HODEDAH
Assembly Instructions
This instruction booklet contains important safety information, please read and keep for future reference.
ITEM # HID 23-D
3 SHELF BOOKCASE
FRONT VIEW
Product Dimensions:
www.Hodedah.com
®
Height 35.6'' x Width 15.9'' x Depth 11.7''
Weight Capacity per shelf: 20 Ibs
1 person
30 mins
1 YR LTD
1 Box
BACK VIEW
1 |
Page
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Hodedah HID 23-D
Summary of Contents for Hodedah HID 23-D
- Page 1 HODEDAH ® Assembly Instructions 1 person This instruction booklet contains important safety information, please read and keep for future reference. 30 mins ITEM # HID 23-D 1 YR LTD 3 SHELF BOOKCASE 1 Box FRONT VIEW BACK VIEW Product Dimensions: Height 35.6'' x Width 15.9'' x Depth 11.7''...
- Page 2 FREE of charge within ONE YEAR of purchase! WARRANTY Hodedah warrants this product to be free from defects in materials and workmanship and agrees to remedy any such defect. This warranty covers one year from the date of original purchase. This is solely limited to replacement of defective parts and no assembly for labor is included.
-
Page 3: Product Care And Maintenance
HODEDAH ® · Never open more than one drawer at a time. · The use of tip-over restraints may reduce but not eliminate the risk of tip-over. Let's get started… Helpful hints, read before beginning assembly · Make sure you receive all boxes. If your item is packed in one box, box count will read 1 of 1, likewise if your item is packed in two boxes, box count will read 1 of 2 and second box will read 2 of 2. -
Page 4: Hardware List
HODEDAH ® Hardware List JCBCW M5 x 40mm PVC NAIL ALLEN KEY SCREW ANTI-TIP KIT Important 1. Before you throw the package, please use the Check Box to identify the parts and hardware to ensure that you have everything you need. -
Page 5: Part List
HODEDAH ® Part List Page www.Hodedah.com... - Page 6 HODEDAH ® The Breakdown Page www.Hodedah.com...
- Page 7 HODEDAH ® Step 1 PVC NAIL - Fix 4 x Pvc Nails (B) into panels (4) & (5) using a Hammer. Step 2 JCBCW M5 x 40mm SCREW ALLEN KEY - Attach panel (4) to panels (1) , (2) , (3).
-
Page 8: Final Step
HODEDAH ® Step 3 Almost there - Slide panels (6) into the groove of panels (1) , (2) , (3). Step 4 Final step JCBCW M5 x 40mm SCREW ALLEN KEY - Attach panel (5) to panels (1) , (2) , (3). - Page 9 HODEDAH ® FITTING OF ANTI-TIP SAFETY STRAP STEP 1: · Attach the mounting bracket a to the furniture in the solid part below the top panel a few inches away from the side of the unit. · Screw b through the smallest hole of a .
-
Page 10: Job Complete
HODEDAH ® Job Complete Enjoy & Thank you for purchasing from Hodedah! 10 | Page www.Hodedah.com...
