OPERATION
To Change a Passcode and Decimal Places
The AG3000 has a passcode system for restricting access
to the menus. The AG3000 comes from the factory with
the passcode set to 000000. When a user attempts to enter
the menu system (see details on page 19), the passcode
entry screen will be displayed.
ENTER PASSCODE
000000
PRESS
The default passcode is 000000. If a different passcode has
previously been set, then the user must enter that passcode
at this time. After entering the passcode, or leaving it at
1.2345678
000000 if using the default passcode, the user does the tap
and hold sequence to move into the menu system.
To change the passcode, you must use the THIRD MENU
screen. Access the THIRD MENU screen as follows:
• Enter the main menu system, as described above.
T UNIT R UNIT SET P
TOTAL = G ALLONS
PRESS +
UNIT S FOR DISPLAY
SET 4 SET 20 SET F
• On the main menu, tab over to the EXIT tab and tap
T UNIT R UNIT SET P
the five times. A SUBMENU screen will display.
T O TA L :
INFO COMM MBID
P R E S S
PRESS
SET 4 SET 20 SET F
ABOUT METER
S AMP HPOLL
• On the SUBMENU screen tab over to the EXIT tab and
tap the five times. The THIRD MENU screen will
display.
SETCD SETD PDAMP
000000
PRESS
PASSCODE
S AMP
Seametrics • 253.872.0284
AND TO CHANGE
TOTAL
CU FT
X1000
100
RATE
GPM
F O R WA R D T O TA L
DAMP
TO SET TOTAL
EXIT
DAMP
G A L L O N S
FL DIR
T O C H A N GE
+ TO VIEW INFO
EXIT
FOUT EXIT
TES T
+ T O SET
FOUT EXIT
• To set the passcode, hold and tap and then use the
and to enter the new code.
• Hold and tap again to return to the THIRD MENU
screen.
• Tab to EXIT, and then hold and tap to return to the
SUBMENU.
To change the number of decimal places in the total
• To set the decimal point, hold and tap on SETD and
then use the
• Hold and tap again to return to the Set THIRD MENU
screen.
• Tab to EXIT, and then hold and tap to return to the
SUBMENU.
PDAMP
PDAMP is used to view or change the number of samples
for rolling average of pulse output.
TEST
TEST allows the user to initiate a fully functional, artificial
flow rate for the purpose of testing other connected
equipment. When TEST is applied, all features of the
meter will function at the stated flow rate (in gallons per
second).
For TEST to function, the meter must be filled (not EMPTY
PIPE).
To enter a value into the TEST feature, navigate to the
TEST tab and enter a flow rate value in the VAL screen (in
gallons per second only,) then
to the ON screen. This will initiate the TEST feature. The
next would bring you to the OFF screen, but you can
'hold and tap' the arrows to return you to the sub menu
while the feature operates.
After use, the TEST feature must be turned OFF. If the
TEST feature is not turned OFF, the stated static flow rate
(in gallons per second) will be shown any time the meter
is full or in a flowing condition. Flow values recorded
by the meter while the TEST feature is operating are
permanently recorded in the displayed TOTAL. It may
be useful to note that these values are only written to
permanent memory every 15 minutes and cycling all
power within this 15 minute time frame will return the
meter to its previous total.
Page 21
AG3000p INSTRUCTIONS
to move the decimal point.
to the VAL box and
