Panasonic TH-103VX200W Service Manual
  1. Manuals
  2. Brands
  3. Panasonic Manuals
  4. Monitor
  5. TH-103VX200W
  6. Service manual

Panasonic TH-103VX200W Service Manual

High definition plasma display
Hide thumbs Also See for TH-103VX200W:
Table of Contents

Advertisement

Quick Links

Download this manual

TABLE OF CONTENTS

1 Safety Precautions----------------------------------------------- 3
1.1. General Guidelines---------------------------------------- 3
1.2. Touch-Current Check ------------------------------------- 3
2 Warning -------------------------------------------------------------- 4
2.2. About lead free solder (PbF)---------------------------- 5
3 Service Navigation ----------------------------------------------- 6
3.1. Service Hint ------------------------------------------------- 6
3.2. Applicable signals ----------------------------------------- 8
4 Specifications ----------------------------------------------------- 9
5 Operating Instructions-----------------------------------------10
6 Service Mode -----------------------------------------------------11
sample data) -----------------------------------------------15
7 Troubleshooting Guide ----------------------------------------16
7.1. Self Check--------------------------------------------------16
7.2. No Power ---------------------------------------------------18
High Definition Plasma Display
Model No.
GPF13DMONV Chassis
PAGE
7.3. No Picture-------------------------------------------------- 18
7.4. Local screen failure-------------------------------------- 19
8 Service Fixture & Tools --------------------------------------- 20
8.1. SC jig-------------------------------------------------------- 20
9.1. Rear Cover and Board---------------------------------- 21
9.2. Location of Rear Cover screws----------------------- 22
9.3. Removal of Side Angle (L), (R) ----------------------- 24
9.4. Removal of HX-Board----------------------------------- 25
9.5. Removal of DS-Board ---------------------------------- 26
9.6. Removal of A-Board------------------------------------- 26
9.7. Removal of DN-Board ---------------------------------- 27
9.8. Removal of PB-Board----------------------------------- 27
9.9. Removal of D-Board------------------------------------- 27
9.10. Removal of P-Board (MAIN_1) ----------------------- 28
9.11. Removal of P-Board (MAIN_2) ----------------------- 28
9.12. Removal of P-Board (SUB)---------------------------- 28
9.14. Removal of SU-Board ---------------------------------- 29
© Panasonic Corporation 2010
Unauthorized copying and distribution is a violation
of law.
Order Number ITD1012166CE
TH-103VX200W
