Summary of Contents for RINGFEDER TNS SX
- Page 1 08.2019 Elastomer Jaw Couplings RINGFEDER ® TNS SX Installation and Operation Manual Partner for Performance www.ringfeder.com...
-
Page 2: Table Of Contents
The coupling shall be operated, mounted, maintained and repaired by authorized, trained and instructed personnel only. In the interest of further development, we reserve the right to carry out modifications serving the technical progress. BAWS 010-GBR-1 RINGFEDER ® TNS SX - 2 -... -
Page 3: Technical Description
• The coupling must only be operated in normal industrial atmospheres. Since aggressive media may attack the coupling components, screws and elastic buffer rings, they repre- sent a risk for the operational safety of the coupling. Consult RINGFEDER POWER TRANSMISSION in such cases. -
Page 4: Coupling Marking
The coupling parts can be stored in the delivered state in a dry place under roof at normal ambient temperatures for a time period of 6 months. Storage for a longer period requires the application of a long-term preservation. (Please consult RINGFEDER POWER TRANSMISSION in this respect.) The buffer rings must not be exposed to ozonic media, direct sun light or intensive light sources with UV light. -
Page 5: Construction
5 Construction Fig. 1 1 Coupling hub, part 200, long hub L, part 210 2 Elastic buffer ring, part 020 3 Coupling flange, part 230, made of aluminium as a standard BAWS 010-GBR-1 RINGFEDER ® TNS SX - 5 -... -
Page 6: Technical Data
6 Technical Data Fig. 2 RINGFEDER TNS SX ® Table 1 Technical Data: Size Knom Kmax Kmax Knom Kmax Knom Kmax Pb72 Pb72 Pb82 Pb82 unbored [min [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [kg] 7250 6000 5250 1200... - Page 7 S depending on the service conditions. For circumferential speeds above 22 m/s, referred to the nominal size of the coupling, we recommend balancing the steel parts of the coupling. BAWS 010-GBR-1 RINGFEDER ® TNS SX - 7 -...
-
Page 8: Installation
‘Technical Data’ are not exceeded. • The maximum permissible bore diameters must not be exceeded. • Check whether the shaft-hub connections safely transmit the occurring operating torques. • The standard tolerance of RINGFEDER TNS for finish bores is fit H7. ®... -
Page 9: Finish Bores
• Axially lock the hub, for example by means of a setscrew on the back of the hub above the keyway Consult RINGFEDER POWER TRANSMISSION in case of other shaft-hub connections. • The stated maximum bore diameters are valid for keyed connec- tions according to DIN 6885/1 and must not be exceeded. -
Page 10: Coupling Installation
• Mount the aluminium coupling flange to the flange connection. When join- ing the parts, take care that they do not get canted at the centering seat. (Fig. 3, pos. 2). Fig. 4 BAWS 010-GBR-1 RINGFEDER ® TNS SX - 10 -... -
Page 11: Coupling Alignment
50 % only when aligning the coupling, so as to have sufficient reserves for thermal growth, foundation settlings etc. during service. In special applications with high demands on quiet running characteristics or higher BAWS 010-GBR-1 RINGFEDER ® TNS SX - 11 -... -
Page 12: Angular Misalignment
2. • The values are applicable for a reference speed of 1500 rpm. Fig. 6 Table 2 Maximum permissible angular misalignment values: Size 100 125 145 170 200 ∆Kw [mm] BAWS 010-GBR-1 RINGFEDER ® TNS SX - 12 -... -
Page 13: Radial Misalignment
• The dimension of h must be in bet- ween the values h and h stated in table 4. ATTENTION! Consult RINGFEDER POWER TRANSMISSION if larger axial misalignments are expected during operation. Fig. 8 Table 4 Recommended axial alignment values:... -
Page 14: Operation
When operating the coupling, its specific technical data have to be carefully observed (see chapter 6 ‘Technical Data’). These values must never be exceeded without the prior written approval by RINGFEDER POWER TRANSMISSION. In order to ensure trouble-free and reliable performance of the coupling, the coupling has to be designed according to the selection specifications, e.g. - Page 15 Inspect elastomer for wear forces act on connected ma- chines. Unacceptable Material properties Disconnect drive temperatures of elastic buffers Replace elastomer change. The torque Re-align coupling transmission Adjust ambient temperature capability is adversely affected. BAWS 010-GBR-1 RINGFEDER ® TNS SX - 15 -...
- Page 16 Overload Coupling is Disconnect drive due to too destroyed. Con- Verify coupling design in coopera- tion with RINGFEDER POWER high torque nected machines TRANSMISSION can be affected, too. Replace coupling Install larger coupling, if necessary BAWS 010-GBR-1 RINGFEDER ®...
-
Page 17: Maintenance
10 Maintenance The flexible coupling RINGFEDER TNS SX only requires little maintenance during ® operation. The elastic buffer ring is subject to wear. The time at which the wear limit of the elastic buffer ring is reached depends on the service parameters and application conditions. -
Page 18: Wear Inspection - Equipment At Standstill
Size [mm] 11,5 12,7 13,8 13,6 14,3 15,4 15,3 12,1 12,1 15,4 Upon completion of the wear measurement, re-install all the protective devices and covers. BAWS 010-GBR-1 RINGFEDER ® TNS SX - 18 -... -
Page 19: Replacement Of Buffer Ring
The cover must not touch the coupling and impair the proper operation of the coupling. We do not assume any responsibility or warranty for any damages resulting from the use of accessories or spare parts, which have not been originally manufactured by RINGFEDER POWER TRANSMISSION. 11 Disposal Disposal of the parts must be arranged in accordance with the regulations and laws of the country where the equipment is installed. - Page 20 RINGFEDER POWER TRANSMISSION INDIA PRIVATE LIMITED Plot No. 4, Door No. 220, Mount - Poonamallee Road, Kattupakkam, Chennai – 600 056, India Phone: +91 (0) 44-2679 1411 · Fax: +91 (0) 44-2679 1422 · E-mail: sales.india@ringfeder.com KUNSHAN RINGFEDER POWER TRANSMISSION COMPANY LIMITED NO.
