Project Source W3030B Assembly Instruction Manual page 9

ASSEMBLY INSTRUCTIONS
10. Insert the shelf onto the cabinet at some angle
as per the drawing and press the shelf from
the top until it gets held with the shelf support
hardware.
11. Insert the shelf onto the cabinet at some angle
as per the drawing and press the shelf from
the top until it gets held with the shelf support
hardware.
12. Mount the door on the cabinet by connecting the
hinges on the door to the mounting plates on
the box. Use the hinge guide below for detailed
instructions.
If the adjustments to the door are needed,
instructions are available on page 10 of this manual.
Hinge guide
105 o Hinge
10
11
12
9
