Model No. SL-MR80
Mid Rise Scissor Lift
Automatic Release
Lifting Capacity 8000 lbs
mportant Note
I
1. This equipment can not be installed, operated or repaired without reading instructions.
2. Electricity must be hooked up by certified electrician.
3. Do not use this equipment beyond its rated capacity.
Questions, problems, missing parts? Before returning to your retailer,
call our customer service department at 800-616-9618
Installation & Operation &
Maintenance Instructions
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for APlusLift SL-MR80
Summary of Contents for APlusLift SL-MR80
- Page 1 Model No. SL-MR80 Installation & Operation & Maintenance Instructions Mid Rise Scissor Lift Automatic Release Lifting Capacity 8000 lbs mportant Note 1. This equipment can not be installed, operated or repaired without reading instructions. 2. Electricity must be hooked up by certified electrician.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Packing, transport and storage ............................4 Packing ..................................4 Transport ..................................4 Storage ..................................5 Technical specifications ..............................6 Equipment plan ................................7 Safety ....................................8 Important notices ............................... 8 Qualified personnel ..............................8 Danger notices .................................. 8 Training .................................. - Page 3 Descriptions of control box ............................14 Flow chart for operation ................................ 14 Operation instructions ............................15 Emergency lowering in case of no power ........................15 Troubleshooting ................................17 Maintenance ..................................19 Daily checking items before operation ........................19 Weekly checking items ............................19 Monthly checking items ............................
-
Page 4: Packing, Transport And Storage
Packing, transport and storage All packing, lifting, handling, transport and unpacking operations are to be performed exclusively by expert personnel with knowledge of the lift and the contents of this manual. Packing The packing of the lift is delivered in following components: ... -
Page 5: Storage
Storage The machine equipment should be stocked in the warehouse, if stocked outside should do the disposal well of waterproof. Use box truck in the process of transport, use container storage when shipping. The control box should be placed perpendicularly during the transport; and prevent other goods from ... -
Page 6: Technical Specifications
Technical specifications Machine model Driving mode Electro hydraulic drive Lifting capacity 8,000lbs (3,500kg) 47.24″（1200mm） Lifting Height About 50 sec Lifting time Voltage 220V/110V Frequency 60Hz power 2.2KW 46＃/68＃ Hydraulic oil 5-40℃ working temperature ambient humidity 30-95% Machine noise < 76dB(A) Equipment weight 1,631 lbs (740kg) -
Page 7: Equipment Plan
Equipment plan... -
Page 8: Safety
Safety Important notices This ultra thin low lift is specially designed for lifting motor vehicles that weighs within its outmost lifting capacity. Users are not allowed to use it for any other purposes. Otherwise, we, as well as our sales agency, will not bear any responsibility for accidents or damages of the lift. -
Page 9: Training
a. If the lift is going to left used for a long time, users are required to: b. Empty the oil tank; c. Lubricate the moving parts with hydraulic oil. Training Only these qualified people, who have been properly trained, can operate the lift. We are quite willing to provide professional training for the users when necessary. -
Page 11: Installation
Installation Only skilled technicians, appointed by the manufacturer, or by authorized dealers, must be allowed to carry out installation. Serious damage to people and to the lift can be caused if installations are made by unskilled personnel Always refer to the exploded views attached during installation. ... -
Page 12: Lighting
The installation near to rooms, where a dangerous situation of explosion can occur, is strictly forbidden. The relevant standards of the local Health and Safety at Work regulations, for instance, with respect to minimum distance to wall or other equipment, escapes and the like, must be observed. Lighting ... -
Page 13: Items To Be Checked After Installation
Step3: Connect the wires of limit switch to the wiring terminals in the control box. Make sure to connect NO.1 wire with NO.1 terminal, NO.2 wire with NO.2 terminal and so forth. Step4: Link the air hose to compressed air source. (This step is only for the type with pneumatic safety lock) Step 5: Fix the base frame. -
Page 14: Operation And Use
Operation and use Precautions Check all the joints of oil hose. Only when there is no leakage, the lift can start work. The lift, if its safety device malfunctions, shall not be used. The machine shall not lift or lower an automobile if its center of gravity is not positioned midway of the rising ... -
Page 15: Flow Chart For Operation
operation Flow chart for Start Start Turn on the power switch Turn on the power switch Press the UP button Press the DOWN button Motor drives the gear pump work The lift is lowered Cylinder piston drives the platform move up The lift is raised Operation instructions Raise the lift... -
Page 16: Emergency Lowering In Case Of No Power
Emergency lowering in case of no power The safety lock is not engaged : Tie up the safety teeth on both sides with rope; pull upward the rope making the safety teeth unlocked. Having the safety teeth unlocked, manually loose the core of electro-magnetic valve on the pump assembly. The safety lock is engaged: Screw off the fitting (opposite to the oil out-let) to connect a hand pump.(Optional) Connect the hydraulic assembly with the optional hand pump. - Page 17 Tie up the safety teeth with rope and pull up the safety teeth. Use a wrench to loose the core of the electro-magnetic valve to lower the platforms.
-
Page 18: Troubleshooting
Troubleshooting ATTENTION: If the trouble could not be fixed by yourself, please do not hesitate to contact us for help. We will offer our service at the earliest time we can. By the way, your troubles will be judged and solved much faster if you could provide us more details or pictures of the trouble. - Page 19 Remove the packages and place the lift as per the following drawing. ...
-
Page 20: Maintenance
Maintenance Easy and low cost routine maintenance can ensure the lift work normally and safely. Following are requirements for routine maintenance. You may choose the frequency of routine maintenance by consulting your lift’s working conditions and time. The Following parts need to be lubricated. ... -
Page 21: Yearly Checking Items
Yearly checking items Empty the oil tank and check the quality of hydraulic oil. Wash and clean the oil filter. If users strictly follow the above maintenance requirements, the lift will keep in a good working condition and meanwhile accidents could be avoided to a large extent. - Page 22 tenance Annex 4，Pneumatic working system Air filter Pneumatic solenoid valve Pneumatic cylinder for the main platform Driving cylinder Pneumatic cylinder for the assistant platform Assistant cylinder Hydraulic working system Electrical release valve Lowering throttle valve Motor Coupling Gear pump One-way valve Over-flowing valve 10.
- Page 23 Annex5， Wiring diagram...
- Page 24 Connection wire: Yellow Green Wire: Ground Wire Blue and Brown Wire: 1. If the supply voltage is 110V, either one can be 110V hot wire or neutral wire, which means if you want blue wire is 110V hot wire, the brown is neutral wire, if you want brown wire is 110V hot wire, the blue will be neutral wire.
- Page 25 Annex6, Separate diagrams for the lift...
- Page 26 Annex 7.Spare parts --electrical system...
- Page 27 Annex8，Size and weight requirements on vehicles Note: Offers may differ as per different requirements on the version. Model A/(inch) B/(inch) C/(inch) D/(lbs) E/(lbs) F/(lbs) G/(lbs) SAE-MS9000XT 74 13/16 114 3/16 4 5/16 5291 3527 5291 3527...
-
Page 28: Special Notes
Special notes Environmental damage Only appropriately trained personnel may dismantle and dispose of the unit. Dismantling To dismantle the product, proceed as follows: ELECTRICAL HAZARD! When carrying out any decommissioning and dismantling work on the unit, switch off all power supply connections, ensure ... - Page 29 Contact Customer Service directly by telephone at: 800-616-9618 https://www.apluslift.com...
