- Page 1 08.2019 Elastomer Jaw Couplings RINGFEDER TNM LG ® Installation and Operation Manual Partner for Performance www.ringfeder.com...
-
Page 2: Table Of Contents
The brake disk is ® BAWN 009-GBR-1 RINGFEDER TNM LG - 2 -... -
Page 3: Technical Description
• The coupling must only be operated in normal industrial atmospheres. Since aggressive media may attack the coupling components, screws and elastic buffer rings, they repre- sent a risk for the operational safety of the coupling. Consult RINGFEDER POWER TRANSMISSION in such cases. -
Page 4: Storage
The coupling parts can be stored in their delivered standard-state for 6 months in a dry, roofed place at normal room temperature. For a longer storage duration a long-term preser- vation is necessary (consult RINGFEDER POWER TRANSMISSION). The elastic intermediate ring must not be subjected to ozone containing mediums, direct solar influence or strong light sources with ultraviolet-light. -
Page 5: Technical Data
6 Technical Data Fig. 2 RINGFEDER TNM LG ® Table 1 Technical Data: Size Knom. Kmax Knom. Kmax Pb72 Pb72 Pb82 Pb82 [Nm] [Nm] [Nm] [Nm] [rpm] 8000 7000 6000 5000 1350 4500 1300 1800 4000 1050 2000 1650 2400... - Page 6 Sz depending on the frequency of starts, the shock factor S depending on the service conditions. For circumferential speeds above 22 m/s, we recommend to balance the coupling. ® BAWN 009-GBR-1 RINGFEDER TNM LG - 6 -...
-
Page 7: Installation
• Select the bore fit so that an interference fit such as H7/m6 results when mating it with the shaft tolerance. • Axially lock the hub, for example by means of a setscrew on the back of the hub above the keyway Contact RINGFEDER POWER TRANSMISSION if other shaft-hub connections are used. ® BAWN 009-GBR-1 RINGFEDER... -
Page 8: Coupling Installation
(Fig. 4, pos. 2). Fig. 4 Note: To facilitate mounting, the hub can be heated to 80° C to 120° C. Take care for uniform heating. ® BAWN 009-GBR-1 RINGFEDER TNM LG - 8 -... - Page 9 Push together the shaft end with the mounted coupling half and the coupling flange (Fig. 6). • Align the coupling in accordance with the instructions given in chap- ter 8 'Coupling Alignment’. Fig. 6 ® BAWN 009-GBR-1 RINGFEDER TNM LG - 9 -...
-
Page 10: Coupling Alignment
® BAWN 009-GBR-1 RINGFEDER TNM LG - 10 -... -
Page 11: Angular Misalignment ∆K
• The values of table 6 are valid for a reference speed of 1500 rpm. Fig. 8 Table 6 Maximal permissible radial misalignment values: Size ∆K [mm] r max ® BAWN 009-GBR-1 RINGFEDER TNM LG - 11 -... -
Page 12: Axial Misalignment
Fig. 9. • During alignment, observe the gap dimension S and the maximum permissible tolerance X according to table 7. ATTENTION! Contact RINGFEDER POWER TRANSMISSION if larger axial misalignments are expected to occur during operation. Fig. 9 Table 7... -
Page 13: Operation
When operating the coupling, its specific technical data has to be carefully observed (see chapter 6 ‘Technical Data’). These values must never be exceeded without the prior written approval by RINGFEDER POWER TRANSMISSION.In order to ensure trouble-free and reliable performance of the coupling, the coupling has to be designed according to the selection specifications, e.g. - Page 14 Check coupling parts for damages products change. The torque and replace parts, if necessary transmission capabil- Replace elastic buffers ity is adversely Verify alignment of coupling affected. Prevent contact with aggressive products ® BAWN 009-GBR-1 RINGFEDER TNM LG - 14 -...
- Page 15 Overload Coupling is de- Disconnect drive due to too stroyed. Connected Verify coupling design in coopera- tion with RINGFEDER POWER high torque machines ca also be TRANSMISSION affected. Replace coupling Install larger coupling, if necessary ® BAWN 009-GBR-1...
-
Page 16: Check Of Direction Of Rotation
• The coupling half with the retracted claw ring must be stationary when checking the direction of rotation. • The rotating half must not contact the stationary half! ® BAWN 009-GBR-1 RINGFEDER TNM LG - 16 -... - Page 17 Table 9 Tightening torques M of the claw ring screws: Size 112 128 DIN 912- 8.8 M10 M10 M10 DIN 912-10.9 M12 M12 M14 M14 M16 M16 M16 M20 M20 [Nm] ® BAWN 009-GBR-1 RINGFEDER TNM LG - 17 -...
-
Page 18: Maintenance
10 Maintenance The RINGFEDER TNM LG couplings only require little maintenance. The time at which the ® wear limit of the elastic buffers is reached, depends on the service parameters and application conditions. On the occasion of routine inspections or maintenance of the equipment, check: •... -
Page 19: Wear Limit Of The Buffer Ring
(e.g. talcum). • Cut through a new buffer ring at one of the connecting webs and insert it be- tween the coupling flange and the flange hub. Fig. 13 ® BAWN 009-GBR-1 RINGFEDER TNM LG - 19 -... -
Page 20: Waste Disposal
The covers must not touch the coupling nor impair its function. We do not assume any liability or warranty for any damages resulting from the use of acces- sories or parts which have not been originally manufactured by RINGFEDER POWER TRANSMISSION. - Page 21 RINGFEDER POWER TRANSMISSION INDIA PRIVATE LIMITED Plot No. 4, Door No. 220, Mount - Poonamallee Road, Kattupakkam, Chennai – 600 056, India Phone: +91 (0) 44-2679 1411 · Fax: +91 (0) 44-2679 1422 · E-mail: sales.india@ringfeder.com KUNSHAN RINGFEDER POWER TRANSMISSION COMPANY LIMITED NO.
