INSTALLATION GUIDELINES

1. This equipment, being built-in-type, normally becomes a part of main control panel and in
such case the terminals do not remain accessible to the end user after installation
and internal wiring.
2. Do not allow pieces of metal, wire clippings, or fine metallic fillings from installation to
enter the product or else it may lead to a safety hazard that may in turn endanger life or
cause electrical shock to the operator.
3. Circuit breaker or mains switch must be installed between power source and supply
terminal to facilitate power 'ON' or 'OFF' function. However this mains switch or circuit
breaker must be installed at convenient place normally accessible to the operator.
4. Use and store the instrument within the specified ambient temperature and humidity
ranges as mentioned in this manual.

MECHANICAL INSTALLATION GUIDELINES

1) To install the instrument on a DIN rail, raise the clamp at the back of the instrument
and place it on the rail. Now release the clamp, so the instrument fits on the DIN rail.
2) Ensure proper fitting of the instrument by pulling it outwards.
3) To remove the instrument raise the clamp to release it from the DIN rail.
4) The equipment in its installed state must not come in close proximity to any heating
source, caustic vapors, oil steam, or other unwanted process byproducts.
5) Do not connect anything to unused terminals.
