This Quick user guide will make the installation of DB9000-RX quick and easy. Applying these
principles, you can simplify the process and save yourself extra time and effort. For more information
about the Safety precautions and the Operating environment recommendations please refer to the
User Manual.
STEP 1
Connect the device to a local network or to the Internet by a cable with an RJ-45 connector.
To operate the device you need to know its IP Address. In case you are not aware of it, you can hear it
through the headphones when you turn on the the device. Alternatively, use the Network discovery feature
at Local networks (for reference see Step 13).
STEP 2
Open a WEB Browser and enter the device IP address in the browser's address field, then press Enter.
The web interface will be displayed to you with the respective main pages: Status; Configuration; MPX;
Factory Defaults; Reboot; Firmware Update.
STEP 3
Current status information will be displayed
comprising Audio Status; Network Status; Connection
Status.
For further reference see the detailed explanation on
the right part of the screen.
NOTE: Clicking on the LIVE DATA icon will toggle live
data ON and OFF
STEP 4
Click on the Configuration button. A dialog will appear. Fill in the
username and password requested, default values being: user and pass.
Device Alias
By choice, you can change the name of the device. Later on it will be used
as a title name on all WEB pages. Customizing the name will make the device
more recognizable.
Date and Time
Internet Time – Enable or disable automatic time synchronization from
Ÿ
Time Zone – Select local time zone of the device.
Ÿ
Local Date and Local Time – Enter the local date and time if the
Ÿ
NOTE: After selecting new settings, press the SAVE button to put them into
effect. Some of the new settings can reset DB9000-RX.
Internet.
Internet Time is disabled.

Connection

WEB Interface

Status Section

General Settings
