Inverter
White wire
3 4
Grid
23 SINGLE PHASE HI 10/12kW | User Manual
Black wire
3
If the data read by the CT is wrong, you can try to point
the direction of the CT to the grid.
CT
4
If the CT coil is fitted in the wrong way
then this variable will have negative
instead of positive values when the
power is flowing into the
house/inverter. Also, the inverter
export limiting function will not work
properly.
N L
CT
L
Arrow pointing
N
to inverter
The primary side of the CT
needs to be clamped on the
Grid live line.
