COMPACT COMPONENT SYSTEM

FS-SD1000R

Consists of CA-FSSD1000R, SP-FSSD1000 and SP-PW1000

REMOTE CONTROL RM-SFSSD1000R

DIMMER

SLEEP

AUTO

DISPLAY

PRESET

FM MODE

PROGRAM

RANDOM

REPEAT

DOOR

SLIDE

BASS

TREBLE

CANCEL

PTY/EON

DISPLAY MODE

SET

DOWN

FADE MUTING

MD/AUX

FM / AM

VOLUME

SP-FSSD1000

CA-FSSD1000R

INSTRUCTIONS

SP-FSSD1000

SP-PW1000

For Customer Use:

Enter below the Model No. and Serial No.

which are located either on the rear, bot-

tom or side of the cabinet. Retain this

information for future reference.

Model No.

Serial No.

LVT0685-007A

[B]

Need help?

Do you have a question about the FS-SD1000R and is the answer not in the manual?

Questions and answers

Summary of Contents for JVC FS-SD1000R

Page 1 COMPACT COMPONENT SYSTEM FS-SD1000R Consists of CA-FSSD1000R, SP-FSSD1000 and SP-PW1000 REMOTE CONTROL RM-SFSSD1000R DIMMER SLEEP AUTO DISPLAY PRESET FM MODE PROGRAM RANDOM REPEAT DOOR SLIDE BASS TREBLE CANCEL PTY/EON DISPLAY MODE DOWN FADE MUTING MD/AUX FM / AM VOLUME SP-FSSD1000...
Page 2 Warnings, Cautions and Others IMPORTANT FOR LASER PRODUCTS IMPORTANT for the U.K. DO NOT cut off the mains plug from this equipment. If the plug REPRODUCTION OF LABELS fitted is not suitable for the power points in your home or the CLASSIFICATION LABEL, PLACED ON EXTERIOR SURFACE cable is too short to reach a power point, then obtain an appro- priate safety approved extension lead or consult your dealer.
Page 3 SAFETY INSTRUCTIONS “SOME DOS AND DON’TS ON THE SAFE USE OF EQUIPMENT” This equipment has been disigned and manufactured to meet international safety standards but, like any electrical equipment, care must be taken if you are to obtain the best results and safety is to be assured. ✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮...
Page 4 ■ The controls and operations have been redesigned to make them very easy to use, freeing you to just enjoy the music. • With JVC’s COMPU PLAY you can turn on the System and automatically start the Radio or CD Player with a single touch.
Page 5 Table of Contents Introduction ......................1 Features ............................1 How This Manual Is Organized ....................1 WARNINGS ..........................1 IMPORTANT CAUTIONS ....................... 1 Getting Started ....................3 Accessories..........................3 How To Put Batteries In the Remote Control ................3 Using the Remote Control......................3 Connecting the FM Antenna ......................
Page 6 Getting Started Accessories Make sure that you have all of the following items, which are supplied with the System. Power Cord (1) AM Loop Antenna (1) Remote Control (1) Batteries (2) FM Wire Antenna (1) Signal Cord (1) Spacers (4) (For SP-PW1000) If any of these items are missing, contact your dealer immediately.
Page 7 Getting Started CAUTION: • Make all connections before plugging the System into an AC power outlet. Connecting the FM Antenna Rear Panel of the Center Unit (CA-FSSD1000R) SPEAKERS IMPEDANCE 4 SUB WOOFER CD DIGITAL OUT MD / AUX ANTENNA AC IN FM(75 ) AM EXT COAXIAL...
Page 8 Getting Started Connecting the AM (MW/LW) Antenna Rear Panel of the Center Unit (CA-FSSD1000R) SPEAKERS IMPEDANCE 4 SUB WOOFER CD DIGITAL OUT MD / AUX ANTENNA AC IN AM EXT FM(75 ) COAXIAL AM LOOP AM loop antenna (Supplied) ANTENNA AM EXT FM(75 ) COAXIAL...
Page 9 Getting Started CAUTION: • Make all connections before plugging the System into an AC power outlet. Connecting the Speakers (SP-FSSD1000) These speakers are exclusively for this system. Using with other devices will damege the speakers. 1. Open each of the terminals to connect the speaker wire leads. 2.
Page 10 Getting Started Connecting the Powered Subwoofer (SP-PW1000) &RQQHFWýDýVLJQDOýFRUGýõVXSSOLHGôýEHWZHHQýWKHý6\VWHP’Vý68%:22)(5ýWHUPLQDOýDQGýWKHý/()7î0212ý,1387ýWHUPLQDOýRIýWKH 3RZHUHGý6XEZRRIHUï Powered Subwoofer Signal cord 11mm Max. SUB WOOFER * Use the plug whose diameter is 11mm or less. Attaching the Spacers Attach the supplied spacers to the bottom of the powered subwoofer (SP-PW1000) to protect the cabinet, prevent slipping, and absorb the cabinet vibration.
Page 11 COMPU Play JVC’s COMPU PLAY feature lets you control the most frequently used System functions with a single touch. With One Touch Operation you can play a CD, turn on the radio, or listen to an external equipment with a single press of the play button for that function.
Page 12 Basic Operations REMOTE CONTROL RM-SFSSD1000R DIMMER SLEEP ü DIMMER AUTO DISPLAY FM MODE PRESET DISPLAY Top Cover PROGRAM RANDOM REPEAT PRESET MD/AUX FM/AM TUNING CLOCK TIMER VOLUME DOOR SLIDE DOWN MULTI CONTROL DOOR SLIDE BASS TREBLE CANCEL BASS PTY/EON DISPLAY MODE TREBLE CLOCK VOLUME+,–...
