Modules
4.2 Available Modules
4.2

Available Modules

A variety of modules are available for use with the RUGGEDCOM RX1512.
For more information, refer to the
support.industry.siemens.com/cs/us/en/view/109747072]" for the RUGGEDCOM
RX1512.
4.3

Installing/Removing Line Modules

Upon installing a new line module in the device, all features associated with the
module are available in RUGGEDCOM RX1512. For more information, refer to the
"RUGGEDCOM ROX II Configuration Manual" for the RUGGEDCOM RX1512.
Once a line module is removed, all the features associated with the module are
hidden or disabled in RUGGEDCOM RX1512.
Electrical hazard – risk of power failure
Do not install more than one RUGGEDCOM APE module. Installing more than one of
this type of module can lead to power fluctuations and irregular shut downs.
Contamination hazard – risk of equipment damage
Prevent the ingress of water, dirts and other debris that may lead to premature
equipment failure. Always make sure slots are not left empty and open ports are
protected with plugs or covers.
Note
Only one WAN line module is supported per chassis.
Removing a Module
To remove a line module, do the following:
1.
2.
3.
24
NOTICE
NOTICE
[Optional] If the device is installed in a rack, remove it from the rack.
Loosen the screws that secure the module.
Pull the module from the chassis to disconnect it.
"RUGGEDCOM Modules Catalog [https://
Equipment Manual, 10/2023, C79000-G8976-1057-25
RUGGEDCOM RX1512
