Cleaning And Maintenance - MPM MOD-53 User Manual

EN
AIR FILTER CLEANING AND REPLACEMENT
Normal use of the vacuum cleaner requires periodical replacement or cleaning of the air
filter, which protects the motor from the side of the dust bag, and the air outlet filter. For
this purpose, disconnect the appliance from the power supply and detach the suction
pipe.
1. Open the cover (5), remove the dust bag (14) and then remove the motor filter grid (22). Slide out
the filter insert.
2. Remove the cover (10) and gently pull out the exhaust filter (11).
3. Remove dust from the removed filters using fine bristles. Do not immerse or wash the filters in
water or other liquids.
4. Clean the cartridges every month or more often (depending on the frequency of use). If any of the
cartridges is too dirty or damaged, replace it with a new one.
5. After cleaning, reinstall the filters, install the cover (10), close the dust bag (14) and close the dust
bag cover (5).

CLEANING AND MAINTENANCE

1. Periodically clean the vacuum cleaner housing and other external elements with a damp cloth. This
will allow maintaining good appearance of the appliance.
2. For this purpose, do not use sharp objects or any strong detergents (e.g. solvents), as this will cause
permanent damage to the vacuum cleaner housing.
3. For air filters and dust bag, follow the above instructions.
IN CASE OF FAILURE
Failure type:
front cover not thoroughly closed
vacuum cleaner housing overheating
low suction power
11
Possible causes:
dust bag not attached or attached
improperly
a slight housing temperature increase is normal, but if the temperature increases
considerably, immediately turn off the vacuum cleaner and contact the service
strongly contaminated filters
full dust bag
blocked hose or extension pipe
Instructions:
attach the dust bag properly
clean or replace the filters
replace the dust bag or empty the textile
bag
remove all items blocking the hose or pipe
