Project Source W3030B Assembly Instruction Manual page 10

ASSEMBLY INSTRUCTIONS
13. YOU'RE FINISHED – ENJOY
Hinge Adjustment:
Side adjustment:
Using a Phillips screwdriver, rotate
screw (1) clockwise to move the door
left and counter-clockwise to move the
door right. Moves the door up to 2 mm.
Depth adjustment:
Using a Phillips screwdriver, rotate screw
(2) clockwise to move the door forward
and counter- clockwise to move the door
backwards. Moves the door up to 2 mm.
13
Height adjustment:
Using a Phillips screwdriver, rotate
screw (3) clockwise to move the door
upward and counter-clockwise to
move the door downward. Moves
the door up to 2 mm.
10
Door Assembly
