COMPACT COMPONENT SYSTEM
FS-SD5R/FS-SD7R/FS-SD9SR
FS-SD5R
FS-SD7R, FS-SD9R
CEC 4 22s)
INSTRUCTIONS See
Enter below the Modei No. and Senai No.
infor nation for future relerence.
Model No_
LVT0418-002A
1e/UB]
SAFETY INSTRUCTIONS
"SOME DOS AND DON'TS ON THE SAFE USE OF EQUIPMENT"
This equipment has been disigned and manufactured to meet intemational safety standards but, like any electrical
equipment, care must be taken if you are to obtain the best results and safety is to be assured.
RRR RR EEE RARER RRR REE RERRERRER EE
'Do read the operating instructions before you attempt to use the equipment
Do ensure that all electrical connections (including the mains plug, extension leads and interconnections between
Pieces of equipment) are properly made and in accordance with the manufacturer's instructions. Switch off and with-
draw the mains plug when making or changing connections.
Do consult your dealer if you are ever in doubt about the installation, operation or safety of your equipment.
Do be careful with glass panels or doors on equipment.
FIO IRIS IOI IOI SII IIIT TOIT AI STOTT A
DON'T continue to operate the equipment if you are in any doubt about it working normally, or if it is damaged in any
way-switch off, withdraw the mains plug and consult your dealer.
DON'T remove any fixed cover as this may expose dangerous voltages.
DON'T leave equipment switched on when it is unattended unless it is specificaity stated that it is designed for unat-
tended operation or has a standby mode.
'Switch off using the switch on the equipment and make sure that your family know how to do this.
Special arrangements may need to be made for infirm or handicapped people.
DON'T use equipment such as personal stereos or radios so that you are distracted trom the requirements of traffic
safety. It is illegal to watch television whilst driving.
DONT listen to headphones at high volume as such use can permanently damage your hearing.
DON'T obstruct the ventilation of the equipment, for example with curtains or soft furnishings
Overheating will cause damage and shorten the tife of the equipment.
DONT use makeshift stands and NEVER fix legs with wood screws — to ensure complete safety always fit the man-
ufacturer's approved stand or legs with the fixings provided according to the instructions.
DON'T allow electrical equipment to be exposed to rain or moisture.
ABOVE ALL
— NEVER let anyone, especially chiidren, push anything into holes, stots or any other opening in the case -
this could result in a fata! electrical shock.;
—-NEVER guess or take chances with electricat equipment of any kind
— itis better to be safe than sorry!
G-2
FS-SD5R/FS-SD7R/FS-SD9R
Warnings, Cautions and Others
IMPORTANT FOR LASER PRODUCTS
REPRODUCTION OF LABELS.
IMPORTANT for the UK
DO NOT cut off the mains plug from this equipment. # the ptug
fined is not suitable for the power points in your home or the
cable is too short to reach a power point, then obtain an appro- 1 F '
priate saloty approved extension laad or consult your doale® CLASSIFICATION LABEL, PLACED ON EXTERIOR SUR
BE SURE to replace the fuse only with an identical approved
type. as originally fined
Mf nontheless the mains pug is cut off ensure to remove the use class
and dispose of the plug immediately, to avoid a possible shock
hazard by inadvertend connection to the mains supply.
{this product is not supplied titled with a mains plug then follow
the instructions given below:
IMPORTANT:
DO NOT make any connection to the terminal which is marked
1
LASER PRODUCT
2 WARNING LABEL, PLACED INS!DE THE UNIT
with the ietter E of by the salety earth symbol of coloured green = = :
oF green-and-yetow. saree m| jane Severs; | woe Sone | seatm soem
The wires in the mains toad on this product are coloured in [Semanctsroeee| eens ores' | |9 mam sagt ne} |traares le
accordance with the folowing code: Prom "4| [ooo «| (ee —s
Blue 'Neutral
Brown 'Live
As these colours may not correspond with the coloured mark: | 1 CLASS 1 LASER PRODUCT
ings identifying the terminalis in your ptug proceed as follows: 2 DANGER: Invisible laser radiation when open and interlock
The wire which is coloured blue must be connected to the termi: failed or defeated. Avoid direct exposure to beam
'nal which is marked with the letter N of coloured black. 3 CAUTION: Do not open the top cover. There are no user
The wire which is coloured brown masst be connected to the 1er-
minal which is marked with the letter L or coloured red.
