ProRacing TS2 PRO User Manual page 13

Proracing is con gured speci cally for your car, all parameters are adjusted for one
uid delivery and with an adequate compromise between consumption and power increases. In some
however, it is possible to further modify the settings by unscrewing the torx and opening the
control unit. Inside there are two selectors called S1 and S2, the same selectors are present
in the smartphone application on the setting page.
The minimum setting is 8, the maximum setting is 7 and is distributed in this sequence:
If you change the S1 and S2 settings and have purchased the TS2 PRO version with bluetooth le
eco sport and race mappings will be recreated via argorithm based on the settings
selected.
• The S1 selector modi es power and torque, we recommend increasing one step at a time in a
clockwise direction.
• The S2 selector is responsible for the duration of the performances for a greater range of revolutions,
normally this selector should not be touched to prevent the car from going into protection.
If you incorrectly change the selector parameters you may no longer have the performance
optimal, even send it to the Recovery system.
Warning: the higher setting is not always the same as the greater increase in power.
Problems with serrations, the gear is not smooth?
-Does the automatic gearbox give abnormal bumps at high revs?
If while driving you feel gaps accelerating or an irregular trend, you can
•
use selector S2 by raising the adjustment and bringing it to position 4.
• If the serration is less noticeable but still noticeable bring it into place
5 or 6 or 7.
The technicians of Proracing according to your needs can help you to calibrate in a manner
optimal (we advise you to always ask).
6 Custom adjustment.
Selettore S1:
S1
MIN 8-9-A-B-C-D-E-F-0-1-2-3-4-5-6-7 MAX
Selettore S2:
S2
17
