oil into the spark plug Problem after long storage periods. hole. Crank the engine a few times and try to start again.
  • Page 24 Troubleshooting Problem Possible Causes Probable Solutions ENGINE STOPS 2. Fuel tank empty or full of impure or low-quality 2. Fill fuel tank with fresh 87+ octane stabilizer SUDDENLY gasoline. treated unleaded gasoline. Do not use gasoline with 3. Defective fuel tank cap creates a vacuum and more than 10% ethanol(E15, E20,E85,etc.).

  • Page 25: Electrical Schematic

    Electrical Schematic 120/240V, 60Hz Electrical Schematic...
