TROUBLESHOOTING GUIDE - DF2608, DF2622
PROBLEm
General
Circuit breaker trips or fuse
blows when unit is turned on
Unit turns on or off by itself
Lights dim in room while the
unit is on
Power cord gets warm
Fireplace seems dark
appearance
Fireplace does not turn on
Manually
Fireplace does not turn on us-
ing the Remote Control
Flame Frozen
Flame not bright or flame not
visible
Log set dim, not glowing
(DF2608 Only)
Flame Shutter
Light leaking around the log set Log set not positioned properly
CaUSE
Short in unit wiring.
Improper circuit current rating
Remote Control has a similar frequen-
cy to other remotes in the area.
Radio frequency disturbance from
outside sources.
Defective Remote Control Receiver
Unit is drawing close to circuit current
rating
Normal Operation
Defective Power Cord
Improper operation
Defective Light Dimmer
Improper operation
No incoming power from the electrical
wall socket
Defective 3-Position Switch
Improper operation
Remote Control not initialized to fire-
place
Remote Control not working
Loose wiring
Defective Flicker Motor
Defective Flame Speed Control
Burnt out light bulbs
Loose wiring
Defective Light Harness
Loose wiring
Defective Log Driver Controller
Defective Log Set
Defective Flicker Motor
SOLUTION
Trace wiring in unit.
Additional appliances may exceed the current
rating of the circuit breaker or fuse. Plug unit into
another outlet or install unit on a dedicated 15
amp circuit.
Replace Remote Control. Initialize to Remote
Control Receiver.
Replace Remote Control. Initialize Remote Con-
trol and Receiver.
Replace Remote Control Receiver. Initialize
Remote Control and Receiver.
Move the unit to another outlet or install unit on a
dedicated 15 amp circuit
The power cord may get slightly warm to the
touch when the heater is on
Replace Power Cord if cord gets hot to the
touch.
Refer to Operation Section
Replace Light Dimmer Components
Refer to Operation Section
Check fuse/breaker panel
Replace 3-Position Switch
Refer to Operation Section
Initialize the Remote Control
Install new battery into the Remote Control. Ini-
tialize Remote Control.
Replace Remote Control Receiver or Remote
Control, where necessary. Initialize Remote
Control and Remote Control Receiver.
Check wiring connections
Replace Flicker Motor
Replace Flame Speed Control Components
Replace light bulbs
Check wiring connections
Replace Light Harness
Check wiring connections
Replace Log Driver Controller
Replace Log Set
Replace Flicker Motor
Check log set for proper fit
