THORLABS M2MS Quick Reference page 11

M2MS Extension Set
Attention!
Prior to connecting the M2MS to the power supply, make sure the
wise the stage drive may be damaged!
Attention!
It is strongly recommended that only the supplied USB cables are used to connect the Beam Profiler and the
control PC to the M2MS.
The use of other than the supplied USB cables may lead to USB connection instabilities.
Attention
Do NOT connect the M2MS to a computer prior to installing the Beam Software!
1. Remove the transportation lock
2. Connect AC power to the power supply and its output to the DC jack
3. When using a BP209 Series Slit Beam Profiler, connect the Beam Profiler using the supplied angled USB 2.0
cable to one of the USB hub outputs (3). Please do not connect a BC207 and BC210C Series camera Beam
Profiler as they require USB 3.0. Please connect the BC207 and BC210C Series camera Beam Profiler directly
to the PC.
4. Switch the M2MS on (8). The green Power On indicator lights up.
5. Connect the M2MS to the PC using the supplied 3 m long USB 2.0 cable; do not start the Beam software yet.
6. The PC's operating system recognizes the connected new hardware and performs the driver installation:
7. Start the Beam Software.
8. Please see further instructions in the full manual that can be found in the "Manuals" folder.
Chapter 6
Protect the Beam Profiler from adverse environmental conditions. The Beam Profiler is not water resistant.
Attention
To avoid damage to the instrument, do not expose it to spray, liquids or solvents!
The unit does not need a regular maintenance by the user.
The M2MS Extension Set does not contain any modules that could be repaired by the user himself. If a mal-
function occurs, please contact
information.
Do not remove covers!
Rev: 8.1, 08-Aug-2023
o
Green indicator "Power On"
p
DC power supply input
q
M2MS power switch
.
6
Maintenance and Service
Thorlabs first. If necessary, you will be provided with the required return
11
© 2023 Thorlabs
Chapter 5 Operation Instructions
transportation lock is removed
(7 ).
7
! Other-
6
Page 8
