Installing the Device
2.3.2 Mounting the Device to a Panel
2.
2.3.2 Mounting the Device to a Panel
For panel installations, the RUGGEDCOM RX1512 can be equipped with panel/DIN rail
adapters pre-installed on each side of the chassis. The adapters allow the device to
be attached to a panel using screws.
To mount the device to a panel, do the following:
1.
10
Panel/DIN Rail Adapter
1
DIN Rail
2
Screw
3
Figure 2.1 DIN Rail Mounting
Install one of the supplied screws on either side of the device to secure the
adapters to the DIN rails.
Place the device against the panel and mark the mounting holes on the panel.
3
2
1
