Summary of Contents for RINGFEDER TNM H
- Page 1 08.2019 Elastomer Jaw Couplings RINGFEDER TNM H ® Installation and Operation Manual Partner for Performance www.ringfeder.com...
-
Page 2: Table Of Contents
The brake disk is ® - 2 - BAWN 007-GBR-1 RINGFEDER TNM H... -
Page 3: Function
The coupling must only be operated in normal industrial atmospheres. Since aggressive media may attack the coupling components, screws and elastic buffer rings, they repre- sent a risk for the operational safety of the coupling. Consult RINGFEDER POWER TRANSMISSION in such cases. -
Page 4: Storage
The coupling parts can be stored in their delivered standard-state for 6 months in a dry, roofed place at normal room temperature. For a longer storage duration a long-term preser- vation is necessary (consult RINGFEDER POWER TRANSMISSION). The elastic intermediate ring must not be subjected to ozone containing mediums, direct solar influence or strong light sources with ultraviolet-light. -
Page 5: Construction
2 Locking washer (caging-washer) 3 Flange hub part 105 4 Removable intermediate piece part 112-118 5 Elastic intermediate ring part 010 Fig. 1 Construction RINGFEDER TNM H ® Reference: Flange hubs (Pos. 3) and removable intermediate piece (Pos. 4) are always delivered screwed together. -
Page 6: Technical Data
6 Technical data Fig. 2 RINGFEDER TNM H ® Table 1 Technical data: Size z x M x Ls Cnom Cpeak Cnom Cpeak Pb72 Pb72 Pb82 Pb82 [Nm] [Nm] [Nm] [Nm] [min [mm] [mm] [mm] [mm] [mm] 10000 4 x M 6 x 20... -
Page 7: Assembly
‘Technical Data’ are not exceeded. • The maximum permissible bore diameters must not be exceeded. • Check whether the shaft-hub connections safely transmit the occurring operating torques. • The standard tolerance of RINGFEDER TNM for finish bores is fit H7. ®... -
Page 8: Finished Borehole
H7/m6 is made. • Provide an axial securing of the hub, where appropriate with a setscrew on the hub back above the parallel key slot. In the case of other shaft hub connections consultation with RINGFEDER POWER TRANSMISSION is necessary. •... -
Page 9: Installing Coupling
Pay attention to possible differing agreements! • Secure possible available set- screws when tightening with an adhesive e.g. Loctite 222 against automatic loosening and flying out. Fig. 4 ® - 9 - BAWN 007-GBR-1 RINGFEDER TNM H... - Page 10 Fig. 6 Table 2 Tightening torques M of the bush screw fitting: Size DIN 912- 8.8 M6 M10 M10 M10 M10 DIN 912-10.9 M12 M12 M14 M14 M16 M16 M16 [Nm] ® - 10 - BAWN 007-GBR-1 RINGFEDER TNM H...
-
Page 11: Adjusting Coupling
If the coupling is mounted in a closed housing / casing so that a subsequent alignment is not possible any more, it must be guaranteed that the geometry and fit accuracy of the contact surfaces in operation aligns the shafts exactly within the mentioned tolerances. ® - 11 - BAWN 007-GBR-1 RINGFEDER TNM H... -
Page 12: Angular Misalignment ∆K
• The values in table 4 are valid for a reference rotation speed of 1500 min Fig. 8 Table 4 Maximum permissible displacement values - radial: Size ∆K [mm] r max ® - 12 - BAWN 007-GBR-1 RINGFEDER TNM H... -
Page 13: Axial Displacement
If the installation dimension re- mains under S the intermediate pieces can not be lifted out! If during operation greater axial displacements are expected, then consultation with RINGFEDER Fig. 9 POWER TRANSMISSION is necessary. Table 5 Recommended alignment values - axial:... -
Page 14: Operation
When using the coupling, attention is to be paid to its rating (see “6 Technical data"). This cannot in no case be exceeded without written permission from RINGFEDER POWER TRANSMISSION. In order to ensure a faultless, lasting operation of the coupling, it must be laid out according to the instructions e.g. - Page 15 Inspect elastomer for wear forces act on connected ma- chines. Unacceptable Material properties Disconnect drive temperatures of elastic buffers Replace elastomer change. The torque Re-align coupling transmission Adjust ambient temperature capability is adversely affected. ® - 15 - BAWN 007-GBR-1 RINGFEDER TNM H...
- Page 16 Overload Coupling is Disconnect drive due to too destroyed. Con- Verify coupling design in coopera- high torque nected machines tion with RINGFEDER POWER can be affected, TRANSMISSION too. Replace coupling Install larger coupling, if necessary ® - 16 - BAWN 007-GBR-1...
-
Page 17: Sense Of Rotation Test
(e.g. Talcum). Attention! The bearing surfaces of the reduction sleeves and flange hubs must be clean, dry and grease-free. Balanced parts are position marked to each other. ® - 17 - BAWN 007-GBR-1 RINGFEDER TNM H... - Page 18 Fig. 11 Table 7 Tightening torques M of the sleeve threaded joints: Size DIN 912- 8.8 M10 M10 M10 M10 DIN 912-10.9 M12 M12 M14 M14 M16 M16 M16 [Nm] ® - 18 - BAWN 007-GBR-1 RINGFEDER TNM H...
-
Page 19: Maintenance
10 Maintenance The elastic coupling RINGFEDER TNM H has in operation a low-maintenance. ® Reaching the wear limit of the elastic intermediate ring depends on the operating parameters and the conditions of use. In the case of routine monitoring work on the plant check: •... -
Page 20: Wear Limit Of Elastic Buffers
• For easier mounting, the new intermediate ring can be provided with Fig. 13 a slip additive before introduction (e.g. Talcum). • Install the new intermediate ring. ® - 20 - BAWN 007-GBR-1 RINGFEDER TNM H... -
Page 21: Waste Disposal
The covering must not touch the coupling or influence it in its function. In the case of use of accessories and spare parts, which were not originally manufactured by RINGFEDER POWER TRANSMISSION, no liability or guarantee will be accepted for any resulting damage. 11 Waste Disposal The waste disposal has to occur according to the specific regulations of the respective user country. - Page 22 RINGFEDER POWER TRANSMISSION INDIA PRIVATE LIMITED Plot No. 4, Door No. 220, Mount - Poonamallee Road, Kattupakkam, Chennai – 600 056, India Phone: +91 (0) 44-2679 1411 · Fax: +91 (0) 44-2679 1422 · E-mail: sales.india@ringfeder.com KUNSHAN RINGFEDER POWER TRANSMISSION COMPANY LIMITED NO.
