  • Page 1 Technical Support and E-Warranty Certificate www.vevor.com/support WET TILE SAW MODEL:TC180II We continue to be committed to provide you tools with competitive price. "Save Half", "Half Price" or any other similar expressions used by us only represents an estimate of savings you might benefit from buying certain tools with us compared to the major top brands and doses not necessarily mean to cover all categories of tools offered by us.
  • Page 2 CustomerService@vevor.com This is the original instruction, please read all manual instructions carefully before operating. VEVOR reserves a clear interpretation of our user manual. The appearance of the product shall be subject to the product you received. Please forgive us that we won't inform you again if...
  • Page 3 Symbol description Warning - To reduce the risk of injury, user must read instructions manual carefully. This symbol, placed before a safety comment, indicates a kind of precaution, warning, or danger. Ignoring this warning may lead to an accident. To reduce the risk of injury, fire, or electrocution, please always follow the recommendation shown below.

  • Page 4: Table Of Contents

    CONTENTS 1. INTENDED USE FOR THE WET TILE SAW 2. SAFETY INSTRUCTIONS 3. DESCRIPTION 4. TECHNICAL DATA 5. BEFORE STARTING THE EQUIPMENT 6. ASSEMBLY 7. OPERATION 8. MAINTENANCE 9. TROUBLE SHOOTING 10. DISPOSAL AND RECYCLING 11. EXPLODED VIEW 12. PART LIST 13.

  • Page 5: Intended Use For The Wet Tile Saw

    1. INTENDED USE FOR THE WET TILE SAW This machine is designed for sawing cutting brick, stone, oor- and wall tiles, etc. The machine is not for the professsional version of use. Machining of other materials is not permitted and may be carried out in speci c cases only after consulting with the manufacturer.
  • Page 6 e) When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric shock. f) If operating a power tool in a damp location is unavoidable, use a residual current device (RCD) protected supply.
  • Page 7 2.2 ADDITIONAL SAFETY INSTRUCTIONS • Ensure that the directional arrow on the cutting disc imatches the directional arrow on the machine (the motor’s rotating direction). • No other people should be in the immediate vicinity of the machine when you are using it. Bystanders must be kept at an appropriate safe distance.

  • Page 8: Description

    WARNING ! Read all the safety information and instructions. Failure to adhere to the safety information and instructions set out below may result in electric shock, re and/or serious injury. Keep all the safety information and instructions in a safe place for future use.

  • Page 9: Technical Data

    4. TECHNICAL DATA Voltage 120V ~ , 6 Amperage No load speed 3500RMP Machine Table Cutting blade diameter ø180 mm Blade bore diameter ø22. 2 mm 1-1/4 in. Maximum Cutting Depth at 90° 3/4 in. Maximum Cutting Depth at 45° 0°- 45°...
  • Page 10 6. ASSEMBLY WARNING ! Pull out the power plug before assembling, adjusting and changing the cutting disc. MOUNTING THE CUTTING BLADE • Attach the staight wrench to the hex nut. • Use angle wrench to lock the motor shaft. • Loosen the hex nut, remove it and outer flange. •...

  • Page 11: Operation

    7. OPERATION ON/OFF SWITCH WARNING! Before starting: • Ensure that there are no visible defects. • Ensure that there is nothing in the work area that may hamper the work to be performed. • Ensure that there is sufficient cooling water. •...

  • Page 12: Maintenance

    TO CHANGE WATER • Unplug tile saw. • Pull out the water tank and empty into a bucket, do not allow water to splash onto ground or around machine. • Discard waste water in accordance with local regulations. CHANGING THE CUTTING BLADE Remove the water tank, then undo the two screws holding the lower blade cover and remove the blade cover so that the blade is accessible.

  • Page 13: Trouble Shooting

    9. TROUBLE SHOOTING Motor doesn’t start - No electricity, check mains. - Defective switch, motor or cord, consult an electrician. - Overload has reacted-Wait and start again. Machine vibrates excessively - Stand on uneven oor, adjust stand for even support. - Dust on saw anges, clean saw arbor and anges.
  • Page 14 11. EXPLODED VIEW...

  • Page 15: Part List

    12. PART LIST Wet Tile Saw Part List Description Description Fixed sheet Water tank Guide Blade Working table Motor Safeguard support Nut M12 Roll frame Screw M5x8 Steel board frame Screw M4x10 Strengthen board Miter gauge Inner ange Scale label (A) Outer ange Hex Nut Pointer...
  • Page 16 Technical Support and E-Warranty Certificate www.vevor.com/support...