Page 13 Basic Operations Fade-out Muting (FADE MUTING) Showing the Time (CLOCK/DISPLAY) You can mute the output with one touch operation. You can show the current time on the display. To mute the output, press the FADE MUTING button on the Remote Control. Then, the output will be faded out To display the clock, press the CLOCK button on the and becomes 0.
Page 14 Using the Powered Subwoofer STANDBY/ON indicator VOLUME PHASE INPUT (LOW-LEVEL) INPUT (HIGH-LEVEL) POWER CAUTION: Operating the Powered • Be sure to turn off the POWER of the Pow- Subwoofer ered Subwoofer when the Powered Sub- woofer is not in use for an extended period Presetting the Volume of time.
Page 15 Using the Tuner REMOTE CONTROL RM-SFSSD1000R DIMMER SLEEP AUTO DISPLAY PRESET FM MODE FM MODE AUTO PRESET PROGRAM RANDOM REPEAT PRESET MD/AUX FM/AM TUNING AHB PRO CLOCK TIMER VOLUME DOOR DOWN SLIDE MULTI CONTROL BASS TREBLE CANCEL FM/AM PTY/EON DISPLAY MODE DISPLAY MODE PTY/EON ¢...
Page 16 Using the Tuner Presetting Stations Auto Presetting You can preset up to 30 FM stations and up to 15 AM (MW/ In each band, you can automatically preset FM-30, AM LW) stations using the Remote Control. (MW/LW) -15 stations. Preset numbers will be allocated as stations are found, starting from the lowest frequency and moving up the frequency.
Page 17 Using the Tuner PS (Programme Service): While searching, “PS” appears, then station name is dis- Receiving FM Stations with RDS played. “NO PS” appears if no signal is sent. You can use the RDS (Radio Data System) by using the but- PTY (Programme Type): tons on the Unit or the Remote Control.
Page 18 Using the Tuner To search for a programme by PTY Descriptions of the PTY Codes News codes News: Topical programme expanding on the cur- Affairs: One of the advantages of the RDS service is that you can locate rent news or affairs a particular kind of programme by specifying the PTY codes.
Page 19 Using the Tuner Case 1:If there is no station broadcasting the type To temporarily switch to a broadcast of programme you have selected programme of your choice The broadcast station being currently heard will continue to be heard. EON (Enhanced Other Networks) is another convenient RDS service that allows this unit to switch temporarily to a «...
Page 20 Using the CD Player REMOTE CONTROL RM-SFSSD1000R DIMMER SLEEP AUTO DISPLAY FM MODE PRESET Top Cover PROGRAM PROGRAM RANDOM REPEAT REPEAT PRESET MD/AUX FM/AM TUNING AHB PRO CLOCK TIMER VOLUME RANDOM DOOR DOWN SLIDE CD 0 MULTI CONTROL BASS TREBLE CANCEL CANCEL ¢...
Page 21 Using the CD Player To Select a Track or Passage within a Track To Unload a CD During playback, press the 4 or ¢ (< or >) button to se- lect the track you want. Take out the CD as shown below. •...
Page 22 Using the CD Player Press the SET button. Random Play Program order number The tracks will play in no special order when you use this mode. (After 2 seconds) Press the RANDOM button on the DOWN Remote Control. The “RANDOM” indicator lights up on the display. Total playback time of the programmed tracks Press the CD #/8 button.
Page 23 Using External Equipments REMOTE CONTROL RM-SFSSD1000R DIMMER SLEEP AUTO DISPLAY FM MODE PRESET PROGRAM RANDOM REPEAT DOOR SLIDE BASS TREBLE CANCEL PTY/EON DISPLAY MODE PRESET MD/AUX FM/AM TUNING CLOCK TIMER VOLUME DOWN MULTI CONTROL DOWN FADE MUTING MD/AUX MD/AUX FM / AM MD/AUX VOLUME Listening to External...
Page 24 Using the Timers REMOTE CONTROL RM-SFSSD1000R DIMMER SLEEP SLEEP AUTO DISPLAY FM MODE PRESET PRESET PROGRAM RANDOM REPEAT MD/AUX FM/AM TUNING AHB PRO CLOCK TIMER VOLUME DOWN DOOR MULTI CONTROL SLIDE TIMER BASS TREBLE CANCEL ¢ CLOCK PTY/EON DISPLAY MODE DOWN ON time, OFF time, FADE MUTING...
Page 25 Using the Timers Set the minute you want the Unit to be turned off, us- Setting the ON time (Example: 10:15). ing the ¢ and 4 buttons. 1. Press the TIMER button on the Unit for more than two seconds. The Timer indicator lights up and the hour digit of the current ON time blinks on the display.
Page 26 Using the Timers Setting the SLEEP Timer (Using the Remote Control) Use the Sleep Timer to turn the System off after a certain number of minutes when it is playing. By setting the Sleep Timer, you can fall asleep to music and know that your Sys- tem will turn off by itself rather than play all night.
Page 27 Care And Maintenance Handle your CDs carefully, and they will last a long time. Cleaning the Lens Compact Discs If the lens in the CD pickup is dirty, dropout, etc., could de- grade sound. Open the Top Cover and clean the lens as shown. •...
Page 28 Troubleshooting • If you are having a problem with your System, check this • If you cannot solve the problem from the hints given list for a possible solution before calling for service. here, or the System has been physically damaged, call a qualified person, such as your dealer, for service.
