- Page 1 Read before installation User Manual TS2 PRO Turbo petrol engines...
- Page 2 Index .......................... 1 Application and Photo montage 2 Proracing overview ..................................................4 Petrol Engines Assembly 5 First start-up ..............................11 ..................................................12 6 Adjustment ..........................14 7 Troubleshooting 7 Contact details .............................. 18 Overview and explanation of the symbols used Warnings on dangers with important information on use.
- Page 3 1 Applicazione per smartphone (optional) Scarica l’app Proracing sul tuo Smartphone e scopri il nuovo piacere di guida. Scansiona con la fotocamera del tuo smarthphone e verrai indirizzato automaticamente all’app store. Android APP iOS APP Normalmente dopo l’acquisto, inviamo tramite mail le foto speci che per il tuo...
- Page 4 2 Panoramica di Proracing TS2 PRO Luminous program interface ECO: Blue color SPORT: Green color RACE: Red color Holes for closing the box opening (TORX) FCI socket connection for xing of the Proracing TS2 PRO harness Holes for xing with cable ties.
- Page 5 3 Installation Phase 1 of 6 - preparing the installation Let the engine cool down before installing the Proracing ECU, you could burn yourself. Open the bonnet and keep the doors locked. Wait about 10 minutes before acting, in this way all the electrical equipment will be deactivated.
- Page 6 3 Installation Step 2 of 6 - Remove the engine cover Normally after purchase, we send speci c photos for yours by email engine for easy editing, then check your mail. In the following images there will be sample photos. Your car may di er, However, the installation is very similar.
- Page 7 Usually the feed sensor is placed on the suction ange, after the turbo, the second turbo pressure sensor is usually after the throttle on the intake manifold. Schematic representation: Pressure connection Pressure connection power supply power supply Cable with connector Cable coming from standard o ProRacing...
- Page 8 4 Assembly of turbo petrol engines To disconnect the connectors from the sensors it is necessary to press not too hard in order to raise the • release clip or move the safety catch. We normally have 90% of the photos in the catalog of all engines, check your inbox registration, at the time of purchase we send the speci c photos in our possession.
- Page 9 Locate the turbo pressure sensor usually located after the throttle body on the • intake manifold, disconnect the connectors and interpose the wiring as shown in the gure schematized. Schematic representation: Link to tube pressure suction Pressure connection of the suction pipe Cable coming from Cable with connector series o Proracing...
- Page 10 4 Assembly To disconnect the connectors from the sensors it is sometimes necessary to raise the safety and then • press the release clip using not too much force and remove the connector. Instructions for disconnecting the suction hose pressure connector are available on the enclosed sheet.
- Page 11 This can cause in some cases an error in the dashboard, the control unit Engine ECU may have detected a wiring harness disconnection. Carry out a rst function test Rest Proracing with the harness securely possibly already clamped in such a way • that no moving part of the engine can create problems.
- Page 12 However, the default basic value is always indicated in the consignment note. This setting is an example that identi es A-0 adjustments available on the version without Application: In case the starting setting of your Proracing is A-0 we recommend these power steps: Selettore...
- Page 13 The minimum setting is 8, the maximum setting is 7 and is distributed in this sequence: MIN 8-9-A-B-C-D-E-F-0-1-2-3-4-5-6-7 MAX If you change the S1 and S2 settings and have purchased the TS2 PRO version with bluetooth le eco sport and race mappings will be recreated via argorithm based on the settings selected.
- Page 14 7 Troubleshooting If you've been experiencing dash warning lights issues or don't feel enough power boost here nd the rst support. If you do not nd the information you are looking for, you can contact assistance customers. Error description How to intervene •...
- Page 15 7 Troubleshooting Error description How to intervene • After installation, warning lights on the dashboard came on The control light giving error? engine or other warning This does not always result in a real problem given that lights in the dashboard if you have disconnected any connectors in the engine when it was remain on.
- Page 16 3. The bosch / siemens fuel system does not match when adjusting Proracing, go to the Bosch / Siemens chapter No savings of •...
- Page 17 8 Contact details Our customer service is available in the dedicated section on our website www.pro.racing.it Legal information PRORACING by Privi Auto Via Federico Confalonieri 50 20099 Sesto San Giovanni -MI- VAT number : 06494530964 mail: info@pro-racing.it web: www.pro-racing.it...
