4 Turbo Petrol Installation
Step 4 of 6 - Connect to Supply Pressure
1
Supply pressure connection
First locate the sensors where to connect the wiring, supply pressure sensor and
•
turbo pressure sensor. Usually the feed sensor is placed on the suction ange,
after the turbo, the second turbo pressure sensor is usually after the throttle on the
intake manifold.
Schematic representation:
Pressure connection
power supply
Cable coming from
ProRacing
A
Cable with connector
standard o
Pressure connection
power supply
7
