Elastomer Jaw Couplings
RINGFEDER
TNM G
®
Installation and Operation Manual
Partner for Performance
www.ringfeder.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TNM G and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for RINGFEDER TNM G

  • Page 1 08.2019 Elastomer Jaw Couplings RINGFEDER TNM G ® Installation and Operation Manual Partner for Performance www.ringfeder.com...
  • Page 2: Table Of Contents

    The brake disk is ® BAWN 002-GBR-2 RINGFEDER TNM E - 2 -...
  • Page 3: Function

    The coupling must only be operated in normal industrial atmospheres. Since aggressive media may attack the coupling components, screws and elastic buffer rings, they represent a risk for the operational safety of the coupling. Consult RINGFEDER POWER TRANSMISSION in such cases.
  • Page 4: Marking Of The Coupling

    The coupling parts can be stored in their delivered standard-state for 6 months in a dry, roofed place at normal room temperature. For a longer storage duration a long-term preser- vation is necessary (consult RINGFEDER POWER TRANSMISSION). The elastic intermediate ring must not be subjected to ozone containing mediums, direct solar influence or strong light sources with ultraviolet-light.
  • Page 5: Construction

    3 Claw ring part 102 4 Flange hub part 104 5 Elastic intermediate ring part 010 6 Coupling hub part 101 Fig. 1 Construction RINGFEDER ® TNM G Details: Claw ring (Pos. 3) and flange hub (Pos. 4) are delivered screwed together.
  • Page 6: Technical Data

    6 Technical data Fig. 2 RINGFEDER ® TNM G Table 1 Technical data: Size Cnom Cpeak Cnom Cpeak Pb72 Pb72 Pb82 Pb82 [Nm] [Nm] [Nm] [Nm] [mm] [mm] [mm] [min 8000 7000 6000 5000 1350 4500 1300 1800 4000 1050...
  • Page 7 Sz in dependence of the operating conditions an impact factor, S With circumferential speeds of more than 22 m/s, we recommend to balance the coupling. ® BAWN 002-GBR-2 RINGFEDER TNM E - 7 -...
  • Page 8: Assembly

    „Technical Data‟ are not exceeded.  The maximum permissible bore diameters must not be exceeded.  Check whether the shaft-hub connections safely transmit the occurring operating torques.  The standard tolerance of RINGFEDER TNM for finish bores is fit H7. ®...
  • Page 9: Finished Borehole

    H7/m6 is carried out.  Provide a setscrew for axial securing on the hub back above the parallel key slot. In the case of other shaft hub connections consultation with RINGFEDER POWER TRANSMISSION is necessary.
  • Page 10: Installing Coupling

    (Figure 4). Pay attention to possible differing agreements!  Secure possible available setscrews by tightening with an adhesive e.g. Loctite 222 against automatic loos- ening and flying out. Fig. 4 ® BAWN 002-GBR-2 RINGFEDER TNM E - 10 -...
  • Page 11  Push the shaft ends with the mounted coupling halves together (Figure 5).  Adjust the coupling according to the following specifications in “8 Cou- pling adjustment”. Fig. 5 ® BAWN 002-GBR-2 RINGFEDER TNM E - 11 -...
  • Page 12: Adjusting Coupling

    If the coupling is mounted in a closed housing / casing so that a subsequent alignment is not possible any more, it must be guaranteed that the geometry and fit accuracy of the contact surfaces in operation aligns the shafts exactly within the mentioned tolerances. ® BAWN 002-GBR-2 RINGFEDER TNM E - 12 -...
  • Page 13: Angular Misalignment K

    1500 min Fig. 7 Table 3 Maximum permissible displacement values - radial: Size 112 128 148 168 194 214 240 265 295 330 370 415 480 575 K [mm] r max ® BAWN 002-GBR-2 RINGFEDER TNM E - 13 -...
  • Page 14: Axial Displacement

     Keep, when aligning the gap measurement S, to the maximum permissible tolerance X according to table 4. ATTENTION! If greater axial displacements are expected in operation, consultation with RINGFEDER POWER TRANSMISSION is necessary. Fig. 8 Table 4 Recommended alignment values - axial: Size [mm] X [mm] ±1...
  • Page 15: Operation

    When using the coupling attention is to be paid to its characteristics (see „6 Technical data”). These can in no case be exceeded without having a written agreement from RINGFEDER POWER TRANSMISSION. In order to guarantee a faultless, lasting operation of the coupling, it must be laid out accord-ing to the regulations e.g.
  • Page 16 Alignment fault Considerable Disconnect drive wear of increase in Remove cause for alignment fault elastomer coupling tempera- Re-align coupling ture. Increased Inspect elastomer for wear reaction forces act on connected machines. ® BAWN 002-GBR-2 RINGFEDER TNM E - 16 -...
  • Page 17 Overload Coupling is Disconnect drive due to too destroyed. Verify coupling design in coopera- high torque Connected tion with RINGFEDER POWER machines can be TRANSMISSION affected, too. Replace coupling Install larger coupling, if necessary ® BAWN 002-GBR-2 RINGFEDER TNM E...
  • Page 18: Sense Of Rotation Test

     The coupling half with the pulled back claw ring must remain stationary during the sense of rotation test.  The rotating half must not touch the stationary half! ® BAWN 002-GBR-2 RINGFEDER TNM E - 18 -...
  • Page 19 112 128 148 168 194 214 240 265 295 330 370 415 480 575 DIN 912- 8.8 M8 M10 M10 M10 DIN 912-10.9 M12 M12 M14 M14 M16 M16 M16 M20 M20 [Nm] 100 100 160 160 240 240 240 490 490 ® BAWN 002-GBR-2 RINGFEDER TNM E - 19 -...
  • Page 20: Maintenance

    10 Maintenance The elastic coupling RINGFEDER ® TNM G has in operation a low-maintenance. Reaching the wear limit of the elastic intermediate ring depends on the operating parameters and the conditions of use. In the case of routine monitoring work on the plant check: ...
  • Page 21: Wear Limit Of Elastic Buffers

    (e.g. Talcum powder).  Cut through the new intermediate ring at a connecting joint and posi- tion it between coupling flange and Fig. 12 flange hub. ® BAWN 002-GBR-2 RINGFEDER TNM E - 21 -...
  • Page 22  The covering must not touch the coupling or influence it in its functioning. When using accessories and spare parts which were not originally manufactured by RINGFEDER POWER TRANSMISSION, no liability or guarantee for any damages will be accepted. ®...
  • Page 23: Waste Disposal

    11 Waste Disposal The waste disposal has to occur according to the specific regulations of the respective user country. ® BAWN 002-GBR-2 RINGFEDER TNM E - 23 -...
  • Page 24 RINGFEDER POWER TRANSMISSION INDIA PRIVATE LIMITED Plot No. 4, Door No. 220, Mount - Poonamallee Road, Kattupakkam, Chennai – 600 056, India Phone: +91 (0) 44-2679 1411 · Fax: +91 (0) 44-2679 1422 · E-mail: sales.india@ringfeder.com KUNSHAN RINGFEDER POWER TRANSMISSION COMPANY LIMITED NO.
