- Page 1 08.2019 Elastomer Jaw Couplings RINGFEDER TNS S-St, TNS S-LSt ® Installation and Operation Manual TNS S-St TNS S-LSt Partner for Performance www.ringfeder.com...
-
Page 2: Table Of Contents
The coupling shall be operated, mounted, maintained and repaired by authorized, trained and instructed personnel only. In the interest of further development, we reserve the right to carry out modifications serving the technical progress. ® BAWS 001-GBR-1 RINGFEDER TNS S-St, TNS S-LSt - 2 -... -
Page 3: Technical Description
TRANSMISSION. 2 Technical Description The RINGFEDER® TNS S-St / TNS S-LSt coupling is a torsionally flexible, puncture proof claw coupling. It compensates for angular, radial and axial shaft misalignments within defined limits. The coupling transmits torque through elastic buffers loaded in shear. These buffers come in Perbunan (Pb) or polyurethane (Vk), as standard in Vulkollan red (VkR), and are connected to each other to form a buffer ring. -
Page 4: Coupling Marking
The coupling parts can be stored in the delivered state in a dry place under roof at normal ambient temperatures for a time period of 6 months. Storage for a longer period requires the application of a long-term preservation. (Please consult RINGFEDER POWER TRANSMISSION in this respect.) The buffer rings must not be exposed to ozonic media, direct sun light or intensive light sources with UV light. -
Page 5: Construction
5 Construction 1 Coupling hub S-St, part 200 1L Long hub S-LSt, part 210 Elastic buffer ring, part 020 Construction RINGFEDER TNS S-St / TNS S-LStt ® Fig. 1 ® BAWS 001-GBR-1 RINGFEDER TNS S-St, TNS S-LSt - 5 -... -
Page 6: Technical Data
6 Technical Data RINGFEDER TNS S-St / TNS S-LStt ® Fig. 2 Table 1 Technical Data: Size Knom Kmax Knom Kmax Knom Kmax Knom Kmax Knom Kmax S-St Pb72 Pb72 Pb82 Pb82 Vk60D Vk60D S-LSt [rpm] [Nm] [Nm] [Nm] [Nm]... - Page 7 S depending on the service conditions. For circumferential speeds above 22 m/s, referred to the nominal size of the coupling, we recommend balancing the steel parts of the coupling. ® BAWS 001-GBR-1 RINGFEDER TNS S-St, TNS S-LSt - 7 -...
-
Page 8: Installation
• Select the bore fit so that an interference fit such as H7/m6 results when mating it with the shaft tolerance. • Axially lock the hub by means of a setscrew on the back of the hub above the keyway. Consult RINGFEDER POWER TRANSMISSION in case of other shaft-hub connections. ® BAWS 001-GBR-1... -
Page 9: Coupling Installation
• Mount the coupling hubs in the proper position on the shaft ends (Fig. 3, pos.2) Fig. 3 ® BAWS 001-GBR-1 RINGFEDER TNS S-St, TNS S-LSt - 9 -... - Page 10 • Push the shaft ends with the mounted coupling halves together. (Fig. 5). • Align the coupling in accordance with the instructions given in chapter 8 ‘Coupling Alignment’. Fig. 5 ® BAWS 001-GBR-1 RINGFEDER TNS S-St, TNS S-LSt - 10 -...
-
Page 11: Coupling Alignment
® BAWS 001-GBR-1 RINGFEDER TNS S-St, TNS S-LSt - 11 -... -
Page 12: Angular Misalignment ∆K
• The values of table 3 are valid for a reference rotation speed of 1500 min Fig. 7 Table 3 Maximum permissible radial misalignment values: Size ∆K [mm] r max ® BAWS 001-GBR-1 RINGFEDER TNS S-St, TNS S-LSt - 12 -... -
Page 13: Axial Misalignment
4. ATTENTION! Consult RINGFEDER POWER TRANSMISSION if larger axial misalignments are expected during operation. Fig. 8 Table 4 Recommended axial alignment values: Size [mm] [mm] 16,5 22,5 27,5 31,5 ® BAWS 001-GBR-1 RINGFEDER TNS S-St, TNS S-LSt - 13 -... -
Page 14: Operation
When operating the coupling, its specific technical data have to be carefully observed (see chapter 6 ‘Technical Data’). These values must never be exceeded without the prior written approval by RINGFEDER POWER TRANSMISSION. In order to ensure trouble-free and reliable performance of the coupling, the coupling has to be designed according to the selection specifications, e.g. - Page 15 Check coupling parts for damages products buffers deterio- and replace parts, if necessary rate. The nego- Replace elastomer tiability is dero- Verify alignment of coupling gated. Prevent contact with aggressive products ® BAWS 001-GBR-1 RINGFEDER TNS S-St, TNS S-LSt - 15 -...
- Page 16 Disconnect drive due to too destroyed. Verify coupling design in cooperation with RINGFEDER POWER high torque Enclosed aggre- TRANSMISSION gates may be affected. Replace coupling Install larger coupling, if necessary ® BAWS 001-GBR-1 RINGFEDER TNS S-St, TNS S-LSt - 16 -...
-
Page 17: Maintenance
10 Maintenance The flexible couplings RINGFEDER TNS S-St / TNS S-LSt only require little maintenance ® during operation. The elastic buffer ring is subject to wear. The time at which the wear limit of the elastic buffer ring is reached depends on the service parameters and application conditions. -
Page 18: Wear Inspection While The Equipment Is At Standstill
Size [mm] 11,4 11,7 11,4 12,7 13,8 13,6 14,3 15,4 15,3 12,1 12,1 15,4 Upon completion of the wear measurement, re-install all the protective devices and covers. ® BAWS 001-GBR-1 RINGFEDER TNS S-St, TNS S-LSt - 18 -... -
Page 19: Replacement Of The Buffer Ring
The cover must not touch the coupling and impair the proper operation of the coupling. We do not assume any responsibility or warranty for any damages resulting from the use of accessories or spare parts, which have not originally been manufactured by RINGFEDER POWER TRANSMISSION. 11 Disposal Disposal of the parts must be arranged in accordance with the regulations and laws of the country where the equipment is installed. - Page 20 RINGFEDER POWER TRANSMISSION INDIA PRIVATE LIMITED Plot No. 4, Door No. 220, Mount - Poonamallee Road, Kattupakkam, Chennai – 600 056, India Phone: +91 (0) 44-2679 1411 · Fax: +91 (0) 44-2679 1422 · E-mail: sales.india@ringfeder.com KUNSHAN RINGFEDER POWER TRANSMISSION COMPANY LIMITED NO.
