Modules

The RUGGEDCOM RX1524 features slots for up to four field-replaceable line modules,
which can be used to expand and customize the capabilities of the device to suit
specific applications.
A variety of modules are available, each featuring a specific type of communication
port: copper Ethernet, fiber optic Ethernet, SFP, WAN, cellular modem and DDS.
The RUGGEDCOM APE (Application Processing Engine) line module, a utility-grade
computing platform for running third-party applications directly from within the
RUGGEDCOM RX1524, is also available.
Use the RUGGEDCOM ROX software to determine which ports are equipped on the
device. For more information, refer to the "RUGGEDCOM ROX Configuration Manual"
for the device.
4.1

Requirements and Restrictions

Before installing modules in the device, consider the following restrictions and
requirements.
Module Support
•
Figure 4.1
4.2

Available Modules

A variety of modules are available for use with the RUGGEDCOM RX1524.
For more information, refer to the
support.industry.siemens.com/cs/us/en/view/109747072]" for the RUGGEDCOM
RX1524.
RUGGEDCOM RX1524
Installation Manual, 10/2021, C79000-G8976-1487-03
Up to two RUGGEDCOM APE modules are supported
Available Chassis Slots
1 3
2 4
"RUGGEDCOM Modules Catalog [https://
