Operating instructions VisionLine 2.0 camera systems
4

Operation

The camera system is designed for continuous operation and can therefore remain switched on conti-
nuously.
NOTICE
During the operation of the machine, it is not allowed to interrupt the compressed air
supply (1 bar) of the camera systems VisionLine RWC and VisionLine EAC.
4.1

Commisioning

CAUTION
Commissioning is only authorized by qualified personnel. During commissioning there is
a risk of starting or rotating parts. Avoid contact during the operation.
When the assembly has been successfully completed, commissioning can begin.
First pressurize the system with compressed air: Set the air service unit via the pressure regulator
so that the pressure gauge shows a pressure of approx. 0.3 to 0.5 bar.
Make sure that both, the control box and the playback device, are connected to the power supply.
Connect the control box and a suitable playback device (with the HDMI input) by plugging an
HDMI cable into the appropriate ports of the respective devices. Make sure the HDMI connector
on the control box snaps into place.
For the RWC and EAC models, connect the Ø6mm compressed air adapter with a compressed air
supply of 1 bar.
Now switch on the playback device: probably you have to set the signal input to „HDMI" on themo-
nitor. Instructions for this are provided by the manufacturer of the playback device you are using.
Now switch on the camera system.
After powering up the system on the control box, it may take up to 30 seconds before the first
footage is transferred to your monitor.
Your new UYAR camera system is now ready for use!