{F IN DOUBT - CONSULT A COMPETENT ELECTRICIAN.
serviceable parts inside the Unit; leave all servicing fo qual-
ified service personnel
CAUTION
Caution — ©1 switch! To reduce the risk of electrical shocks, fire, etc
Disconnect the mains ptug to shut the power off completely 1 Do not remove screws, covars or cabinet
The ©'1 switch in any position does not disconnect the mains 2 Do not expose this appliance to rain or moisture
line. The power can be remote controlled.
Caution: Proper Ventitation
To avoid risk of electric shock and fire, and to prevent damage, locate the apparatus as follows:
3° Front No obstructions and open spacing.
4 Sides/ Top Back: No obstructions should be placed in the areas shown by the dimensions below.
5 Bottom: Place on the level surface. Maintain an adequate aw path fot ventilation by placing on a stand with a height
of 10 cm of more.
Front view Side view
sem
CAUTION
IB About the internal Cooling Fan
This unit includes an internal cooling tan, so as 10 allow for high-power operation within a smail space.
Tnis tan comes on when the sound level 1s set high. and may also come on even al low sound levels if the 'ternal temperature 'ses. To ensure
qtbetiv fan operation. pleas leave at east 15cm clearance between tho roa of te unt and the wal and al least cm cleavance on each $100 of
1 uni
G-1
Tategereleren die)
Thank you for purchasing the JVC Compact Component System.
We hope it will be a valued addition to your home. gi ving you years of enjoyment.
Be sure to read this instruction manual carefully before operating your new stereo system.
In it you will find all the information you need to set up and use the system,
If you have a query thal is not answered by the manual, please contact your dealer.
Features
Here are some of the things that make your System both powerful and simple to use.
1B The controls and operations have been redesigned to make them very easy to use, freeing you to
just enjoy the music.
+ With VC's COMPU PLAY you can tum on the System and automatically stast the Radio or
CD Player with a singte touch.
'The System incorporates Active Hyper Bass PRO circuitry to faithfully reproduce low frequency
sounds.
A 45-station preset capability (30 FM and 1S AM (MW/LW)) in addition to auto-seek and manual tuning,
CD options that include repeat, random and program play
Timer functions; Daily Timer and Sleep Timer.
The System is compatible with RDS (Radio Data System) broadcasting.
+ The EON data enables you to standby for desired information.
+ The PTY Search function searches for programmes in the category you wish.
In addition, Radio Text can be displayed using data sent by station
You can connect various external units, such as an MD recorder.
How This Manual Is Organized
'+ Basic information that is the same for many different functions - ¢.g. setting the volume - is given in the section
"Basic Operations', and not repeated under each function.
+ The names of buttons/controls and display messages are written in all capital letters: e.g. FM/AM, "NO DISC".
* System functions are written with an initial capital fetter only: e.g Normal Play.
Use the table of contents to took up specific information you require.
We have enjoyed making this manual for you, and hope it serves you in enjoying the many features built into your System
WARNINGS
* DO NOT PUT ANYTHING ON THE TOP COVER. IF THE SYSTEM IS OPERATED WITH SOMETHING
PUT ON THE TOP COVER, IT WILL BE DAMAGED WHEN YOU TRY TO OPEN THE TOP COVER.
+ NEVER REMOVE THE TOP COVER FROM THE UNIT. SERIOUS INJURY MAY OCCUR IF THE SYS-
TEM IS OPERATED WITHOUT THE TOP COVER.
IMPORTANT CAUTIONS
1 Installation of the System
* Select a place which is level. dry and neither too hot nor loo cold. (Between $°C and 35°C or 41°F and 95°B)
+ Leave sufficient distance between the System and a TV.
* Do not use the System in a place subject to vibrations.
2 Power cord
* Do not handle the power cord with wet hands!
+ Some power is always consumed as Jong as the power cord is connected to the wall outlet
+ When unplugging the System from the wall outlet, always pull the plug, not the power cord.
3 Malfunctions, etc.
+ There are no uses serviceable pans inside. In case of sysiem failure. unplug the power cord and consult your deater.
* Do not insert any metallic object into the System.
+ Do not insert your hand between the Top Cover and the main body when the 'Top Cover is being closed.
1-5
