APPLIANCE ASSEMBLY

1. Press both latches on the suction hose mounting ring (17), insert the ring into the opening (7) and
release the latches. To disassemble, press the latches again and remove the ring (17) from the
opening (7).
2. Connect the telescopic tube (16) to the other side of the suction hose. Attach one of the suction
attachments (20) or (21) to the end of the pipe.

USING THE APPLIANCE

1. Before turning on the vacuum cleaner, unwind the power cord (9) to a suitable length and plug it
into the mains socket. The yellow mark on the power cord indicates the optimum length. Do not
pull out the cord beyond the red mark! While unwinding the cord, do not press the cord winder
button (23).
2. Press the switch (1) to turn on the vacuum cleaner.
WARNING! Dust bag filling level indicator light turns red when the suction hose is clogged or
the dust bag is full. You need to clean the dust bag or remove the clogging from the suction hose.
3. To wind the power cord, press the cord winder button (23) with one hand, while holding the cord
with another hand to prevent a sudden movement that could damage it.
4. To ensure optimum appliance setting upon the completion of work, use the guide (3) in the rear
of the vacuum cleaner. Place the rail in the rear of the floor-carpet attachment with connected
suction hose and telescopic pipe on the guide. The second guide that facilitates vacuum cleaner
storage in the vertical position is under the bottom of the appliance.

ACCESSORIES OVERVIEW

FLOOR-CARPET ATTACHMENT
Designed for cleaning large flat surfaces. It is equipped with castors that facilitate mo-
vement in difficult to access places and a flexible joint, connecting it with the suction
hose, which allows directing at various angles. When you press the button on the upper
attachment housing (switch it to the brush mode), a row of rigid bristles will appear on the
bottom to facilitate cleaning hard floors.
SLIT ATTACHMENT WITH MOVABLE BRUSH
Used for cleaning difficult to access areas, such as in room corners, by and below pieces
of furniture and in bends and slits. It is also perfect for cleaning computer keyboards,
drawers, radiators or window frames.
EMPTYING THE DUST BAG
To empty the dust bag, turn off the vacuum cleaner, disconnect it from the power source,
unhook the narrow suction hose (18), then use the button (6) to open the top cover (5)
and remove the bag with the frame. Then slide the bag out of the frame (12) and remove
the plastic seam sealing the bag above the waste bin. After emptying the bag, replace the
bag's sealing seam, insert the bag into the frame and place the frame into the dust conta-
iner. Finally, close the cover (5).
