Symmons Dia SLS-3522-1.5 Installation Brief

Lavatory Faucet
Installation Brief
Model Numbers
SLS-3522-1.5 Lavatory faucet only,
(5" height)
Modification Options
Append -suffix code to part numbers
when applicable
-1.0 1.0 gpm (3.8 L/min) aerator

Dimensions
B B
A A
C C
WARNING: This product can expose you to chemicals including lead, which is known to the state of California to cause
cancer, birth defects, or other reproductive harm. For more information, go to www.P65Warnings.ca.gov.
Dia
SLS-3522-1.5
Tools & Materials
2.5 mm
Dia Lavatory Faucet, SLS-3522-1.5
F F G G
H H
®
PLUMBERS
PUTTY
D D E E
I I
J J
K K
L L

Need Help?
Contact Symmons customer service at
P: (800) 796-6667, (781) 848-2250
Email: gethelp@symmons.com
Monday - Friday 7:30 am - 6:00 pm EST

Please check Symmons website
for technical help, the latest product
information, warranty policy and a list of
Symmons distributors
www.symmons.com
Measurements
A 1-7/8", 48 mm
B 1-3/16", 30 mm
Hole Size
C Min. Ø 1-1/4", 32 mm
Max. Ø 1-1/2", 38 mm
D 4-1/16", 103 mm
E Min. 2-1/2", 64 mm
F 6-1/8", 155 mm
G 5", 127 mm
H 3-5/16", 84 mm
I 26°
Deck Thickness Ref.
J Min. 7/8", 22 mm
Max. 1-7/8", 47 mm
K 25-7/8", 658 mm
L 3/8" compression fitting
